Summary of Contents for AccuEnergy Acuvim II Series

  • Page 3 Accuenergy. The information contained in this document is believed to be accurate at the time of publication, however, Accuenergy assumes no responsibility for any errors which may appear here and reserves the right to make changes without notice.
  • Page 4 Installation and maintenance of the Acuvim II meter should only be performed by qualified, competent personnel that have appropriate training and experience with high voltage and current device. This document is not fit for people without adequate experience and training. Accuenergy is not liable for any problems occurring under proper operation.

  • Page 5: Table Of Contents

    Content Chapter 1 Introduction-------------------------------------------------------------------1 1.1 The Purpose of Acuvim II--------------------------------------------------2 1.2 The Application Area of Acuvim II---------------------------------------3 1.3 The Function of Acuvim II-------------------------------------------------3 Chapter 2 Installation-------------------------------------------------------------------5 2.1 Appearance and Dimensions--------------------------------------------8 2.2 Installation Method------------------------------------------------------9 2.3 Wiring of Acuvim II-------------------------------------------------------11 Chapter 3 Meter Operation and Parameter Setting---------------------------------27 3.1 Display Panel and Keys---------------------------------------------------28 3.2 Metering Data-------------------------------------------------------------31 3.3 Statistics Data-------------------------------------------------------------34...
  • Page 6 5.1 Introducing Modbus Protocol--------------------------------------------74 5.2 Format of Communication----------------------------------------------77 5.3 Data Address Table and Application Details of Acuvim II-----------82 Appendix--------------------------------------------------------------------------------107 Appendix A Technical data and specifications--------------------------------------108 Appendix B Ordering Information----------------------------------------------------111 Appendix C Revision History----------------------------------------------------------112...
  • Page 7 Starting! Congratulations! You have received an advanced, versatile, multifunction power meter, also known as a Remote terminal unit (RTU), which will greatly benefit your power system. When you open the package, you will find the following items 1. Acuvim II meter 2.

  • Page 9: Chapter 1 Introduction

    Chapter 1 Introduction The Purpose of Acuvim II The Application Area of Acuvim II The Functions of Acuvim II...

  • Page 10: The Purpose Of Acuvim

    1.1 The Purpose of Acuvim II Powerful Multifunction Power Meter Acuvim II Multifunction digital power meter is designed using modern MCU and DSP technology. It integrates three-phase energy measuring and displaying, energy accumulating, power quality analysis, malfunction alarming and network communication. Large and vivid LCD meets your visual requirement greatly.

  • Page 11: The Application Area Of Acuvim

    Power Quality Analysis With the help of powerful digital signal processing technology, the Acuvim II intelligent power meter can be used as an online power quality analysis instrument. It can simultaneously and continuously give out the analysis results such as THD of voltage and current, harmonics up to 31st order and unbalance factor of voltage and current, etc.
  • Page 12 Easy to Use With a large high density LCD screen, the display of the Acuvim II is easy to read and use. All the measuring data and setting parameters can be accessed by using panel keys or a communication port. The setting parameters are protected in EEPROM, which will maintain its content after the meter is powered off.

  • Page 13: Chapter 2 Installation

    Chapter 2 Installation Appearance and Dimensions Installation Method Wiring of Acuvim II...
  • Page 14 Do not HIPOT/Dielectric test any Outputs, Inputs or Communications terminals. ACCUENERGY recommends the use of Shorting Blocks and Fuses for voltage leads and power supply to prevent hazardous voltage conditions or damage to CTs, if the meter needs to be removed from service. CT ground- ing is optional.
  • Page 15 NOTE: IF THE EQUIPMENT IS USED IN A MANNER NOT SPECIFIED BY THE MANUFACTURER, THE PROTECTION PROVIDED BY THE EQUIPMENT MAY BE IMPAIRED. NOTE: THERE IS NO REQUIRED PREVENTIVE MAINTENANCE OR INSPECTION NECESSARY FOR SAFETY. HOWEVER, ANY REPAIR OR MAINTENANCE SHOULD BE PERFORMED BY THE FACTORY. DISCONNECT DEVICE: The following part is considered the equipment disconnect device.

  • Page 16: Appearance And Dimensions

    The installation method is introduced in this chapter. Please read this chapter carefully before beginning installation work. 2.1 Appearance and Dimensions Appearance ⑤ ① ② ③ ⑧ ⑦ ④ ⑨ ⑥ Fig 2.1 Appearance of Acuvim II Part Name Description The Acuvim II enclosures are made of high strength anti- 1.

