44 Modbus Communications
Register Description
(Decimal)
8024 Request Flow
Viscosity
8025 Calibrate Temp
Low
8026 Calibrate Temp
High
8027 Calibrate Press
Low
8028 Calibrate Press
High
8029 Temperature
Units
8030 Pressure Units
8031 Density Units
Request Flow
8038-39
Temperature
†
(16-bit)
8042-43 Request Flow
† Pressure
(16-bit)
Request Flow
8050-51
Density
†
(16-bit)
Request Flow
8054-55
Viscosity
†
(16-bit)
* The Total and Grand Total values are available in 3 formats:
64-bit in a single register, 64-bit in four consecutive 16-bit
registers and 32-bit in two consecutive 16-bit registers. The
64-bit format is recommended for greater precision, especially
with values greater than 7-digits.
Temperature, Pressure, Density and Viscosity are available in
†
16-bit registers in firmware versions 1.020821 and later.
HP-329
Data Access
Type
FP32 RO
U16 R/W
U16 R/W
U16 R/W
U16 R/W
U16 R/W
U16 R/W
U16 R/W
FP32 RO
FP32 RO
FP32 RO
FP32 RO
Notes
Flowing Viscosity
Write 5000 to calibrate
Read for A/D counts
Write 5000 to calibrate
Read for A/D counts
Write 5000 to calibrate
Read for A/D counts
Write 5000 to calibrate
Read for A/D counts
0 = Fahrenjeit;
1 = Celsius
0 = PSIA, 1 = bar-a,
2 = PSIG, 3 = bar-g
0 = lb/gal; 1 = kg/l
Flowing Temperature
in two consecutive
16-bit registers
Flowing Pressure in
two consecutive 16-
bit registers
Flowing Density in
two consecutive 16-
bit registers
Flowing Viscosity in
two consecutive 16-
bit registers
HIT-4L
