South bend SB1039 Product Specifications
14" x 40" 16 speed lathe 220v
Hide thumbs
Also See for SB1039:
- Owner's manual (132 pages) ,
- Owner's manual (132 pages) ,
- Manual insert (136 pages)
Table of Contents
Advertisement
Quick Links
14" x 40" 16 Speed Lathe 220V
Product Dimensions
Weight........................................................................................................................................................... 2420 lbs.
Width (side-to-side) x Depth (front-to-back) x Height................................................... 80-3/4 x 32-1/8 x 54-3/8 in.
Footprint (Length x Width)........................................................................................................... 80-3/4 x 19-1/2 in.
Shipping Dimensions
Type.................................................................................................................................................. Wood Slat Crate
Content.......................................................................................................................................................... Machine
Weight........................................................................................................................................................... 2420 lbs.
Length x Width x Height................................................................................................................... 33 x 81 x 55 in.
Electrical
Power Requirement................................................................................................................. 220V, 3-Phase, 60 Hz
Prewired Voltage................................................................................................................................................ 220V
Full-Load Current Rating................................................................................................................................. 14.4A
Minimum Circuit Size.......................................................................................................................................... 20A
Connection Type..................................................................................................................................... Cord & Plug
Power Cord Included.............................................................................................................................................. No
Recommended Power Cord............................................................................. "S"-Type, 4-Wire, 12 AWG, 300 VAC
Plug Included.......................................................................................................................................................... No
Recommended Plug Type................................................................................................................................... 15-20
Switch Type....................................................................................... Control Panel w/Magnetic Switch Protection
Recommended Phase Converter...................................................................................................................... G7978
Motors
Main
Type........................................................................................................................................ TEFC Induction
Horsepower................................................................................................................................. 5 HP / 2.5 HP
Phase.................................................................................................................................................... 3-Phase
Amps.................................................................................................................................................... 14A/10A
Speed..................................................................................................................................... 3450 / 1720 RPM
Power Transfer ............................................................................................................................ V-Belt Drive
Bearings................................................................................................ Shielded & Permanently Lubricated
Coolant Pump
Type......................................................................................................................... TEFC Induction (Class F)
Horsepower............................................................................................................................................ 1/8 HP
Phase.................................................................................................................................................... 3-Phase
Amps.......................................................................................................................................................... 0.4A
Power Transfer ............................................................................................................................ Direct Drive
Bearings................................................................................................ Shielded & Permanently Lubricated
Model SB1039
Model SB1039
Page 1 of 3
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for South bend SB1039
Summary of Contents for South bend SB1039
- Page 1 Model SB1039 14" x 40" 16 Speed Lathe 220V Product Dimensions Weight................................2420 lbs. Width (side-to-side) x Depth (front-to-back) x Height........... 80-3/4 x 32-1/8 x 54-3/8 in. Footprint (Length x Width)......................80-3/4 x 19-1/2 in. Shipping Dimensions Type..............................Wood Slat Crate Content................................
- Page 2 Main Specifications Operation Info Swing Over Bed..........................14.17 in. Distance Between Centers........................40 in. Max Weight Between Centers......................440 lbs. Swing Over Cross Slide........................8.66 in. Swing Over Saddle..........................13-3/4 in. Swing Over Gap..........................20.94 in. Maximum Tool Bit Size.......................... 3/4 in. Compound Travel............................
- Page 3 Construction Base..............................Cast Iron Headstock............................Cast Iron Headstock Gears......................Flame Hardened Steel Bed..............Induction-Hardened, Precision-Ground Meehanite Cast Iron Body..............................Cast Iron Stand..............................Cast Iron Paint..............................Urethane Fluid Capacities Headstock Capacity..........................6.4 qt. Headstock Fluid Type............ISO 32 (eg. Grizzly T23963, Mobil DTE Light) Gearbox Capacity............................