  • Page 17: Installation Method

    Dimensions (mm) Front view Side view Fig 2.2 Dimensions 2.2 Installation Method Environmental Before installation, please check the environment temperature and humidity to ensure the Acuvim II meter is being placed where optimum performance will occur. Temperature Operation: -25℃ to 70℃. Storage: -40℃...
  • Page 18 Installation Steps Acuvim II can be installed using a standard ANSI C39.1 (4” Round) or an IEC 92mm DIN (Square) form. 1. Firstly, cut a square hole or round hole on the panel of the switch gear. The cutting size is shown in fig 2.3. The Unit is mm. Fig 2.3 Panel Cutting 2.

  • Page 19: Wiring Of Acuvim

    3. Finally, put clips back to the meter from the backside and push the clip tightly so that the meter is fixed on the panel. Fig 2.5 Use the clips to fix the meter on the panel 2.3 Wiring of Acuvim II Terminal Strips There are four terminal strips on the back of Acuvim II.
  • Page 20 Current Input Terminal Strip Voltage Input Terminal Strip Power Supply Terminal strip L / + N / – P ow er S upply Communication terminal strip C om m P ort Fig 2-6. Terminal Strips of Acuvim II...
  • Page 21 Safety Earth Connection DANEROUS Before doing the meter wiring connection, please Only the qualified personnel could do make sure that the switch gear has a safety Earth the wire connection system. Connect the meter safety earth terminal work. Make sure to the switch gear safety earth system.
  • Page 22 1 A F U SE Pow er Supply Acuvim II G r ound Fig 2-8 Power supply A fuse (typical 1A/250Vac) should be used in auxiliary power supply loop. No. 13 terminal must be connected to the safety earth system of switchgear.
  • Page 23 primary rated voltage of PT is equal to or close to the phase voltage of the system. For the delta system, it is the line voltage of the system. A fuse (typical 1A/250Vac) should be used in voltage input loop. The wire of voltage input could be AWG16-12 or 1.3-2.0mm Note: In no circumstance could the secondary of PT be shorted.
  • Page 24 Please read this part carefully before you begin to do the wiring so that you can choose a suitable wiring method for your power system. The voltage and current input wiring mode can be set separately in the meter parameter setting process. The voltage wiring mode could be 3-phase 4-line Wye (3LN), 3-phase 4-line 2PT Wye mode (2LN) and 3-phase 3-line open delta (2LL).
  • Page 25 LIN E 1A F U SE Acuvim II LOAD Fig 2.10b 3LN with 3PT 3-Phase 4-Line 2PT mode (2LN) In some 3-Phase 4-Line Wye system, 2PT Wye mode is often used as in fig2.11, where the 3 phases of power system is supposed to be balanced. The voltage of V2 is calculated according to the V1 and V3.
  • Page 26 3-Phase 3-Line direct connection mode (3LL) In a 3-Phase 3-Line system, power line A, B and C are connected to V1, V2 and V3 directly. Vn is floated. The voltage input mode of the Acuvim II should be set 3LL. LIN E 1 A F U SE Acuvim II...
  • Page 27 Current Input Wiring All the current input of three phase system can be looked as 3CT one, whether there are 2 CTs or 3 CTs in the input side. The current input mode of the Acuvim II should be set 3CT for this current input wiring mode.
  • Page 28 The difference of the fig 2.16 and the fig.2.15 is that there is no current input in the I21 and I22 terminals. The I2 value is calculated from formula i1+i2+i3=0. The current input mode of the Acuvim II should be set 2CT for this current input wiring mode.
  • Page 29 Frequently used wiring method The voltage and current wiring method are put together in one drawing. The Acuvim II meter will display normally only that the setting of the meter is assorted with the wiring of the voltage and current input. 1.
  • Page 30 3. 2LN, 2CT LIN E 1A F U SE T erm inal block Acuvim II LOAD Fig 2.20 2LN, 2CT 4. 2LN, 1CT LIN E 1A F U SE T erm inal block I 12 I 21 Acuvim II I 22 I 31 I 32 LOAD...
  • Page 31 5. 2LL, 3CT LIN E 1A F U SE T erm inal block Acuvim II LOAD Fig 2.22 2LL, 3CT 6. 2LL, 2CT LIN E 1A F U SE T erm inal block Acuvim II LOAD Fig 2.23 2LL, 2CT...
  • Page 32 7. 2LL, 1CT LIN E 1A F U SE T erm inal block Acuvim II LOAD Fig 2.24 2LL, 1CT 8. Single Phase 2 Line (Wiring mode setting 3LN, 3CT) LIN E 1A F U SE T erm inal block Acuvim II LOAD Fig 2.25 Single phase 2Lines...
  • Page 33 9. Single Phase 3 Line (Wiring mode setting 3LN, 3CT) LIN E 1A F U SE T erm inal block Acuvim II LOAD Fig 2.26 Single phase 3Lines Communication The communication port and protocol of Acuvim II are RS485 and Modbus- RTU.
  • Page 34 The shield of each segment of the RS485 cable must be connected to the ground at one end only. Every A(+) should be connected to A(+), B(-) to B(-), or it will influence the network, or even damage the communication interface. The connection topology should avoid “T”...

