Summary of Contents for Qtx RP4
Page 1
4-Channel DMX Relay Pack Item ref: 154.111UK User Manual Caution: Please read this manual carefully before operating Damage caused by misuse is not covered by the warranty www.avsl.com 154.111UK User Manual...
Page 2
Fuses The RP4 can carry maximum overall load of 10 amps. Each channel can also carry a maximum overall load of 10 amps but the unit is factory fitted with 10amps on each channel. These can be changed but the maximum overall load and each channel load must not exceed 10 amps.
Page 3
Channel 4 ON The RP4 can be used as a 4 Channel DMX switch pack or for standalone operation: Stand alone: Set DIP switch 10 to OFF then use switch 1 to 4 to turn on / turn off each channel DMX Mode: Set DIP switch 10 to ON and use DIP switches 1 - 9 to set the DMX start address.
