VBOX VIDEO HD2 Mounting
Bracket Assembly Guide

Assembly Guidelines

1. Attach the upper harness bar brackets to the mount base using the four black counter sunk
screws provided and tighten using the 3/32" hex key.
2. Place the VIDEO VBOX HD2 on the mount
base and secure by attaching the upper half
of the mount using the six button head
screws and the 3mm hex key.
3. Ensure the VIDEO VBOX HD2 is straight
and mounted securely.
(ACS268-ASSEM)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VBOX VIDEO HD2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Racelogic VBOX VIDEO HD2

Summary of Contents for Racelogic VBOX VIDEO HD2

  • Page 1 VBOX VIDEO HD2 Mounting Bracket Assembly Guide (ACS268-ASSEM) Assembly Guidelines 1. Attach the upper harness bar brackets to the mount base using the four black counter sunk screws provided and tighten using the 3/32” hex key. 2. Place the VIDEO VBOX HD2 on the mount...
  • Page 2 VBOX VIDEO HD2 Mounting Bracket Assembly Guide (ACS268-ASSEM) 4. Place the upper harness bar brackets on the desired vehicle roll cage location and secure using the lower harness bar brackets and the four cap head screws provided. Tighten using the 9/64”...
