OPERATION MANUAL
Serial Number
EK1240LX and EK1240CLX
GATOR
Battery-powered,
®
Crimping Tools
Read and understand all of the instructions and
safety information in this manual before operating
or servicing this tool.
Register this product at www.greenlee.com
52080016 REV 3
© 2019 Greenlee Tools, Inc.
6/19
Advertisement
Table of Contents
Related Manuals for Greenlee GATOR EK1240LX
Summary of Contents for Greenlee GATOR EK1240LX
- Page 1 EK1240LX and EK1240CLX GATOR Battery-powered, ® Crimping Tools Read and understand all of the instructions and safety information in this manual before operating or servicing this tool. Register this product at www.greenlee.com 52080016 REV 3 © 2019 Greenlee Tools, Inc. 6/19...
-
Page 2: Table Of Contents
All specifications are nominal and may change as design manual, may cause harmful interference to radio com- improvements occur. Greenlee Tools, Inc. shall not be liable for munications. Operation of this equipment in a residential damages resulting from misapplication or misuse of its products. -
Page 3: Important Safety Information
• Keep hands away from the crimp- ing tool head when crimping. Failure to observe these warnings could result in severe injury or death. Greenlee Tools, Inc. 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... - Page 4 Failure to observe these precautions may result in injury or property damage. Note: Keep all decals clean and legible, and replace when necessary. Greenlee Tools, Inc. 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070...
-
Page 5: Identification
Crimping Range ................ 8 AWG to 750 kcmil Battery Charger .............Read the instructions supplied with the battery charger Battery Technology .............. MAKITA Lithium ion ® ® BL1830, BL1840, BL1850 Greenlee Tools, Inc. 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... -
Page 6: Operation
Send tool in for service at end of cycle * Running the battery below 16 V can damage the battery. Greenlee Tools, Inc. 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... - Page 7 Failure to observe these warnings could result in severe injury or death. First Compression Crimping Direction SIDE B (evenly spaced) First Compression SIDE A First Compression SIDE B Crimping Direction SIDE A (evenly spaced) Greenlee Tools, Inc. 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070...
-
Page 8: Die Selection
YA-A ACL/ACN 60176; 400 to Aluminum VACL BLUA number provided with YA-ATN 2ACL/2ACN 60230 to 750 kcmil: Lugs the connector. ALNS/ALNN/ALND 60278 3 crimps Greenlee Tools, Inc. 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... -
Page 9: Lcd Screen
Tool deactivated Service necessary Real-time clock not found Bluetooth unit not found ® Pressure sensor not found Burst pressure exceeded Battery temperature too low Greenlee Tools, Inc. 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... -
Page 10: Maintenance
3. Inspect the rotation of the head assembly. Fully debris or hydraulic oil. retract the ram. The head should rotate no more than 360°. If damage is detected, contact Greenlee customer service at 800-435-0786 for warranty service or repair. After use: 1. -
Page 11: Troubleshooting
