Page 7: Chapter 1 Introduction
5. Product Disk (Manual, Warranty, Software) 6. Additional documentation(Quick Setup Guide, Calibration Certificate) To avoid complications, please read this manual carefully before installation and operation of the Acuvim II series meter. Chapter 1 Introduction Chapter 2 Installation and Wiring Chapter 3 Meter Display and Parameter Settings...
Page 9: Meter Overview
Chapter 1 Introduction 1.1 Meter Overview 1.2 Areas of Application 1.3 Functionality...
Page 10 An Ideal for Electric Automation SCADA Systems The Acuvim II series meter is the ideal choice for replacing traditional, analog electric meters. In additon to providing clear real-time readings on the meter front, it can also be used as a remote terminal unit (RTU) for monitoring and controlling for a SCADA system.
Page 11 Power Quality Analysis Utilizing digital signal processing (DSP) technology, the Acuvim II series meter provides high accuracy power quality analysis and supports remote monitoring via the Ethernet module. The meter continuously updates metering results and allows users to access the meter online to monitor parameters such as voltage and current THD, harmonics, voltage crest factor, current K factor, and voltage and current unbalance factor etc.
Page 12 1.2 Areas of Application  Power Distribution Automation  Electric Switch Gear and Control Panels  Industry Automation  Building Automation  Energy Management Systems  Marine Applications  Renewable Energy 1.3 Functionality Multifunction Acuvim II meters provide powerful data collecting and processing functions. In additon to measuring various parameters, the meter is able to perform demand metering, harmonic analysis, max/min statistic recording, over/under limit alarming, energy accumulating and data logging.
Page 13 Multiple Wiring Modes The Acuvim II series meter can be used in high voltage, low voltage, three phase three wires, three phase four wires and single phase systems using different wiring mode settings. High Safety, High Reliability Acuvim II series meter was designed according to industrial standards. It can run reliably under high power disturbance conditions.
Page 14 Acuvim Acuvim Acuvim Acuvim Category Item Parameters Waveform Capture If 400Hz voltage and Trigger, Manual, DI change, Sag/Dips, type,there is no this current Waveform Swell, Over Current function Voltage U_unbl Unbalance Factor Current I_unbl Unbalance Factor Voltage THD THD_V1,THD_V2,THD_V3, THD_Vavg Power Quality Current THD THD_I1, THD_I2, THD_I, THD_Iavg...
Page 15 Acuvim Acuvim Acuvim Acuvim Category Item Parameters RS485 Port,Half Communication Duplex, Optical Modbus-RTU/DNP3.0 Protocol Isolated Others Time Real Time Clock Year, Month, Date, Hour, Minute, Second Only support full-wave energy,support 400Hz type ~ 15 individual harmonics. Switch Status (DI) Digital Input (Wet) Power Supply for DI 24 Vdc Relay Output (RO) NO, Form A...
Page 17: Chapter 2 Installation
Chapter 2 Installation 2.1 Appearance and Dimensions 2.2 Installation Methods 2.3 Wiring 2.3.1 Terminal Strips 2.3.2 Power Requirements 2.3.3 Voltage Input Wiring 2.3.4 Current Input Wiring 2.3.5 Frequently Used Wiring Methods 2.3.6 Communication...
Page 18: Considerations When Installing Meters
Considerations When Installing Meters  Installation of the meter must be performed by qualified personnel only, who follow standard safety precautions through the installation procedures. Those personnel should have appropriate training and experience with high voltage devices. Appropriate safety gloves, safety glasses and protective clothing are recommended.
Page 19 CTs. CT grounding is optional.  ACCUENERGY recommends using a dry cloth to wipe the meter. NOTE: IF THE EQUIPMENT IS USED IN A MANNER NOT SPECIFIED BY THE MANUFACTURER, THE PROTECTION PROVIDED BY THE EQUIPMENT MAY BE IMPAIRED.
Page 20 The installation method is introduced in this chapter. Please read this chapter carefully before beginning installation. 2.1 Appearance and Dimensions Multifunction Power Meter   Gasket  96.00 (3.800) 96.00 (3.800) Front View of the Display Meter Gasket and Remote Display Unit 7.60 (0.300) ...
Page 21 Unit: mm(inches) Fig 2-1 Appearance and dimensions of Acuvim II series meter Table 2-1 Part name of Acuvim II series meter Part Name Description  LCD Display Large bright white backlight LCD display. Visible portion (for display and control) after mounting onto a ...
Page 22: Installation Methods
Operation: -25˚C to 70˚C. Storage: -40˚C to 85˚C Humidity 5% to 95% non-condensing. The Acuvim II series meter should be installed in a dry and dust free environment. Avoid exposing meter to excessive heat, radiation and high electrical noise source. Installation Steps The Acuvim II series meter can be installed into a standard ANSI C39.1 (4”...
Page 23 2. Remove the clips from the meter, and insert the meter into the square hole from the front side. Please note: optional rubber gasket must be installed on the meter before inserting the meter into the cut out. Panel Panel Fig 2-3 Put the meter into the opening 3.
Page 24: Wiring
2.3 Wiring 2.3.1 Terminal Strips There are four terminal strips at the back of the Acuvim II series meter. The three phase voltage and current are represented by using 1, 2, and 3 respectively. These numbers have the same meaning as A, B, and C or R, S, and T used in other literature.
Page 25: Power Requirement
NOTE There are 2 options for the Control Power of the Make sure the control Acuvim II series meter: p o w e r t e r m i n a l o f 1. Standard: 100~415Vac (50/60Hz) or 100-300Vdc the meter ground is 2.
Page 26 Choice of wire of power supply is AWG22-16 or 0.6-1.5mm Voltage Input Maximum input voltage for the Acuvim II series meter shall not exceed 400LN/690LL VAC rms for three phase or 400LN VAC rms for single phase. Potential Transformer (PT) must be used for high voltage systems. Typical...
Page 27 CT loop. One end of the CT loop should be connected to the ground. Vn Connection Vn is the reference point of the Acuvim II series meter voltage input. Low wire resistance helps improve the measurement accuracy. Different system wiring...