  • Page 35: Chapter 3 Meter Operation And Parameter Setting

    Chapter 3 Meter Operation and Parameter Setting Display Panel and Keys Metering Data Statistics Data Demand Data Harmonic Data Expanded I/O Module Data Parameters Setting...

  • Page 36: Display Panel And Keys

    Detailed human-machine interface of the meter will be described in this chapter, including how to get the metering data and how to do the parameter setting. 3.1 Display Panel and Keys There are one display panel and four keys in the front of Acuvim II. All the display segments are illustrated in fig 3.1.
  • Page 37 Main Display Area: display metering data such as voltage, current, power, power factor, frequency, imbalance, phase angle, etc; display statistics Four lines of “ ” letters in the metering area such as maximum and minimum; display demand data; display settings and display expanded I/O data.
  • Page 38 voltage: V，kV; current: A，kA；active power: kW, MW; reactive power: kvar, Mvar; apparent Unit power: kVA, MVA; frequency: Hz; active energy: kWh; reactive energy: kVarh; apparent energy: kVAh; percentage: %; phase angle: ° No label: no communication Communication label One label: inquiry Two labels: inquiry and answer Energy pulse output indicator No label: no pulse output With label: pulse output...

  • Page 39: Metering Data

    3.2 Metering Data Press H and V/A simultaneously will activate the display mode selection and the cursor will flash. Press P or E to move the cursor right or left to “Meter”, then press V/A, and you will enter the metering mode. In the metering mode, meter displays measurements such as voltage, current, power, power factor, phase angle, imbalance, etc.
  • Page 40 b) Power, Power Factor and Frequency: Press P, display power related data. The screen will roll to the next page as you press P each time. It will go back to the first screen if you press P at the last screen. The following figure shows how it rolls: T hree phase pow er T hree phase...
  • Page 41 if you press H at the last screen. The following figure shows how it rolls: U nbalance factor Voltage phase angle C urrent phase angle Note: Voltage stands for line-to-line voltage when the wiring setting is “2LL” or “3LL” and for line-to-neutral voltage when other wiring settings. d) Energy: Press E key, display energy and real time clock.

  • Page 42: Statistics Data

    C onsum ption ener gy M eter r unning tim e T im e F or m at: G ener ation ener gy hh :m m :ss D ate F or m at : T otal ener gy m m: dd: yyyy T otal electr ical N et ener gy degr ee...
  • Page 43 Press P, screen will roll to the next page, and will roll back to the first screen when pressed at the last page. Press E, screen will roll back to the last page, and will roll back to the last screen when pressed at the first page. V/A is used for switch the display between maximum and minimum.

  • Page 44: Demand Data

    ii) When meter is set to “2LL” or “3LL”, the first screen will not be displayed. 3.4 Demand Data Press H and V/A simultaneously will activate the display mode selection and the cursor will flash. Press P or E to move the cursor right or left to “Demand”, then press V/A, and you will enter the demand data mode.
  • Page 45 a) Power Quality Data: Press H, display power quality data. It rolls to the next page when press H each time and roll back to the first page when press H at the last page. Press P, no function. Press E, no function. Press V/A, switch to the display of harmonic ratio data.

  • Page 46: Expanded I/O Module Data

    The harmonic order will minus by one when press E each time and will back to 31 when press E at the 2nd harmonics. Press V/A, switch display between voltage harmonics and current harmonics. The following figure shows how it rolls: V /A T he 2nd har m onic T he 2nd har m onic...
  • Page 47 In the expanded I/O module data mode, meter displays the data from expanded I/O modules, such as DI status, pulse counter number, Relay status, Analog Output, and Analog Input, etc. In the expanded I/O module data mode, first page is the module selection and you can choose any module as you wish.
  • Page 48 As shown in the figure, three modules are connected, AXM-IO11, AXM- IO21, AXM-IO31, which are indicated by M11, M21, M31 respectively. The cursor points to M21, which indicates that AXM-IO21 is chosen now. b) I/O Module Data Selection Press H, back to module selection mode. Press P, move the cursor downwards.
  • Page 49 V/ A M 11 (M 12 ) : D I1 -3 M 11 (M 12 ) : D I4 -6 M11 ( M12 ) : D I M 11 /M 12 V/ A IO : M 11 or M 12 M11 ( M12 ) : R O M 11 ( M12 ) : R O 1 、R O 2 V/ A...

