Antenna Characteristics; Mechanical Details - Lancom AirLancer ON-Q60ag Mounting Instructions

Technical details
Frequency range

Antenna characteristics

Radiation characteristics
Recommended use
VSWR
Gain

Mechanical details

Size
Weight
Temperature range
Color
Material
Mounting options
Cables, connectors
Item
Warranty
Item number
Package content
2.4 & 5 GHz h-plane
10
330
5
0
-5
-10
300
-15
-20
-25
-30
270
-35
240
210
2400 - 2500 MHz, 4900 - 5900 MHz
horizontal (2.4 GHz)
vertical (2.4 GHz)
horizontal (5
vertical (5
Point-to-multipoint, sector
1.5:1 typ. / 2.0:1 max.
2.4 GHz 6.5 dbi max.
5 GHz 7.5 dbi max.
200 x 200 x 34 mm (length x width x height)
450 g (antenna without mounting kit)
-40°C bis 70°C
Light grey
UV-resistant plastic
Wall mounting, fixed
Wall, and pole mounting, adjustable (with optionally available AirLancer Mount (ON))
3 x 81.2 cm UV-resistant RG316 cable with N-plug connector
2 years for AirLancer and accessories
61248
Antenna, fastening screws, dowels, Quick Reference Guide
