- Page 1 Gas Built In Oven 70cm LP Gas Oven & Grill INSTALLATION AND USER INSTRUCTIONS Model: GG720LP (FSD) You must read these instructions prior to using the appliance and retain them for future reference.
- Page 2 If you smell gas: Do not try to light any appliance. Do not touch any electrical switch. 0800 111999 Call the Gas Emergency Helpline at TRANSCO on: In the Republic of Ireland, call the Bord Gaìs emergency line on 1850 205050 or contact your local gas supplier. The Gas Consumer Council (GCC) is an independent organisation which protects the interests of gas users.
-
Page 3: Table Of Contents
Technical Data ........33 Belling Customer Care........34 Please keep this handbook for future reference, or for anyone else who may use this appliance. -
Page 4: User Section
Introduction Thank you for choosing a Belling Gas & Electrical connection appliance Please refer to installation instructions hope that following for the Gas & Electrical Safety Regulations information will help you to familiarise and the Ventilation Requirements. yourself with the features of the... - Page 5 Introduction The cooling fan Continued use of the appliance without it being serviced could result in The cooling fan helps to keep the excessive temperatures being exterior cool during normal use. generated, which in turn could reduce When a burner is operated, you the life of certain components.
- Page 6 Introduction Glass door panels Environmental Protection To meet the relevant Standards of We are committed to protecting the Domestic cooking appliances, all the environment operate glass panels on this appliance are Environmental Management System toughened to meet the fragmentation which complies with BS EN ISO requirements of BS3193.
-
Page 7: Be Safe - Not Sorry
Be Safe - Not Sorry When you are cooking, keep l Use oven gloves when removing children away from the vicinity hot food / dishes from the oven or of the appliance. grill. The oven / grill and utensils will be very hot when in use. This product is designed as a domestic cooking appliance for the preparation l When opening the appliance... -
Page 8: Using The Grill
Using the Grill Caution: Accessible parts may Using the grill be hot when the grill is used, Push the grill pan towards the back of young children should be kept the shelf, to position it under the grill. away. Variation in grilling can be achieved by setting the grill between the large Grill ignition and small flame symbols, or by... - Page 9 Using the Grill Preheating For best results, always preheat the The handle should be removed from grill for a few minutes before grilling. the pan during grilling, to prevent overheating. The handle is designed for removing / Detachable grill pan handle inserting the grill pan under the grill grid when grilling.
-
Page 10: Using The Oven
Using the Oven When you are cooking, keep and dishes. children away from the vicinity of the oven. Preheating Oven ignition The oven must be preheated for 15 minutes when reheating frozen or Push in and turn the oven control knob chilled food, and we recommend anticlockwise to gas mark 9. -
Page 11: Oven Furniture
Cleaning Oven furniture Slow cooking l Make sure that frozen foods are thoroughly t h a w e d before cooking. Oven shelves l Do not slow cook joints of meat The oven shelf must be positioned with or poultry weighing more than the upstand at the rear of the oven and kg / 4 ⁄... -
Page 12: Cooking Frozen & Chilled Foods
Using the Oven Cooking frozen & chilled foods Baking guide - hints l Preheat the oven. Cooking times for pastry dishes depend on the size and type of l When cooking frozen or chilled foods, cooking dish and also the filling. please follow the manufacturer’s instructions. -
Page 13: Baking Guide
Using the Oven Baking guide Dish Recommended Shelf Approximate gas mark position cooking times Scones top to middle 8 - 15 mins Meringues “S” (slow setting) middle to bottom 2 - 3 hours Cakes Small cakes middle to top 15 - 25 mins Whisked sponge middle to top 20 - 25 mins... -
Page 14: Traditional Fruit Cakes
Using the Oven Traditional fruit cakes Roast turkey It should be remembered that ovens Roasting turkey perfectly involves can vary over time, therefore cooking cooking two different types of meat - times can vary, making it difficult to be the delicate light breast meat, which precise when baking fruit cakes. -
Page 15: Roasting Guide
Using the Oven Roasting guide Notes: The times given in the roasting guide l When cooking stuffed meat or are only approximate, because the poultry calculate the cooking time size and age of the bird will influence from the total weight of the meat cooking times as will the shape of a plus the stuffing. -
Page 16: Cleaning
Cleaning C a u t i o n : Any cleaning agent used incorrectly may damage the appliance. Always let the appliance cool before cleaning. Approx. Some cooking operations generate a 30˚ considerable amount of grease. This, combined with spillage, can become a hazard if allowed to accumulate on the appliance through lack of cleaning. - Page 17 Cleaning Vitreous enamel parts Stainless Steel surfaces (stainless steel finish models only) & GRILL PAN GRILL COMPARTMENT OVEN COMPARTMENT FLOOR FACIA PANEL HANDLES DOOR PANELS Use a mild cream cleaner - eg; “Cif”. Only use a clean cloth wrung out in hot soapy water, and dry with a soft cloth.
-
Page 18: Installation Instructions
Installation Instructions Before start: Please read 9. For installation in environments other instructions. Planning your installation will than domestic dwellings e.g. caravans and save you time and effort. boats, refer to the relevant standards for information on ventilation and gas supply. Prior to installation, ensure that the local Also for LP gas, refer to B.S 5482: Part 1,2 distribution conditions (nature of the gas and... - Page 19 Installation Instructions Failure to install appliances correctly is This appliance can be installed either at low level - ie; under a worktop, or at high dangerous and could lead to prosecution. level ie; into a tall kitchen cabinet unit. This appliance is not connected to a Please note that all dimensions and sizes combustion products evacuation device.