  • Page 50: Parameter Setting Mode

    V /A M 3 1(M 3 2) ：D I M 3 1(M 3 2): D I1-4 M o d u le: M 3 1/M 3 2 V /A V /A IO: M 3 1 o r M 3 2 M 3 1( M 3 2)：R O M 3 1(M 3 2): R O 1 、R O 2 V /A M 3 1(M 3 2): p u lse...
  • Page 51 Entering the parameter setting mode, firstly, the device address will appear for several seconds and then go to the password inquiry page. “Password” is the key to the parameter setting mode and only valid password will help you to go through and use the meter setting. This function helps to prevent the mis-operation and unauthorized people to modify the meter parameters.
  • Page 52 Press H, no function. Press P, move the cursor downwards. When the cursor is at the bottom, press P will move the cursor to the top. Press E, move the cursor upwards. When the cursor is at the top, press E will move the cursor to the bottom.
  • Page 53 The screen will roll to the next page each time when press P and will roll back to the first page when press P at the last page. The screen will roll to the last page each time when press E and will roll back to the last page when press E at the first page.
  • Page 54 SYS setting A ny integer from 1~247 S01 : M eter addr ess S elect form 600,1200, 2400,4800,9600, 19200,38400 S02 : Baud r ate V oltage wiring mode can be one of “ 3LN”, “2LN”, S 03: Voltage w ir ing “2LL”, “3LL”...
  • Page 55 To cle ar the Ma x a nd Min va lu e do es n ot me a n write 0 to a ll th e re g iste rs, it will cop y the metering valu e to the sta tistic re giste rs S 15 ：m ax/m in clear a nd start a ne w sta tistic p eriod .
  • Page 56 Note: The figure shows the rolling sequence for using key P. If using E key for rolling page, the sequence will reverse. d) Expanded I/O Module Parameter In the expanded I/O module parameter mode, firstly choose the module to be modified and then make the modification. If no expanded I/O module is connected, it will display “NO IO”.
  • Page 57 Key functions for modifying the parameter: Press H, move the flashing cursor to the next position. Press P, the flashing number will add one. Press E, the flashing number will minus one. Press V/A, confirm the modification and back to parameter finding mode. The following table shows how it rolls: DI of AXM-IO1 can be used as the pulse counter, each DI function M odule M 11 /M 12...
  • Page 58 M odule M 21 /M 22 DI of AXM-IO2 can be used as the pulse counter, each DI function IO ：M 21 /M 22 m odule is correspond to one bit of a 4-bit register. The correspondence bit of 0 means that the DI works as the digital status input and the correspondence bit of 1 means that the DI works as the pulse M 21 (M 22 )：pulse counter.
  • Page 59 M odule M 31 / M32 DI of AXM-IO3 can be used as the pulse counter, each DI function IO ：M31 / M32 m odule is correspond to one bit of a 4-bit register. The correspondence bit of 0 means that the DI works as the digital status input and V /A the correspondence bit of 1 means that the DI works as the pulse M 31 ( M32 ) ：pulse...
  • Page 60 e) Ethernet Module Parameter In the Ethernet module parameter mode, firstly find the parameter and then modify. If Ethernet module is not connected, all the settings will have no effect. Key functions for finding the Ethernet module parameter: Press H, back to parameter selection mode. The screen will roll to the next page each time when press P and will roll back to the first page when press P at the last page.
  • Page 61 Ether net setting V /A The selection of DHCP setting: MANU or AUTO N01 : D H C P setting Default setting: MANU IP address have four segments. Any segment can be set from N 02 : IP Addr ess 0~255.
  • Page 62 f) Alarm Parameter In the alarm parameter mode, firstly find the parameter and then modify. Key functions for finding the alarm parameter: Press H, back to parameter selection mode. The screen will roll to the next page each time when press P and will roll back to the first page when press P at the last page.
  • Page 63 Alar m ing setting Yes: alarming is available; No: means not. A01 ：Alar m ing It can be selected as cue signal for alarming. enable Yes: the backlight will flashes; No: means not. A02 : Backlight flashing There are 16 records in all and each one is corresponding to one bit of a 16-bit register.

