OPERATORS MANUAL
EN p. 2
CLHT2422_V1
Read all safety rules and instructions carefully before operating this tool.
Distributed By Cleva North America 601 Regent Park Court Greenville, SC 29607 (866)-384-8432
22" - 24V MAX** LITHIUM-ION CORDLESS HEDGE
TRIMMER CLHT2422
** Maximum initial battery workload voltage
(measured without a workload) is 24 volts.
Nominal voltage is 21.6 volts

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CLHT2422 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for LawnMaster CLHT2422

Summary of Contents for LawnMaster CLHT2422

  • Page 1 OPERATORS MANUAL EN p. 2 22" - 24V MAX** LITHIUM-ION CORDLESS HEDGE TRIMMER CLHT2422 ** Maximum initial battery workload voltage (measured without a workload) is 24 volts. Nominal voltage is 21.6 volts CLHT2422_V1 Read all safety rules and instructions carefully before operating this tool.

  • Page 2: Table Of Contents

    CONTENTS CONTENTS PRODUCT SPECIFICATIONS GENERAL SAFETY RULES ELECTRICAL INFORMATION SYMBOLS KNOW YOUR CORDLESS HEDGE TRIMMER ASSEMBLY BATTERY PACK AND CHARGER 12-14 OPERATING 14-16 MAINTENANCE ENVIRONMENTALLY SAFE BATTERY DISPOSAL WARRANTY EXPLODED DIAGRAM PARTS LIST NOTES PRODUCT SPECIFICATIONS 24 V LITHIUM-ION CORDLESS HEDGE TRIMMER TYPE Cordless, Battery-powered BATTERY...

  • Page 3: General Safety Rules

    GENERAL SAFETY RULES WARNING Read and understand all instructions before using this prod- uct. Failure to follow all instructions listed below may result in electric shock, fire, and / or serious personal injury. • Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases, or dust.
  • Page 4 GENERAL SAFETY RULES • Do not force tool. Use the correct tool for your application. The correct tool will do the job better and safer at the rate for which it is designed. • Do not operate the equipment while barefoot or when wearing sandals or similar lightweight footwear.

  • Page 5: Electrical Information

    ELECTRICAL INFORMATION • Do not charge battery tool in rain, or damp or wet location. Following this rule will reduce the risk of electric shock. • For household use only. • For household use only.Battery tools do not have to be plugged into an electrical outlet therefore, they are always in operating condition.
  • Page 6 ELECTRICAL INFORMATION sharp blow. • Exercise care in handling batteries in order not to short the battery with conducting materials such as rings, bracelets, and keys. The battery or conductor may overheat and cause burns. Do not open or mutilate the batteries. Released electrolyte is corrosive and may cause damage to the eyes or skin.
  • Page 7 ELECTRICAL INFORMATION CHILD SAFETY Tragic accidents can occur if the operator is not aware of the presence of children. • Keep children out of the working area and under the watchful care of a responsible adult. • Do not allow children under the age of 14 to operate this hedger.
  • Page 8 SYMBOL S On the product, the rating label and within these instructions you will find among others he following symbols and abbreviations. Familiarise yourself with them to reduce hazards like personal injuries and damage to property. SLOBMY NEMA DNOITANALPXE/NOITANGISE Volts Voltage Amperes Current...

  • Page 9: Symbols

    SYMBOLS The following signal words and meanings are intended to explain the levels of risk associated with this product. SYMBOL SIGNAL MEANING DANGER Indicates an imminently hazardous situation, which, if not avoided, will result in death or serious injury. WARNING Indicates a potentially hazardous situation, which, if not avoided, could result in death or serious injury.

  • Page 10: Know Your Cordless Hedge Trimmer

    KNOW YOUR CORDLESS HEDGE TRIMMER KNOW YOUR PRODUCT This LawnMaster cordless hedge trimmer features laser cut blades made of special-grade steel. When trimming, slowly cut in a back and forth linear shearing motion. NEVER force the tool, let the tool do the work. The protective tip at the top of the blade prevent unpleasant kickback reactions when hitting walls, fences, etc.

