Connector 2 / 3 - Camera Inputs (Lemo 9 PIN)
PIN
1
2
3
4
5
6
7
8
9
https://en.racelogic.support//Product_Info/Video_Data_Loggers/VBOX_Video_HD2/VBOX_Video_HD2_User_Guide/10_-
I/O
I
I
I
O
O
O
I
I
O
Function
Ground
Data
Data
Ground
Camera Power (4V)
Chassis
Data
Data
Camera Power (4V)
_HD2_Technical_Properties/VBOX_Video_HD2_-_PIN_OUTS
94