  • Page 64: Page Recovery Function

    3.8 Page recovery Function Acuvim II has the page recovery function, which means that the meter stores the current display page in the non-volatile memory during power off and reloads the page when power recovers. If power goes off when displaying at the parameter setting mode, the meter will start with page of voltage display when power recovers.

  • Page 65: Chapter 4 Function And Software

    Chapter 4 Function and Software Basic Analog Measurements Max/Min Harmonics and power quality analysis Over-Range alarming...

  • Page 66: Basic Analog Measurements

    The function of Acuvim II is very powerful. It can measure almost all the parameters in the power system. Some of its function may not be controlled by simply pressing the keys, so we made this software to go with it. To express clearly, we’ll introduce functions with the help of the software interface in this chapter.
  • Page 67 Demand: Types of demand calculated in Acuvim II are: active power demand of three phase, reactive power demand of three phases, and apparent power demand of three phases. Demand memory can be cleared. To clear is to reset all the registers to 0, like the initial of the meter (demand calculation only).
  • Page 68 fundamental wave. 2. There are two ways to calculate reactive energy(power) Mode 0: real reactive energy − − Mode 1: general reactive energy − 3. User can choose primary energy or secondary energy by pressing key or via communication as shown in figure 4-7. Figure 4-2 energy and power quality parameters Current direction adjustment The normal current direction is from port 1 to port 2, but sometimes...

  • Page 69: Max/Min

    we may make wrong wiring. To adjust direction of current, the three current directions can be set as “Negative” which means reversing 180 degrees and “Positive” which means normal. It is easy to get the right data without changing the wiring. It is also shown in figure 4-7. 4.2 Max/Min Figure 4-3 Max/Min Acuvim II can make statistics of the maximum and minimum values of...

  • Page 70: Harmonics And Power Quality Analysis

    that they will not lose when the power supply is off. All of the maximum and minimum data can be accessed via communication or panel, but the time stamps can only be accessed via communication. The statics can be cleared via communication or panel. 4.3 Harmonics and Power Quality Analysis 1.

  • Page 71: Over-Range Alarming

    Figure 4-4 Sequence component and Phase angle 4.4 Over-Range Alarming In Acuvim II, when the metering data is over the pre-setting limit and over pre-setting time interval, the over limit alarming will be picked up. The over limit value and time stamp will be recorded and the maximum number of records is 16.
  • Page 72 registers via communication as shown in figure 4-5. Figure 4-5 Alarm Setting 1. Single alarming group setting Table 4-1 indicates the first group of settings, there are 16 groups in all with the same format. Address Parameter Range Property 104eH First group: parameter code 0~47 104fH...
  • Page 73 Parameter code: used to select a parameter for this group. For example: 0-frequency, 44-AI4 sampling data. Then this parameter will be monitored. Comparison mode: set alarming condition 1: larger, 2: equal, 3: smaller. For example: if you choose frequency, larger, and setting value is 50, then it will alarm when the frequency is larger than 50Hz.
  • Page 74 When “Alarming flash enable“ is set to be “1”, the backlight will flash when alarm happens. “Alarming channel enable setting” determines whether the corresponding group is enabled or not. There are 16 groups in all and each one is corresponding to one bit of a 16-bit register. For each group, whether it works or not depends on the enable setting.
  • Page 75 DO2~DO4 are the same as DO1. After finishing the previous steps correctly, the alarming function is available. 3. Setting Example We’ll show you an example of how to use the logical “and” in a pair. We set an event as follow: I1 greater than 180A, delay 5s for the 1st group;...
  • Page 76 1000*10ms=10s. “Output to relay (1057H)” is set to 0, because there is no output to RO. Global settings: “Alarming channel enable setting (1048H)” is set as 0x0003, which enables the first and the second channel. “Logical "AND" between alarming setting (1049H)” is set as 0x0001, which enable logic "AND"...
  • Page 77 Here is the 1st group of record. Other groups of records have the same format. Address Parameter Range 42a9H First group: alarming status 0~65535 42aaH First group: parameter code 0~47 42abH First group: over range or reset value Related with parameters First group: 42acH~42b2H time...
  • Page 78 Fig 4-6 Alarming records...
  • Page 79 Figure 4-7 basic settings...

  • Page 80: Extended I/O Module

    4.5 Extended I/O Module Please refer to <<User’s manual of Extended I/O Modules>>. 4.6 Extended Communication Block Please refer to <<User’s manual of Ethernet Module>>and <<Use’s manual of Profibus Module>>.