Page 28: Voltage Input Wiring
modes require different Vn connection methods. Please refer to the wiring diagram section for more details. Three Phase Wiring Diagram This meter can satisfy almost any kind of three phase wiring diagrams. Please read this section carefully before choosing the suitable wiring method for your power system.
Page 29 Fig 2-9a 3LN direct connection Fig 2-9b 3LN with 3PT 3-Phase 3-Line Direct Connection Mode (3LL) In a 3-Phase 3-Line system, power line A, B and C are connected to V1, V2 and V3 directly. Vn is floated. The voltage input mode of the meter should be set to 3LL.
Page 30: Current Input Wiring
Fig 2-10 3LL 3-Phase 3-Line direct connection 3-Phase 3-Line open Delta Mode (2LL) Open delta wiring mode is often used in high voltage systems. V2 and Vn are connected together in this mode. The voltage input mode of the meter should be set to 2LL for this voltage input wiring mode.
Page 31 to the system. In either case, there is current flowing through all three current terminals. Fig 2-12 3CTs a Fig 2-13 3CTs b The difference between Fig 2-14 and Fig 2-15 is that no current flows through current input terminal I21 and I22. The meter should be set to the I2 value which is calculated from formula i1+i2+i3=0.
Page 32: Frequently Used Wiring Methods
Fig 2-14 2CTs Fig 2-15 1CT 2.3.5 Frequently Used Wiring Method In this section, the most common voltage and current wiring combinations are shown in different diagrams. In order to display measurement readings correctly, please select the appropriate wiring diagram according your setup and application.
Page 33 1. 3LN, 3CT with 3CTs Fig 2-16 3LN, 3CT 2. 3LN, 3CT with 2CTs Fig 2-17 3LN, 3CT with 2CTs...
Page 34 3. 2LL, 3CT Fig 2-18 2LL, 3CT 4. 2LL, 2CT Fig 2-19 2LL, 2CT...
Page 35 5. 1LN, 1CT(Wiring mode setting 1LN, 1CT) Fig 2-20 Single phase 2 Lines 6. 1LL, 2CT(Wiring mode setting 1LL, 2CT) Fig 2-21 Single phase 3 Lines...
Page 36: Communication
) or higher. The overall length of the RS485 cable connecting all devices should not exceed 1200m (4000ft). The Acuvim II series meter is used as a slave device of masters such as a PC, PLC, Data Collector or RTU.
Page 37: Chapter 3 Meter Display And Parameter Settings
Chapter 3 Meter Display and Parameter Settings 3.1 Display Panel and Keys 3.2 Metering Data 3.3 Statistics Data 3.4 Demand Data 3.5 Harmonic Data 3.6 Expanded I/O Module Data 3.7 Parameter Settings Mode 3.8 Page Recovery Function...
Page 38: Display Panel And Keys
3.1 Display Panel and Keys The front of the Acuvim II series meter consists of an LCD screen and four control keys. All the display segments are illustrated in Fig 3-1. Users should note that all the segments will not display in a single page under normal conditions.
Page 39 Display Description Shows different modes on the display area. “Meter” for real-time measurement; “Max/Min” for statistic Display mode indication data; “Demand” for power demand data; “Harmonic” for harmonic data; “Setting” for parameters setting; “Digital I/O” for expanded IO module data. Main display area: displays metering data such as voltage, current, power, power factor, frequency, Four lines of “...
Page 40 Display Description voltage: V, kV; current: A, kA:active power: kW, MW; reactive power: kvar, Mvar; apparent power: kVA, MVA; Units measured frequency: Hz; active energy: kWh; reactive energy: kvarh; apparent energy: kVAh; percentage: %; phase angle: ° No icon: no communication Communication icon One icon: query sent Two icons: query sent and response received...
Page 41: Metering Data
navigate the meter. Note: If the LCD backlight is off, pressing any key one time will bring the backlight on. 3.2 Metering Data Pressing H and V/A simultaneously will activate the display mode selection and the cursor will flash. Press P or E to move the cursor right or left. To enter the metering mode, move the cursor to "Meter"...
Page 42 Note: When the meter is set to “2LL” or “3LL”, there is no phase voltage or neutral current display. Therefore, only the third screen (line voltage & avg) and the fourth screen (three phase current & avg) will be displayed. When the meter is set to “1LN”, there are only phase A voltage and phase A current display, without line voltages or other displays.
Page 43 Note: When the meter is set to “2LL” or “3LL”, only the fifth screen (system power) and the sixth screen (system power factor & frequency) will be displayed. When the meter is set to “1LN”, there are only phase A power and phase A power factor display.
Page 44 E is pressed again. It will go back to the first screen if you press E at the last screen. Acuvim II series meter can be set to record primary energy or secondary energy.The unit of energy is kWh for active energy, kvarh for reactive energy and kVAh for apparent energy.
Page 45 e) TOU display Press “P” and “E” simultaneously to enter the TOU Energy and maximum demand page. Press “E”display the TOU energy. Press “P”display the TOU maximum demand. Press again display the TOU maximum demand year,month and date. Press again display the TOU maximum demand hour, minute and second. Press “H”would change the tariffs page.
Page 46 The following fiure shows the sequence: Total Total Total Total Total Total Total Total Total Total Total Total Sharp Sharp Sharp Sharp...
Page 47 month Total Total Total Total month Total Total month Total Total month Total Total month Total Total month Sharp Sharp month Sharp Sharp month month month...
Page 48: Statistics Data
3.3 Statistics Data Pressing H and V/A simultaneously will activate the display mode selection and the cursor will flash. Press P or E to move the cursor right or left. To enter the statistics data mode, scroll the cursor to "Max/Min" then press V/A. In statistics data mode, the meter displays the maximum values and minimum values for voltage, current, power, power factor, unbalance, demand, THD etc.
Page 49 Max value of phase Max value of Power voltage Demand Max value of voltage Max value of the line to line voltage Max value of current Max value of current Max value of current Max value of power demand Max value of Max value of power unbalance factor factor &...