  • Page 11: Assembly

    ASSEMBLY DANGER If the hedge trimmer blade jams or gets caught on an electrical cord or wires, DO NOT TOUCH THE BLADE FOR ANY REASON! IT CAN BE ELECTRICALLY LIVE AND CAUSE SERIOUS OR FATAL INJURY! Release or drop the trimmer in the quickest, safest way. If possible, disconnect the dbattery from the tool.
  • Page 12 ASSEMBLY BATTERY PACK AND CHARGER Release/Attach ● Press the release button Hedge Trimmer on the battery pack and remove battery from product (Fig. 2). ● Align the battery pack to Slide Battery Into Tool the slots at the bottom Battery Pack Fig.

  • Page 13: Battery Pack And Charger

    BATTERY PACK AND CHARGER BATTERY CHARGING ● Do not use other battery chargers. The battery charger supplied is specifically designed for the Lithium-Ion battery used in this garden appliance. This ISM device complies with Canadian ICES-003. ● Check the mains voltage! Battery chargers operate on 100-240 V. ●...
  • Page 14 ● Your product is now ready to be used. Intended Use This hedge trimmer CLHT2422 is with rated battery voltage of 24V. This hedge trimmer is charged with a charger which output is 24V. The product is intended for trimming hedges, bushes and shrubs. Observe the technical data for the maximum cutting capacity.
  • Page 15 OPERATION General Operation ● Check the product, its battery pack and charger as well as accessories for damage before each use. Do not use the product if it is damaged or shows wear. ● Double check that accessories or application tools are properly fixed. ●...
  • Page 16 OPERATION Trimming (See figs. 6-7) ● Cut and remove branches exceeding the cutting capacity of this product using a proper pruner before operation. ● Move the cutting device lightly through the cutting surface in a sweeping motion following the shape of the hedge or shrub. ●...

  • Page 17: Maintenance

    MAINTENANCE WARNING In order to avoid personal injury and the risk of fire and electric shock, remove the battery pack before adjusting, inspecting, or cleaning the hedge trimmer. Remove The Battery Pack. 1. Clean the product with a dry cloth. Use a brush for areas that are hard to reach. 2.

  • Page 18: Environmentally Safe Battery Disposal

    ENVIRONMENTALLY SAFE BATTERY DISPOSAL The following toxic and corrosive materials are in the batteries used in this hedge trimmer battery pack: Lithium-Ion, a toxic material. WARNING environment. Before disposing of damaged or worn out Lithium-Ion battery packs, contact your local waste disposal agency, or the local Environmental Protection Agency for information and cadmium disposal.
  • Page 19 WARRANTY POLICY Batteries must be charged in accordance with the operator's manual directions and regulations in order to be valid. Warranty does not apply to defects due to direct or indirect abuse, negligence, misuse, accidents, repairs or alterations and lack of maintenance. Please keep your receipt/packing list as proof of purchase.
  • Page 20 EXPLODED VIEW CLHT2422 EXPLODED VIEW...

  • Page 21: Parts List

    PART LIST CLHT2422 PART LIST ITEM NO. PART NO. DESCRIPTION GH70DC.00.02.X1.01 Rear Handle Assembly TOTHYY.08.07 Spring GH80DC.00.01.X1.01 Front Handle Assembly TOTHYY.08.07 Spring GH85DC.30.10.X2.01 Motor Assembly With Blade GH85DC.30.12 Protective Top w/ Hang Hole GHB0DC.00.01.W3 PCB Board GH85DC.00.01 Blade Scabbard FO1211.12.00 24V Lithium Ion Battery Charger (24lSC01-ETL) FO2211.13.00...
  • Page 22 NOTES...