  • Page 81: Chapter 5 Function And Software

    Chapter 5 Function and Software Introducing Modbus Protocol Format of the communication Data Address Table and Application Details of Acuvim II...

  • Page 82: Introducing Modbus Protocol

    This chapter will mainly discuss how to handle the meter via the communication port using software. To master this chapter, you should be familiar with Modbus and have read other chapters of this manual, and you have generously mastered the function and application of this product.
  • Page 83 Address Field The address field of a message frame contains eight bits. Valid slave device addresses are in the range of 0~247 decimal. A master addresses a slave by placing the slave address in the address field of the message. When the slave sends its response, it places its own address in this address field of the response to let the master know which slave is responding.
  • Page 84 items to be handled, and the count of actual data bytes in the field. For example, if the master requests a slave to read a group of holding registers (function code 03), the data field specifies the starting register and how many registers are to be read. If the master writes to a group of registers in the slave (function code 10 hexadecimal), the data field specifies the starting register, how many registers to write, the count of data bytes to follow in the data field, and the data to be written into the...

  • Page 85: Format Of Communication

    not apply to the CRC. During generation of the CRC, each 8-bit character is exclusive ORed with the register contents. Then the result is shifted in the direction of the least significant bit (LSB), with a zero filled into the most significant bit (MSB) position.
  • Page 86 1. Read Status of Relay Function Code 01 This function code is used to read status of relay in Acuvim II. 1=On 0=Off Relay1’s address is 0x0000, Relay2’s address is 0x0001, and so on. The following query is to read relay status of Acuvim II with the address of 17.
  • Page 87 2. Read the Status of DI Function Code 02 1=On 0=Off DI1’s address is 0x0000, DI2’s address is 0x0001, and so on. The following query is to read the Status of 4 DIs of Acuvim II with the address of 17. Query DI start DI start...
  • Page 88 3. Read Data (Function Code 03) Query This function allows the master to obtain the measurement results of Acuvim II. Table5.8 is an example to read the 3 measured data (F, V1 and V2) from slave device number 17, the data address of F is 4000H, 4001H; V1's address is 4002H, 4003, and V2's address is 4004H, 4005H.
  • Page 89 data value FF00H will set the relay on and the value 0000H will turn it off; all other values are illegal and will not affect that relay. The example below is a request to the Acuvim II with the address of 17 to turn on Relay1.