Page 50: Demand Data
3.4 Demand Data Pressing H and V/A simultaneously will activate the display mode selection and the cursor will flash. Press P or E to move the cursor right or left. To enter demand mode, move the cursor to "Demand" then press V/A. In the demand data mode, the first screen displays the demand of active power, reactive power and apparent power, and the second screen displays the current demand of phase A, phase B and phase C.
Page 51 a) Power Quality Data: Press H to display power quality data. When H is pressed again, the screen will roll to the next page and will roll back to the first screen when pressed at the last page. No commands are associated with keys P and E in "Harmonic" display mode. Press V/A to switch to harmonic ratio data display.
Page 52 b) Harmonic Ratio Data Press H to switch to power quality data display. The harmonic order will increase by one each time P is pressed and will return to the 2 when P is pressed at the 63 harmonic. The harmonic order will decrease by one each time E is pressed and will return to the 63 when E is pressed at the 2 harmonic.
Page 53: Expanded I/O Module Data
3. When the meter is set to “1LN”, there is only phase A display for voltage and current harmonic magnitude. 4. When the meter is set to “1LL”, there is no phase C display for voltage and cur- rent harmonic magnitude. 3.6 Expanded I/O Module Data Pressing H and V/A simultaneously will activate the display mode selection and the cursor will flash.
Page 54 As shown in the figure, three modules are connected, AXM-IO11, AXM-IO21, AXM-IO31, which are indicated by M11, M21, M31 respectively. The cursor points to M21, which indicates that AXM-IO21 is chosen now. b) I/O Module Data Selection Press H to return to module selection screen. Press P to move the cursor downwards, the cursor will move to the top when it reaches the bottom.
Page 55 The screen will roll to the last page each time E is pressed and will return to the last page E is pressed at the first page. If only one page exists, pressing E will have no effect. No commands are associated with the key V/A in this display. The following figure shows the sequence:...
Page 56 Note: The figure shows the rolling sequence for using key P. If using E key for rolling page, the sequence will reverse.
Page 57: Parameter Settings Mode
3.7 Parameter Setting Mode Pressing H and V/A simultaneously will activate the display mode selection and the cursor will flash. Press P or E to move the cursor right or left. To enter parameter setting mode, move the cursor to "Setting" then press V/A. In the parameter setting mode, parameters such as system parameters, expanded I/O module parameters, alarm parameters and Ethernet module parameters, can be read and modified.
Page 58 To input password: Press H to move the flashing cursor to the next position. Press P to increase the number by 1. Press E to decrease the number by 1. Press V/A to confirm the password. b) Parameter Selection Mode There are four parameters to choose from in the parameter selection manual: system, expanded I/O module, Ethernet module and alarm.
Page 59 means system parameter is selected. c) System Parameter Setting Users can select and modify system parameter in the system parameter setting mode. Key functions for selecting a parameter: Press H to return to parameter selection mode. The screen will roll to the next page each time P is pressed and will return to the first page when P is pressed at the last page.
Page 62 Note: The figure shows the rolling sequence for usingthe P key. If using the E key for rolling page, the sequence will reverse. d) Expanded I/O Module Parameter In the expanded I/O module parameter mode, user can choose to view the available modules that are attached to the meter and modify their parameters.
Page 63 If there is only one module connected, pressing E will have no effect. Press V/A to select the module and enter the I/O module parameter setting mode. Key functions for setting the I/O module parameter: Press H to return to I/O module selection mode. The screen will roll to the next page each time P is pressed and will return to the first page when P is pressed at the last page.
Page 65 DI of AXM-IO2 can be used as the pulse counter, each DI function corresponds to one bit of a 4-bit register. The correspondence bit of 0 means that the DI works as the digital status input and the correspondence bit of 1 means that the DI works as the pulse counter.
Page 66 DI of AXM-IO3 can be used as the pulse counter, each DI function corresponds to one bit of a 4-bit register. The correspondence bit of 0 means that the DI works as the digital status input and the correspondence bit of 1 means that the DI works as the pulse counter. For example, if the setting value is 0001, it means that DI1 is set as the pulse counter and other DIs work as digital status inputs.
Page 67 e) BACnet and Ethernet Module Parameter When the second communication protocol is set to BACnet, there is parameters display related to BACnet, while these pages only show as modules successfully connecting with meter. If meter does not detect any module, there will show LOADING page.
Page 68 Press V/A to confirm the modification and return to parameter selection mode. The following figure shows the sequence of Ethernet module. The selection of DHCP setting: MANU or AUTO Default setting: MANU IP address has four segments. Any segment can be set from 0~255.
Page 69 Note: The figure shows the rolling sequence for using key P. If using E key for rolling page, the sequence will reverse. BACnet IP module rolling sequence:...
Page 70 BACnet MS/TP module rolling sequence MESH module interface part f) Alarm Parameter In the alarm parameter mode, user can view and modify the parameters. Key functions for finding the alarm parameter: Press H to return to parameter selection mode.
Page 71 The screen will roll to the next page each time P is pressed and will return to the first page when P is pressed at the last page. The screen will roll to the last page each time E is pressed and will return to the last page when E is pressed at the first page.
Page 72 Yes: Alarm enable; No: Alarm disable It can be selected as cue signal for alarming. Yes: backlight flashes upon alarm condition; No: no backlight flashing There are 16 alarm channels available. Each channel is controlled and enabled 1 bit each from a 16-bit register. Bit value of 1 means that the corresponding alarm channel is enabled whereas 0 means that the channel is disabled.
Page 73: Page Recovery Function
3.8 Page Recovery Function Acuvim II series meter has a page recovery function. This means that the meter stores current display page in the non-volatile memory upon power loss and reloads the page when power recovers. If power goes off when viewing under the parameter setting mode, the meter will show voltage display when power recovers.
Page 75: Chapter 4 Detailed Functions And Software
Chapter 4 Detailed Functions and Software 4.1 Basic Analog Measurements 4.2 Max/Min 4.3 Harmonics and Power Quality Analysis 4.4 Over/Under Limit Alarming 4.5 Data Logging 4.6 Time Of Use(TOU) 4.7 Power Quality Event Logging and Waveform Capture 4.8 Seal function...
