Instructions - Parts List
Wall Mount Bulk Oil
Transfer Packages
For dispensing non-corrosive and non-abrasive oils and lubricants only. For professional
use only.
Not approved for use in European explosive atmosphere locations.
Model Number 244846, 3:1 Fire-Ball
180 psi (1.2 MPa, 12 bar) Maximum Air Inlet Pressure
540 psi (3.7 MPa, 37 bar) Maximum Fluid Working
Pressure
Model Number 244628, 6:1 Fire-Ball 425
180 psi (1.2 MPa, 12 bar) Maximum Air Inlet Pressure
1100 psi (3.7 MPa, 37 bar) Maximum Fluid Working
Pressure
Model Number 244847, 10:1 Fire-Ball 425
180 psi (1.2 MPa, 12 bar) Maximum Air Inlet Pressure
1800 psi (3.7 MPa, 37 bar) Maximum Fluid Working
Pressure
Important Safety Instructions
For complete warnings refer to the
Operating and/or Repair manual 3:1
Fire-Ball 425 Pump, 6:1 Fire-Ball 425 Pump,
or 10:1 Fire-Ball 425 Pump.
Related Manuals
Manual in
Description
English
308485
3:1 Fire-Ball 425 Pump
308608
6:1 Fire-Ball 425 Pump
308655
10:1 Fire-Ball 425 Pump
®
425
309351E
EN