  • Page 90: Data Address Table And Application Details Of Acuvim

    Response The normal response to a preset Multi-Register request includes the Acuvim II address, function code, data start register, the number of registers, and error checking. Data start Data start Data #of Data #of CRC16 CRC16 Addr reg hi reg lo reg hi Reg lo Table5.13 Preset Multi-Register Response Message...
  • Page 91 Parameters Relationship Unit Format code Numerical value equals to System parameters No unit communication value Run time T=Rx/100 Hour Numerical value equals to Clock Unit of time communication value Energy(primary) Ep=Rx/10 Reactive energy(primary) Eq=Rx/10 kvarh Apparent energy(primary) Es=Rx/10 Energy(secondary) Ep=Rx/1000 Reactive energy (secondary) Eq=Rx/1000 Kvarh Apparent energy...
  • Page 92 1. Using function code 10H, one communication order can only modify contents in one region, such as “System parameters settings”, ”System status parameter”, “Date and Time table”, “Over-range alarming-Global settings”, “Over-range alarming-Single settings”, “I/O Modules settings”. It can not be accomplished in one communication order to modify contents in both of two or more regions above.
  • Page 93 1:sliding window 100eH Demand calculating mode word 2:thermal 100fH Clear demand memory Only 1 works word 1010H Max/Min clear 0x55 Only 0x0A works word 1011H Run time clear Only 1 works word 0: Positive 1012H Current I1 direction word 1: Negative 0: Positive 1013H Current I2 direction word...
  • Page 94 Flags should be cleared after being read by the controller, otherwise new data will not be stored properly. Function code: 03H for reading, 10H for writing. Data type: word. Format Data Address Parameter Range Property code type Recording pointer 101eH~102dH 1: new data word bj_st0-15...
  • Page 95 1041H Month 1~12 word 1042H 1~31 word 1043H Hour 0~23 word 1044H minute 0~59 word 1045H second 0~59 word Over-range alarming setting This setting consists of global settings and single settings. The global settings contain settings of all global variables. There are 16 groups of records with the same format.
  • Page 96 A l a r m i n g o u t p u t t o D O 2 0~65535 104bH word setting The same as previous A l a r m i n g o u t p u t t o D O 3 0~65535 104cH word...
  • Page 97 Power of phase Power of phase C Power of all Reactive power Reactive power Reactive power of of phase A of phase B phase C Reactive power Apparent power Apparent power of of all of phase A phase B Apparent power Apparent power PF of A of phase C...
  • Page 98 AXM-IO11 Address Parameter Default Range Data type Property Bit0: DI1, Bit1: DI2 Bit2: DI3, Bit3: DI4 109eH DI1~6 type word Bit4: DI5, Bit5: DI6 0: DI,1: pulse counter 109fH DI pulse constant 1~65535 word Working mode of relay 0: control output, 10a0H word 1 and 2...
  • Page 99 AXM-IO31 Address Parameter Default Range Data type Property Bit0: DI11,Bit1: DI12, 10aaH DI11~14 type Bit2: DI13, Bit3: DI14 word 0: DI, 1: pulse counter 10abH DI pulse constant 1~65535 word Wo r k i n g m o d e o f 0: control output, 10acH word...
  • Page 100 Wo r k i n g m o d e o f 0: pulse output, 10b7H word DO3,4 1: alarming output 10b8H DO Pulse width 20~1000ms word 0: none 1: consumption power 2: gererating power 10b9H DO3 output 3: absorption reactive word power 4: generating reactive...
  • Page 101 AO2 transforming 10c3H Refer to following table word parameter AO3 transforming 10c4H Refer to following table word parameter AO4 transforming 10c5H Refer to following table word parameter AO transforming parameter settings Setting Ttransforming Setting Transforming Setting Transforming value object value object value object...
  • Page 102 and the real physical value is as following table. (Rx is the numerical value in register of Acuvim II) Function code: 03H for reading. Data Address Parameter Code Relationship Property type 4000H~4001H Frequency F = Rx float 4002H~4003H Phase voltage V1 U=Rx×(PT1/PT2) float 4004H~4005H Phase voltage V2...
  • Page 103 Phase A Apparent 402cH~402dH S=Rx×(PT1/PT2)×(CT1/CT2) float power Sa Phase B Apparent 402eH~402fH S=Rx×(PT1/PT2)×(CT1/CT2) float power Sb Phase C Apparent 4030H~4031H S=Rx×(PT1/PT2)×(CT1/CT2) float power Sc System Apparent 4032H~4033H S=Rx×(PT1/PT2)×(CT1/CT2) float power Ssum Phase A power factor 4034H~4035H PF = Rx float Phase B power factor 4036H~4037H PF = Rx...
  • Page 104 Address Parameter Code Range Data type Property 4048H~4049H Energy IMP F4/F7 0~999999999 dword 404aH~404bH Energy EXP F4/F7 0~999999999 dword 404cH~404dH Reactive energy IMP F5/F8 0~999999999 dword 404eH~404fH Reactive energy EXP F5/F8 0~999999999 dword 4050H~4051H Energy TOTAL F4/F7 0~999999999 dword 4052H~4053H Energy NET F4/F7 0~999999999...
  • Page 105 4083H THFF of V1(V12) 0~10000 word 4084H~40a5H Parameters of V2(V31) Same as V1 word 40a6H~40c7H Parameters of V3(V23) Same as V1 word Current Harmonics, even HD, odd HD, Crest Factor are shown as below Harmonics of I1 (the 2 40c8H~40e5H 0~10000 word to 31...
  • Page 106 4160H MAX of I1 -32768~32767 Time stamp: yyyy:mm: 4161H~4166H time dd:hh:mm:ss 4167H MAX of I2 -32768~32767 Time stamp: yyyy:mm: 4168H~416dH time dd:hh:mm:ss 416eH MAX of I3 -32768~32767 Time stamp: yyyy:mm: 416fH~4174H time dd:hh:mm:ss 4175H MAX of system power -32768~32767 Time stamp: yyyy:mm: 4176H~417bH time dd:hh:mm:ss...
  • Page 107 Time stamp: yyyy:mm: 41a7H~41acH time dd:hh:mm:ss M A X o f v o l t a g e 41adH -32768~32767 unbalance factor Time stamp: yyyy:mm: 41aeH~41b3H time dd:hh:mm:ss M A X o f c u r r e n t 41b4H -32768~32767 unbalance factor...
  • Page 108 Data Address Parameter code Range property type 4294H positive sequence real part of UA -~ 4295H positive sequence complex part of UA -~ 4296H negative sequence real part of UA -~ 4297H negative sequence complex part of UA F11 -~ 4298H zero sequence real part of UA -~...
  • Page 109 Data Address Parameter code Range property type First group: alarming 42a9H 0~65535 word status First group: alarming 42aaH 0~47 word parameter code First group: over range or Related with 42abH F10~F18 word reset value parameters First group: Time stamp: 42acH~42b2H word yyyy:mm:dd:hh:mm:ss:ms 42b3H~42bcH Second group...
  • Page 110 Address Parameter code Range Data type property AXM-IO11 4349H~434aH DI1 pulse counter number 0~4294967295 dword 434bH~434cH DI2 pulse counter number 0~4294967295 dword 434dH~434eH DI3 pulse counter number 0~4294967295 dword 434fH~4350H DI4 pulse counter number 0~4294967295 dword 4351H~4352H DI5 pulse counter number 0~4294967295 dword 4353H~4354H DI6 pulse counter number...
  • Page 111 AI input value The output of AI is mapped to the range of 0~4095 according to its sampling value using some algorithm. Data type is “word”. Function code: 03H for reading. Please refer to <<User’s manual of expanded I/O modules>> for more details. Address Parameter code...
  • Page 112 Address Parameter code Range Data type property First group: time stamp: 4399H~439fH word yyyy:mm:dd:hh:mm:ss:ms 43a0H First group: DI status word 43a1H~4438H 2nd to 20th group word 0:none; 1:AXM-IO11; 2:AXM-IO21; 4439H I/O module of SOE 3:AXM-IO31; word 4:AXM-IO12; 5:AXM-IO22; 6:AXM-IO32 DI Status Current DI status, if related I/O module isn’t connected, the DI status will be set to 0.
  • Page 113 000dH DI14 1=ON,0=OFF AXM-IO12 000eH DI15 1=ON,0=OFF 000fH DI16 1=ON,0=OFF 0010H DI17 1=ON,0=OFF 0011H DI18 1=ON,0=OFF 0012H DI19 1=ON,0=OFF 0013H DI20 1=ON,0=OFF AXM-IO22 0014H DI21 1=ON,0=OFF 0015H DI22 1=ON,0=OFF 0016H DI23 1=ON,0=OFF 0017H DI24 1=ON,0=OFF AXM-IO32 0018H DI25 1=ON,0=OFF 0019H DI26 1=ON,0=OFF 001aH...
  • Page 114 AXM-IO32 0006H Relay7 1=ON,0=OFF 0007H Relay8 1=ON,0=OFF...