Page 76 The Acuvim II series meter contains advanced metering tools and is able to measure a multitude of power, energy and power quality parameters. Some advanced functions may not be accessible directly from the meter front; therefore, every meter comes with a powerful software that helps access the information.
Page 77 Demand: This meter consists of several types of demand calculation: total active power demand, total reactive power demand, total apparent power demand, phase A current demand, phase B current demand, and phase C current demand. When demand is reset, demand memory registers are set as 0. Demand calculating mode can be set as sliding window and thermal according to user.
Page 78 2. There are two ways to calculate reactive energy(power) Mode 0: real reactive energy Mode 1: general reactive energy 3. User can choose primary energy or secondary energy either by pressing keys from the meter front or via communication as shown in Fig 4-7. Note: Acuvim II is able to display either primary energy or secondary energy on the LCD screen;...
Page 79 Current direction adjustment Under normal circumstances, current flows from input terminal 1 to terminal 2 (i.e. from I11 to I12 for phase A current); however, current may flow in the opposite direction due to incorrect wiring setup. Instead of rewiring the system, the meter provides users an option to reverse the polarity of the current.
Page 80: Max/Min
They are shown in Fig 4-4. 3. Sequence component and unbalance analysis Acuvim II series meter is able to perform sequential analysis for the input signal. It looks at the positive sequence, negative sequence and zero sequence of...
Page 81: Over/Under Limit Alarming
Fig 4-4 Sequence component and Phase angle 4.4 Over/Under Limit Alarming Acuvim II series meter has over/under limit alarming capabilites. When the monitored parameter goes over/under the preset limit and stays at the level over the preset amount of time delay, the over/under limit alarm will be...
Page 82 alarming log. The meter can record up to 16 alarming records. When extended I/O modules are attached, digital outputs (DO) and relay outputs (RO) can be triggered upon alarm conditions and used to activate downstream devices such as a beacon light or a buzzer. Before using the alarming function, alarm conditions such as logic dependency, target setpoint, time delay etc must be set correctly.
Page 83 1. Single Alarming Group Setting Table 4-1 indicates the first group of settings, there are 16 groups in total with the same format. Table 4-1 First Group of Alarming Settings Address Parameter Range Property 104EH First group: parameter code 0~79 104FH First group: comparison mode 1:larger,2:equal,3:smaller...
Page 84 Note: 1) If RO is under alarming mode, it can only work in “latch” mode. 2) If the number is 51~79, there are special guide for contrast method and meaning of parameters, please refer to Chapter 6. After setting up the alarming parameters, user must also setup the global settings in order for the alarm to work properly.
Page 85 This function is controlled by the lower 8 bits of the 16-bit register and each bit is corresponding to a pair. “1” means this function is enabled and “0” means disabled. “Alarming output to DO1 setting”: When “Digital output mode” is set to “1”, DO1 can be used as alarming output.
Page 86 “Delay time (1051H)” is set to 500, so the actual delay time is 500*10ms=5s. “Output to relay (1052H)” is set to 0, because there is no output to RO. Settings of second group: “Parameter code (1053H)” is set to 1, which stands for U1. “Comparison mode (1054H)”...
Page 87 4. Records of Alarming Event Acuvim II series meter has built in alarm logging capabilities. 16 entries can be recorded in total. The record sequence of these entries do not depend on the sequence of the 16 alarm channels. The meter begins logging alarm status starting from the 1 record location to the last one.
Page 88 “Time” indicates the time stamp with the accuracy in milliseconds (ms). Alarming event will set bit0 of “system status (102EH)” to be 1. When software send clear alarm command, Bit0 of “system status (102EH)” will be set to 0. Alarming group number (1032H): the range is 0~16, 0 is no alarm record, and others stand for which record is newest alarm.
Page 89: Data Logging
Fig 4-7 Basic settings 4.5 Data Logging meter provides data logging that records the data at a set Acuvim IIR/IIE/IIW interval.This meter has 8 MegaBytes of memory which gives it extensive data- logging capabilities. It has a real-time clock that allows logs to be time-stamped when log events are created.
Page 90 1. Data log settings meter has three sets of historical data logs. Each log can be Acuvim IIR/IIE/IIW independently programmed with individual settings, meaning that each can be used to monitor different parameters. You can program up to 117 parameters per log.
Page 91 Having three sets of historical logs provides you with the option of programming each log with unique parameters. For example, you can program Historical Log 1 to record measured values parameters (for example, Frequency, Voltage, Current), Log 2 to record energy values parameters, and Log 3 to record power quality parameters.
Page 92 • DI Counter (the DI numbers of the IO modules) • AO/AI Raw Value (the AO output register values and the AI sample register values) • AO/AI Value(the AO output values and the AI sample values) The following procedures show how to select and store parameters in historical log 1.
Page 93 A. Mode1: if correctly set historical log, can record without setting date and time, depending on first-in first-out recycling log. B. Mode2: if correctly set historical log, as set date and time, can record within begin to end time. Record will stop after buffer is full. C.
Page 94 Fig 4-9 Retrieval screen The "read one window" method allows you to access and read a specific log location at an offset from the first log. The "window record num" is the maximum number of record entries the software can read at a time, it is calculated by 246 / Record Size.
Page 95: Time Of Use (Tou)
4.6 Time of use (TOU) User can assign up to 4 different tariffs (sharp, peak, valleyand normal) to different time period within a day according to the billing requirements. The meter will calculate and accumulate energy to different tariffs according to the meter’s internal clock timing and TOU settings.
Page 96 year (the earlier date comes first and the later date comes last). For example, if 3 seasons are selected, the date parameters are January 1, June 6 and September 7, and TOU schedule 02, 01, 03 will be used respectively, the first TOU season table slot shall enter 01-01 02, the second slot shall enter 06-06 01, and the third slot shall enter 09-07 03.
