40 Modbus Communications
Register Description
(Decimal)
2067 Frequency 17
2069 Frequency 18
2071 Frequency 19
2073 Frequency 20
2075 K-Factor 13
2077 K-Factor 14
2079 K-Factor 15
2081 K-Factor 16
2083 K-Factor 17
2085 K-Factor 18
2087 K-Factor 19
2089 K-Factor 20
4000 Pulse Function
4001 Pulse Width
(mS)
4003 Pulse Scale
4005 Analog Out
Function
4007 Analog Out Low
4009 Analog Out High
4011 Alarm Function
4012 Total Alarm Set
Point
4013 Rate Alarm Low
Set Point
4014 Rate Alarm High
Set Point
7000 Request Hourly
Log Pointer
7001 Request Daily
Log Pointer
HP-329
Data Access
Type
FP32 R/W
FP32 R/W
FP32 R/W
FP32 R/W
FP32 R/W
FP32 R/W
FP32 R/W
FP32 R/W
FP32 R/W
FP32 R/W
FP32 R/W
FP32 R/W
U16 R/W
U16 R/W
U16 R/W
U16 R/W
FP32 R/W
FP32 R/W
U16 R/W
FP64 R/W
FP32 R/W
FP32 R/W
FP32 RO
FP32 RO
Notes
0.001-5000.000
0.001-5000.000
0.001-5000.000
0.001-5000.000
0.001-9999999
0.001-9999999
0.001-9999999
0.001-9999999
0.001-9999999
0.001-9999999
0.001-9999999
0.001-9999999
0=off, 1=on, 2=test
4-300mS
0=0.01, 1=0.1, 2=1,
3=10, 4=100
0=off, 1=rate, 2=4mA,
3=12mA, 4=20mA
0.000-999998
0.001-999999
0=off, 1=rate lo, 2=rate
hi 3=rat lohi, 4=total,
5=test
0.001-99999999
0.001- Max limited by
rate decimal point
selection: 999.999,
9999.99, 99999.9,
99999
0.001- Max limited by
rate decimal point
selection: 999.999,
9999.99, 99999.9,
99999
-1 (cleared logs) - 767
-1 (cleared logs) - 383
