Connector 6 - MIC (Lemo 4 PIN)
PIN
1
2
3
4
https://en.racelogic.support//Product_Info/Video_Data_Loggers/VBOX_Video_HD2/VBOX_Video_HD2_User_Guide/10_-
I/O
I
O
O
I
Function
Microphone - left channel
Ground
Ground
Microphone - right channel
_HD2_Technical_Properties/VBOX_Video_HD2_-_PIN_OUTS