Page 97 operation, TOU function will be disabled. 6. Tariff setting parameter: This parameter corresponds to the number of tariffs available for the TOU calendar and can be selected from any integer from 0 to 3. The four tariffs: sharp, peak, valley and normal are represented by 4 integers: 0, 1, 2 and 3 respectively.
Page 98 week)/hour/minute/adjust time(in minutes). By using the function, you can cause the instrument to automatically switch to and from daylight saving time. When the clock starts to run to daylight saving time, the meter will automatically adjust the clock to a time period in advance, while the clock is running to the end of daylight saving time, meter will automatically adjust the clock pushed back to a time period, as shown in Fig 4-10...
Page 99 Holiday Auto Switch: When Ten-year Holiday is enabled, if the current year of the meter falls into the Ten-year Holiday setting, it automatically loads the Ten- year Holiday settings into the current TOU settings. If the current year of the meter does not fall into the Ten-year Holiday setting, it remains the current TOU settings.
Page 100 Setting field. When the meter clock is within the preset Weekend Schedule, the energy will accumulate under the tariff that corresponds to the Schedule. Note: Holiday schedule has the highest priority among all the schedules. Weekend schedule's priority is followed by Holiday schedule. When Holiday schedule is not enabled, Weekend schedule has the highest priority, overiding the normal (weekday) schedule.
Page 101: Power Quality Event Logging And Waveform Capture
Month TOU or Prior Month TOU.User can set the time in the following format :DD HH:MM:SS"-DD stands for day,HH stands for hour,MM stands for minute,SS stands for second.Similar to the previous method,once Current Accumulation Month TOU is transferred to Prior Accumulation Month TOU,Current Accumula- tion Month TOU will continue to accumulate.once Current Month TOU is trans- ferred to Prior Month TOU,Current Month TOU will be cleared and reset to 0.
Page 102 Threshold: W7—Threshold for voltage sag and swell. Half Cycle count: W8 (Voltage Swell: 0; Voltage Sag: 4~200) 2. Logging Events The event logging feature can log 50000 events. If the 50000 events are full, no more events will be logged even if the triggering condition happens. The user must clear the event log, and then the logging will log the new event.
Page 103 waveform capture. The other triggering conditions for Waveform Capture can be set when necessary. When the Waveform Capture triggering by Voltage Sag and Voltage Swell is enabled, the corresponding event log and waveform will be recorded when Voltage Sag or Voltage Swell happens. Fig.
Page 104 each retrieve (0X8CFF) must be set correctly. It must be ensured that the starting number of event log should equal or smaller than the newest log number. When setup is correct, reading registers 0X8D00H—0X8D4FH will acquire the event log data. Each time a maximum of 10 logged events can be retrieved. The event log retrieve page is in the figure below.
Page 105 Waveform Capture Acuvim IIW can record 100 groups of voltage and current waveform data at a sampling rate of 64 points per cycle. It provides the captured waveform of 10 cycles before and after the triggering point (including U1,U2,U3,I1,I2,I3). The triggering condition is settable.
Page 106 W13— Voltage Swell Triggering (0: disabled; Bit0: 1 – u1 voltage swell waveform, 0 – no u1 waveform; Bit1: 1 – u2 voltage swell waveform, 0 – no u2 waveform; Bit2: 1 – u3 voltage swell waveform, 0 – no u3 waveform;) W14—...
Page 107 the process of memory writing, it will respond to new waveform triggering condition. 3. Waveform Capture Triggering Condition 1) Manual Triggering Manually trigger one group waveform capture. 2) DI Triggering DI Triggering must fulfill the following two conditions at the same time. •IO modules with the logical address of 1 (AXM-IO11, AXM-IO21, AXM-IO31).
Page 108 capture will be implemented. If one phase is over-current, any other phase over- current cannot implement the waveform capture. Only when all of the phase current restore back to normal, waveform capture will be responding. 4. Waveform Capture Retrieve Because of large quantity of saved waveform, waveform retrieving window use 64 addresses to make retrieving data easier, which keeps consistent with recording points of one period.
Page 109 retrieving partial data. Waveform Group Number for Retrieving (8E00H) will stop increasing while value reaches Newest Waveform Group Number. If the value added 4, the value will be larger than Newest Waveform Group Number. Second retrieving method is retrieving all waveforms data. When 0x8E01H (Waveform Group Number) is set to 1~121, each time only one group data of each number will be retrieved, then Waveform Group Number for Retrieving (8E01H) will automatically add 1 after retrieving.
Page 110 72~81: Each waveform number of ten waveforms after U2 waveform is triggered 82~91: Each waveform number of ten waveforms after U3 waveform is triggered 92~101: Each waveform number of ten waveforms after I1 waveform is triggered 102~111: Each waveform number of ten waveforms after I2 waveform is triggered 112~121: Each waveform number of ten waveforms after I3 waveform is triggered...
Page 111 1)5A,1A: Real Value(Unit: A) = Waveform Value/1683.153; 2)333mV: Real Value(Unit: A) = Waveform Value/K (firmware above 3.21,K=14427.15; other: K = 15869.87); 3)100mV(Rope-CT):Real Value(Unit: A) = Waveform Value/K (firmware above 3.21,K=20291.1; firmware 3.20, K=22068.8,other: K = 15869.87); 4)mA CT:Real Value(Unit: A) = Waveform Value/K (80mA CT:K=7414.289; 100mA:K=9267.440;...
Page 112: Seal Function
Note: When selecting 400Hz type,not support event logging and wave capture. 4.8 Seal Function The panel with seal, which has sealed key control, is different with one without seal. When the seal is in opened status, functions are same like normal meters. But when the seal is in sealed status, some functions of meters, which include parameters blocked by seal and optional parameters, will be blocked.
Page 113 As long as seal is in sealed status, parameters below must be blocked, no matter what value of address 101EH. System parameters setting: Address Parameter Keys Communication 1003H Voltage input wiring type √ √ 1004H Current input wiring type √ √...
