Roll Mode (Optional) - Racelogic VBOX 3i Manual

6. Once the 'OK' confirmation screen has cleared, 'Enabled' will be displayed.
7. Scroll to 'Antenna Separation' and select. Enter the distances measured between Antenna A and Antenna B by
pressing the scroll wheel to move along the digits and rotating to the desired number, selecting past the final digit
will store the value. More information on this can be found here.
8. Driving forward should now show a

Roll Mode (optional)

If you intend to test roll and pitch measurements rather than slip and pitch, follow the steps below. More information on
this can be found here.
1. Navigate back to the 'Dual Antenna' menu.
2. Scroll to the 'Antenna Orientation' menu and select.
green 'DUAL' LED.
https://en.racelogic.support//Product_Info/ADAS_Applications/ADAS_Knowledge_Base/General_Information/
ADAS_Dual_Antenna_Configuration
2