  • Page 115: Appendix

    Appendix Appendix A Technical Data and Specifications Appendix B Ordering Information Appendix C Revision History...

  • Page 116: Appendix A Technical Data And Specifications

    Appendix A Technical data and Specification Input ratings Voltage input Voltage rating 400 LN / 690 LL Vac RMS (3-phase)， 400 LN Vac RMS（single-phase） With 20% overage (3LN or 2LN wiring) Installation Category III, Pollution Degree 2 Frequency range 45~65Hz overload 2 times(continuously);...
  • Page 117 Accuracy Parameter Accuracy Voltage1 0.2% Current2 0.2% Power 0.5% Reactive Power 0.5% Apparent Power 0.5% Power Factor 0.5% Frequency 0.2% Energy 0.5% Reactive Energy 0.5% 1.0% Unbalance Factor 0.5% Less than 100ppm/℃ Drift with Temperature Stability 0.5‰/year Standards Measuring IEC 62053-22 0.5S IEC 62053-23 Environmental IEC 60068-2...
  • Page 118 Suitable Conditions 96x96x51 Dimensions (mm) (Cut-out 92x92 or 4-inch Round) Protection Level IP52 (Front), IP30 (Cover) Weight (g) 350g -25℃~70℃, Metering Temperature -40℃~85℃, Storage Humidity 5%~95% Non-condensing 100~415Vac, 50/60Hz; 100~300Vdc Power Supply Category III, Pollution degree 2 Power Consumption...

  • Page 119: Appendix B Ordering Information

    Appendix B Ordering Information Acuvim II Ordering Information: Acuvim II Blank: 5A Current 1:1A Blank: 100~415Vac, 50/60Hz, 100~300Vdc Power Supply DC: 20~60Vdc Systerm Frequency 50: 50Hz 60: 60Hz Note: 1. The same IO module can't be used exceed 2 piece at one Acuvim II, and the 2 same IO modules must be different logic NO.

  • Page 120: Appendix C Revision History

    Appendix C Revision History Revision Date Description 20070915 20070930 P47: change the flow chart; P86: change value of address 101dH from "Reserved" to "Basic parameter mode"; P93: change the description of "Basic analog measurement"; P101~P102: change the description "Counting number of I/O modules".