Page 114 Energy: Address Parameter Keys Communication 4048H--4049H Energy IMP √ 404AH--404BH Energy EXP √ 404CH--404DH Reactive energy IMP √ 404EH--404FH Reactive energy EXP √ 4050H--4051H Energy TOTAL √ 4052H--4053H Energy NET √ 4054H--4055H Reactive energy TOTAL √ 4056H--4057H Reactive energy NET √...
Page 115 10BAH DO4 output √ √ Sealed Nonstandard Parameters: 1) When bit 0 of address 101EH is valid, parameters about 1 communication should be blocked. Address Parameter Keys Communication 0FFEH Communication Protocol 1 √ √ 0FFFH Parity Setting 1 √ √ 1000H Password √...
Page 116 DNS1 4 byte (low) √ √ DNS2 1 byte (high) √ √ DNS2 2 byte (low) √ √ DNS2 3 byte (high) √ √ DNS2 4 byte (low) √ √ Modbus Tcp/Ip port √ √ Http port √ √ BACnet Module BACnet module enable √...
Page 117 3) When bit 2 of address 101EH is valid, parameters below should be blocked. Address Parameter Keys Communication 1011H Run time clear √ √ 4) When bit 3 of address 101EH is valid, parameters below should be blocked. Address Parameter Keys Communication 101CH...
Page 118 Address Parameter Keys Communication 1039H Ten years download setting enable √ 103AH Fee of sharp demand clear √ 103BH Fee of peak demand clear √ 103CH Fee of valley demand clear √ 103DH Fee of normal demand clear √ 103EH Total fee of demand clear √...
Page 119: Chapter 5 Extended Modules
Chapter 5 Extended Modules 5.1 IO Modules 5.2 Ethernet Module (AXM-NET) 5.3 ProfiBus Module (AXM-PRO) 5.4 RS485 Module (AXM-485) 5.5 BACnet Module (AXM-BACnet)
Page 120: Io Modules
5.1 IO Modules 5.1.1 The Purpose of IO Modules The standard Acuvim II meter base does not have any built-in IO functions. However, with the addition of the extended modules, multiple IO options can be added. These functions include digital input, pulse counter, relay output, analog output, analog input, etc.
Page 121 The AXM-IO2 module is composed of: 4 digital inputs (DI) -- Each digital input can be used to detect remote signals, or be used an input pulse counter. When it is used to detect remote signals it can also enable SOE(sequence of events), recording the events and time of the events.
Page 122 5.1.2 List of Functions of IO Modules Table 5-1 Functions AXM-IO1 AXM-IO2 AXM-IO3 Detection of remote signals Recording of SOE Counting of input pulses Output remote controlling by relay Output alarm by relay Output alarm by digital output Output power pulses by digital output Analog output Analog input 24V isolated voltage output...
Page 123 Enclosure Installation screw Wiring Terminals Counterpart of clip Linking pins Installation clip Linking socket Fig 5-1 Dimensions 5.1.4 Installation Method Environment Please verify the installation environment meets the requirements listed as follows: Temperature Operation: -25ºC to 70ºC Storage: -40ºC to 85ºC Humidity 5% to 95% non-condensing.
Page 124 press the IO module lightly, so linking is established. 2. Tighten the installation screws. 3. Install other IO modules the same way. Note: 1. Install IO Modules carefully to avoid damage; 2. Under no circumstances should any installation be done with the meter powered on.
Page 125 DI1 to DIC: digital input terminals, where DIC is the common terminal for DI1 to DI6 circuits. RO1 to ROC: relay output terminals, where ROC is the common terminal for RO1 and RO2 circuits. V24+ and V24-: auxiliary voltage supply terminals. Terminal Strips of AXM-IO2 Module: Digital Input Digital Output...
Page 126 DI1 to DIC: digital input terminals, where DIC is the common terminal for DI1 to DI4 circuits. RO1 to ROC: relay output terminals, where ROC is the common terminal for RO1 and RO2 circuits. AI1+, AI1-, AI2+, AI2-: analog input terminals. Sequence of DI, RO, DO, AO, AI in IO modules (according to the logical order in the communication address table of the main body): DI Sequence: AXM-IO11 (AXM-IO1 module in logic NO.1): DI1-6...
Page 127 There are 6 digital input circuits, 4 digital input circuits and 4 digital input circuits in AXM-IO1, AXM-IO2 and AXM-IO3 modules respectively. The digital input circuit can be used to detect remote signals, or be used as an input pulse counter.
Page 128 mediate relay External power supply control IO module coil output Fig 5-7 schematic diagram of relay output circuit The wire of relay output should be chosen between AWG22~16 or 0.5~1.3mm Wiring of Digital Output Circuit: There are 2 digital output circuits in AXM-IO2 module. The digital output circuit can work in alarm state, or work in energy pulse output state.
Page 129 When J is in low state as shown in Fig 5-8, OUT is in low state. When J is in high state, OUT is in high state. OUT can therefore output pulse signals under the control of J. The max output voltage and current of digital output circuit are 250V and 100mA respectively.
Page 130 The simplified circuit is as shown in Fig 5-10. load load Current analog output Voltage analog output Fig 5-10 schematic diagram of analog output circuit The Load Capability of Analog Output Circuit: 0 to 20mA mode: the max load resistance is 500Ω. 4 to 20mA mode: the max load resistance is 500Ω.
Page 131 Current analog input Voltage analog input Fig 5-11 schematic diagram of analog input circuit 24V Isolated Power Supply: To simplify and make more convenient for the end user, there is a DI auxiliary power supply provided in AXM-IO1 module. The voltage of the DI auxiliary power supply is 24Vdc (1W).
Page 132 Fig 5-12 functions of IO modules 5.1.6 Detection of Remote Signals The digital input circuit can be set to detect remote signals. a. Detection of Remote Signals When digital input circuit detects a qualified voltage input, it will show “1” on screen and “ON”...
Page 133 Fig 5-13 showing DI state on screen b. Record of SOE When the digital input circuit is set to detect remote signals, the recording function of SOE can be enabled. Therefore, when the remote signals change, the IO module can record this information accordingly. SOE Record: including “4399H to 4439H”...
