Instructions - Parts List
Pressure Cups
Part No. 244731, Series A, 1 Quart Size
20 psi (0.14 MPa, 1.4 bar) Maximum Working Fluid Pressure
Part No. 287301, Series A, 2 Quart Size
50 psi (0.35 MPa, 3.5 bar) Maximum Working Fluid Pressure
Graco Inc. P.O. Box 1441 Minneapolis, MN 55440-1441
Copyright 2003, Graco Inc. is registered to I.S. EN ISO 9001
Part No.
244731
309361F
Part No.
287301
ti1640c
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Graco 244731
Summary of Contents for Graco 244731
- Page 1 Part No. 287301, Series A, 2 Quart Size 50 psi (0.35 MPa, 3.5 bar) Maximum Working Fluid Pressure Part No. Part No. 287301 244731 ti1640c Graco Inc. P.O. Box 1441 Minneapolis, MN 55440-1441 Copyright 2003, Graco Inc. is registered to I.S. EN ISO 9001...
-
Page 2: Preparation For Operation
When using the pressure cup with an elec- ids containing such solvents in this equipment. Such trostatic spray gun, connect the Graco use could result in a serious chemical reaction, with Grounded Air Supply Hose between the... - Page 3 Preparation for Operation Air Hose Ground Wire (used on electrostatic Pressure Cup guns only) Main Air Inlet Air Spray Gun (electrostatic gun shown) Fluid Outlet Gun Air Regulator Fluid Hose Cup Air Regulator Air Hose (for electrostatic guns use the grounded air hose shown) One Quart Pressure Cup Two Quart Pressure Cup...
-
Page 4: Operation
Operation Operation One Quart Pressure Cup 2. Turn off the gun air regulator (4) and the cup air reg- ulator (6). 3. Trigger the gun into a grounded metal waste con- tainer to relieve the fluid pressure. WARNING 4. Place the cup on a table and slowly release the clamp lever (3b) to bleed off pressure in the cup. - Page 5 Operation Operation Two Quart Pressure Cup 2. Turn off the gun air regulator (2) and the cup air reg- ulator (10). 3. Open the pressure relief valve all the way (counter- clockwise) to bleed off pressure in the cup. WARNING 4.
- Page 6 Cleaning Cleaning One Quart Pressure Cup 8. Remove the solvent from the cup and wipe the equipment with a solvent dampened rag. 9. Assemble the empty cup and set the cup air regula- tor to 10 psi (.07 MPa, 0.7 bar). Spray the gun into a waste container until all the solvent is purged.
- Page 7 Cleaning Cleaning Two Quart Pressure Cup CAUTION To avoid swelling of the gasket, do not soak the gas- CAUTION ket or expose it to solvent for a prolonged period when cleaning the pressure cup lid. To avoid damage to the air regulator diaphragms, do not clean the air regulators in a gun washer or use any cleaning method which allows solvent to enter the regulator.
- Page 8 Parts Parts Part No. 244731 Pressure Cup (1 Quart) TI1639b 309361F...
- Page 9 1/4 in. (6 mm) OD 108190 GAUGE, pressure, air, gun 117243 ADAPTER, hex pipe 116904 REGULATOR, air, pressure cup Technical Data (Model 244731) Category Data Maximum Working Fluid Pressure 20 psi (0.14 MPa, 1.4 bar) Air inlet fitting 1/4 npt(m) Diameter 5.25 in.
- Page 10 Parts Part No. 287301 Pressure Cup (2 Quart) ti1643d 309361F...
- Page 11 Parts Ref. Part No. Description Ref. Part No. Description 116903 REGULATOR, air 287302 CUP, pressure 2 qt. 104655 GAUGE, pressure, air, cup 111804 REGULATOR, air, gun 110440 TEE, branch, male, 1/8 npt 110436 GAUGE, pressure, air 189557 RESTRICTOR, air, regulator 156971 NIPPLE, short 115671...
-