- Page 20 Installation Instructions Important In low level installations in caravan Warning: The gas dispersal hole holiday homes (other than domestic may be taken into consideration for installations boats,) calculating Low Level Ventilation dispersal hole (drop hole) should be requirements. However, under no provided underneath the appliance in circumstances should...
-
Page 21: Step 1: Prepare Installation
Installation Instructions Step 1: Prepare for installation The Fixing Kit There are 4 methods of installing If you require a replacement fixing kit the appliance: please call: Into a space between two Method 1: 0870 458 9961 and order part base units, ie;... - Page 22 Installation Instructions Method 1: Without housing unit (between 2 base units) Shown with fixing kit min 550mm 598 - 602mm 710mm sidetrim runners 50mm...
- Page 23 Installation Instructions Method 1: Without housing unit (between 2 base units) Shown without fixing kit min 550mm 598 - 602mm sidetrim...
- Page 24 Installation Instructions Method 2: Housing unit with internal To fix the runners (if required) height less than 710mm 1. Take the side trims, hold it against Note: You will not need the 2 side the side of the base unit, and use trims (687mm long) or the appliance it to mark off the 687mm from the runners for this installation.
- Page 25 Installation Instructions Method 2: Housing unit with internal height less than 710mm Shown with fixing kit min 550mm 560 - 570mm 710mm runners 50mm...
- Page 26 Installation Instructions Method 2: Housing unit with internal height less than 710mm Shown without fixing kit min 550mm 560 - 570mm...
- Page 27 Installation Instructions Method 3: Housing unit with internal Remove any fixings that may prevent height 710mm or more entry of the oven into housing, or obstruct the gas inlet pipe. Note: You will not need the 4 runners cabinetry should be kept structurally and 2 trims that are packed with the sound by fixing to adjacent cabinets, oven for this installation.
- Page 28 Installation Instructions Cut 12mm from the top of any plinth Method 4: Tall housing unit that may be fitted, or the equivalent in with internal height of 710mm slots or holes in the plinth below the or more oven. (See diagram.) Sitting the appliance.
- Page 29 Installation Instructions Dimensions. The appliance is designed to fit into a standard housing unit. with minimum internal dimensions as shown. Note: All sizes are nominal, some variation is to be expected. 560mm 547mm 550mm 703mm 706mm 595mm 550mm...
-
Page 30: Step 2: Connect To Gas Supply
Installation Instructions Step 2: Connect to gas supply This appliance can be installed using 3. Use a 900mm - 1125mm length of flexible rigid connections. flexible connector. The flexible Installation into leisure connector shall be fitted such that accommodation vehicles or other road it cannot come into contact with a vehicles must be made using a rigid moveable part of the housing unit... -
Page 31: Step 3: Connect To Electricity Supply
Installation Instructions Step 3: Connect to the electricity must be connected to the terminal supply marked L (Live), or coloured Red. Warning: This appliance must be plug socket must earthed. accessible after installation. The flexible mains lead is supplied Should mains lead connected to a BS 1363 fused plug,... -
Page 32: Step 5: Secure Appliance To Housing Unit
Installation Instructions Step 5: Secure appliance into Step 6: Installing a hob above housing unit the appliance When the appliance is installed under Note: The unit housing the appliance a worktop, with a hob installed above must be appropriately fixed. it, the installation instructions for the Method 1: Care must be taken to hob must be read in conjunction with... -
Page 33: Step 7: Commissioning
Installation Instructions Step 8: Commissioning Oven Pressure test point 1. Push in and turn the control knob Use the oven burner. From inside the anticlockwise to gas mark 9. The oven oven remove the burner cowl. Remove light will come on automatically. the small screw at the LHS of the 2. -
Page 34: Conversion Instructions
Conversion Instructions (LPG - Natural Gas) Before conversion, disconnect the 3. Thermostat & grill bypass screws gas and electrical supplies. 1. Remove the appliance facia panel. 2. Remove the appliance top/rear After conversion, check gas soundness. panel. The conversion procedure must be 3. - Page 35 Conversion Instructions (LPG - Natural Gas) 4. Grill injector. 1. Remove the appliance top/rear panel. 2. Remove the grill burner top cover. 3. Disconnect the gas supply pipe from the grill tap, and injector adaptor, and remove. 4. Unscrew and remove the screw which secures the grill burner cap c/w injector adaptor to the burner mixing tube.
-
Page 36: Technical Data
Technical Data Data badge Lower part of front frame Oven Bray type burner, sheet steel body, Pressure setting stainless steel flame strip G20 Natural Gas @ 20 mbar (8”wg) Spark gap 3 - 4mm G30 Butane @ 28-30 mbar(11.2” wg) G31 Propane @ 37mbar ( 14.8”... -
Page 37: Belling Customer Care
Belling Customer Care In case of difficulty within the UK and Northern Ireland, please call the Belling Customer Care Helpline on 0871 22 22 503 When you dial this number you will hear a recorded message and be given a number of options. - Page 40 Stoney Lane, Prescot, Merseyside L35 2XW 08 27353 00 © 06.2007...