Page 134 All groups of SOE records are in the same format. Take the first group of SOE records for example, “4399H to 439FH” registers record the time information, including year, month, day, hour, minute, second and millisecond. “43A0H” register records the state information, which is an unsigned integer, where bit 0 records DI1 state, bit 1 records DI2 state, and so on.
Page 135 c. Parameter Setting of Detection of Remote Signals Take parameter setting of AXM-IO11 (AXM-IO1 module in logic NO.1) for example. “109EH” register: this register is an unsigned integer, where bit0 determines DI1’s working mode, bit1 determines DI2’s working mode, and so on. If the bit is “1”, then the DI circuit is set to be a pulse counter.
Page 136 Fig 5-15 parameters setting of IO module’s SOE function 5.1.7 Pulse Counter The digital input circuit can also be set to count pulses. Recorded number of pulses: including “4349H to 4380H” address The “4349H to 4380H” registers record 28 groups of individual number of individual number of pulses.
Page 137 NO.1), 4 groups of records for AXM-IO21 (AXM-IO2 module in logic NO.1), 4 groups of records for AXM-IO31 (AXM-IO3 module in logic NO.1), 6 groups of records for AXM-IO12 (AXM-IO1 module in logic NO.2), 4 groups of records for AXM-IO22 (AXM-IO2 module in logic NO.2) and 4 groups of records for AXM- IO32 (AXM-IO3 module in logic NO.2) in sequence.
Page 138 Fig 5-17 recorded number of pulses read by the utility software Parameter Settings for Counting Input Pulses: Take AXM-IO11 (AXM-IO1 module in logic NO.1) for example. 1. “109EH” register: if the bit is set as “1”, the counterpart digital input circuit is set to be a counter of input pulses.
Page 139 Real number of pulses = A × Recorded number of pulses. For example, if A=20, the recorded number of pulses counted by DI1 circuit of AXM-IO11 is 100 (4349H to 434aH registers), then the real number of pulses is 20×100=2000. The parameter setting is shown in Fig 5-15.
Page 140 Fig 5-18 status of relays read on screen b. Parameter Setting Take AXM-IO11 (AXM-IO1 module in logic NO.1) for example. “RO working mode (10A0H)” register: this register determines the working mode of relays. If the register is “0”, then RO1 and RO2 will work in controlling mode.
Page 141 5.1.9 Digital Output There are two mode selections for the digital output circuit; one being alarm mode, and the other being energy output mode. For alarm mode, action of digital output circuit is controlled by whether the alarm is triggered or not. For energy output mode, digital output circuits can output various types of energy, such as import active energy, export active energy, import reactive energy and export reactive energy.
Page 142 “DO1 output type” register and “DO2 output type” register can be set to the same value or not. The parameter setting is shown in Fig 5-19. Fig 5-19 parameter setting of DO energy pulse constant...
Page 143 5.1.10 Analog Output 1. Analog Output Relationship with Electrical Quantities The analog output circuit can convert anyone of 30 electrical quantities (reference Chapter 6), which is selected by user, to analog voltage or current. The analog output circuit supplies 4 output modes, including 0 to 20mA mode, 4 to 20mA mode, 0 to 5V mode and 1 to 5V mode.
Page 144 When number is 2, which includes (X1, Y1), (X2, Y2) and (X4, Y4), only AO following value range setting start point, AO1 following value range setting point 2, AO following value range setting end point, AO1 output range setting start point , AO1 output range setting point 2 and AO1 output range setting end point should be set.
Page 145 Reactive power Qa, Qb and Qc: -4800~4800 Var, real setting value is- 4800~4800. System reactive power: -14400~14400 Var. Apparent power Sa, Sb and Sc: 0~4800VA, real setting value is 0~4800. System apparent power: 0~14400VA, real setting value is 0~14400. Power factor PFa, PFb, PFc and System power factor: -1~1, real setting value is -1000~1000.
Page 146 2. Display of Analog Output Value of analog output is displayed in hex on screen. The relationship between displayed value and real value of analog output is: Displayed Value Real value = ×20mA (current output mode) 4096 Displayed Value or Real value = ×5V (voltage output mode) 4096 As shown in Fig 5-21, the displayed value of AO1 is 0x0800, so the real value of...
Page 147 “Frequency”. “Electrical quantities relative to AO2 (10C3H)” register: this register determines which electrical quantity AO2 should be relative to. The value of this register is defined as the same as “Electrical quantities relative to AO1 (10C2H)” register. “Electrical quantities relative to AO1 (10C2H)” register and “Electrical quantities relative to AO2 (10C3H)”...
Page 148 5.1.11 Analog Input Analog input circuits supply 4 types of input modes, including 0 to 20mA mode, 4 to 20mA mode, 0 to 5V mode, and 1 to 5V mode. Fig 5-23 shows the relationship between AI value and input analog value. AI value ranges from 0 to 4095 without any unit.
Page 149: Ethernet Module (Axm-Net)
5.2 Ethernet Module (AXM-NET) 5.2.1 Introduction to Ethernet Ethernet was originally developed by Xerox and then developed further by Xerox, DEC, and Intel. Ethernet uses a Carrier Sense Multiple Access with Collision Detection (CSMA/CD) protocol, and provides transmission speeds up to 10 Mbps.
Page 150 5.2.3 Appearance and Dimensions 22mm (Side View) 90mm 55.6mm (Top View)
Page 151 (Bottom View) 5.2.4 Installation Method The Ethernet module is linked to the Acuvim II meter by a communication plug. It can also be linked to other extended modules like IO modules. 1.Insert the installation clips to the counterpart of the meter, and then press the Ethernet module lightly, so linking is established.
Page 152 Note: 1. Install Ethernet Module carefully to avoid damage; 2. Under no circumstances should any installation be done with the meter powered on. Failure to do so may result in injury or death. 5.2.5 Definition of RJ45 Interface The Ethernet module uses a standard RJ45 connector to access the Ethernet network.
