Racelogic VBOX Video HD2 User Manual page 73

Save to SD
The
button allows you to save a scene file to an SD card or USB stick, which can then be uploaded to the VBOX Video HD2.
IMPORTANT – Scenes cannot be named as 'default'.
Note: If a scene is saved and a file with the same name exists on the card/stick, the original will automatically have the
file type suffix changed from '.vvhsn' to '.bak' and the new one will be saved as normal. To open the old one, manually
change the file type suffix back to '.vvhsn' and it will work as normal.
Uploading a scene
Once a scene file has been saved to the SD card or USB stick using the 'Save to SD' button:
• Power up the VBOX Video HD2 unit with cameras connected.
• Load the SD card or USB stick into the front panel - the OK LED will flash
• The HD2 will double beep when the upgrade is complete - the OK LED will change to solid green.
Top panel buttons
These buttons are used to load scene files, view CAN and OBD settings, access the library of elements as well as set
up lap timing.
https://en.racelogic.support//Product_Info/Video_Data_Loggers/VBOX_Video_HD2/VBOX_Video_HD2_User_Guide/09_-
green fast as the scene is loaded.
_HD2_Setup_Software_Overview_-_macOS
73