Page 153 LED_L (yellow): displays speed status. LED on indicates 100Mbps, while LED off indicates 10Mbps. LED_R (green): displays link and activity status combined. LED on indicates link status, while flashing LED indicates activity status. 5.2.6 Cable Shielded twisted-pair cable (standard 568A or standard 568B) is usually recommended as reference to the EIA/TIA standard.
Page 154 1. Pressing “H” key and “V/A” key simultaneously on the meter will go to the menu selecting mode. Cursor “Meter” flashes in this mode. Fig 5-25 2. Press “P” key or “E” key to move the cursor to "Setting". Press “V/A” key to go to the meter parameter setting mode.
Page 155 Fig 5-26 Fig 5-27...
Page 156 Fig 5-28 3. Set configuration mode in the first setting page. “AUTO” means that users configure module settings with DHCP protocol while “MANU” means that users configure module settings with manual setting. Press “V/A” key, to go to the setting state and the area pointed out in Fig 5-29 will flash. Press “P” key or “E” key to select configuration mode, press “V/A”...
Page 157 Fig 5-29 4. Set IP Address in the second setting page, such as 192.168.1.254 as shown below. Press the "V/A" key to go to the IP setting page. Users may set the parameters in the area pointed out in Figure 5-30. The cursor starts at the first digit.
Page 158 5. Set Subnet Mask in the third setting page, such as 255.255.255.0. Press “V/A” key to go to the setting page. Users may set the parameters in the area pointed out in Fig 5-31. The cursor starts at the first digit. After setting the Subnet Mask, press the "V/A"...
Page 159 6. Set Gateway in the fourth setting page, such as 192.168.1.1. Press the "V/A" key to go to the setting page. Users may set the parameters pointed out in Fig 5-32. The cursor starts at the first digit. After setting the Gateway, press the "V/ A"...
Page 160 7. Set DNS Primary Server in the fifth setting page, such as 202.106.0.20. Press the "V/A" key to go to the setting page. Users may set the parameters pointed out in Fig 5-33. The cursor starts at the first digit. After setting the DNS Primary Server, press the "V/A"...
Page 161 8. Set DNS Secondary Server in the sixth setting page, such as 202.106.196.115. Press the "V/A" key to go to the setting page. Users may set the parameters pointed out in Fig 5-34. The cursor starts at the first digit. After setting the DNS Secondary Server, press the "V/A"...
Page 162 9. Set Modbus-TCP port in the seventh setting page, such as 502. Press the "V/A" key to go to the setting page. Users may set the parameters pointed out in Fig 5-35. The cursor starts at the first digit. After setting the Modbus-TCP port, press the "V/A"...
Page 163 10. Set HTTP port in the eighth setting page, such as 80. Press the "V/A" key to go to the setting page. Users may set the parameters pointed out in Fig 5-36. The cursor starts at the first digit. After setting the HTTP port, press the "V/ A"...
Page 164 Fig 5-37 12. The password of AXM-NET module can be reset by selecting " RESET". The password then becomes "12345678". Selecting "NO" means no change. Press "V/A" key to accept. Fig 5-38 13. After configuring AXM-Net settings completely, press “H” key and “V/ A” key simultaneously to return to menu selecting mode.
Page 165 5.2.9 Searching IP Address of Ethernet Module The utility software of Acuvim II series meter supports a meter search function. Users can use this function to obtain IP addresses, MAC addresses and all parameters of Ethernet Modules. Operation steps: 1) Click “Start” menu of utility software.
Page 166 3) Utility software pop-ups “Search Device(s)” window, and the window displays IP address and MAC address of module. Fig 5-40 Note:This function is used only in LAN, not used in WAN or direct connect to computer. 5.2.10 Description of Modbus-TCP protocol The Modbus-TCP protocol is used for communication in Ethernet modules.
Page 167 Request Indication Modbus Client Modbus Server Confirmation Response Fig 5-41 1. Protocol a. Data Frame Format Table 5-2 MBAP Header Function Data 7x8-Bits 8-Bits Nx8-Bits b. Modbus Application Header (MBAP Header) Field The Modbus application header field is the start of the data frame and consists of seven bytes.
Page 168 Table 5-4 Code Meaning Action Read Relay Output Status Obtain current status of Relay Output Read Digital Input(DI) Status Obtain current status of Digital Input Read Data Obtain current binary value in one or more registers Control Single Relay Output Force Relay to a state of on or off Place specific value into a series of consecutive Write Multiple-registers...
Page 169 Data #of regs lo: number of register low byte a. Read Status Relay (Function Code 01) Function Code 01 This function code is used to read relay status in Acuvim II series meter. 1=On 0=Off There are 8 Relays in the meter, and the starting address is 0000H.
Page 170 Data #of regs lo Response The Acuvim II series meter response includes MBAP Header, function code, quantity of data byte and the data. For example response to read the status of Relay 1 and Relay 2 is shown as Table 5-6. The status of Relay 1 and Relay 2 is responding to the last 2 bit of the data.
Page 171 1=On 0=Off There are 38 DIs in the meter, and the starting address is 0000H. The following query is to read the 4 DIs Status of address 1 of Acuvim II series meter. Query Table 5-8 Read 4 DIs Query Message...
Page 172 Table 5-9 Read 4 DIs Response Message DI1: bit0 DI2: bit1 DI3: bit2 DI4: bit3 Transaction Transaction Protocol Protocol Unit Length hi Length lo identifier hi identifier lo identifier hi identifier lo identifier Byte count Data The content of the data is, c.
Page 173 The message forces a single Relay either on or off. Any Relay that exists within the Acuvim II series meter can be forced to be either status (on or off ). The address of Relay starts at 0000H, and the meter has eight Relays.
Page 174 Function code 16 allows the user to modify the contents of a Multi-Register. The example below is a request to an Acuvim II series meter address 1 to Preset CT1 (500) and CT2 (5). CT1 data address is 1008H, and CT2 data address is 1009H.
Page 175 Data #of regs lo Users may refer to the sixth chapter “Communication” and get the details of Acuvim II series meter. When using Modbus/TCP function, it is best to set the Scan interval of the software to under 1000 ms.
Page 176 5.2.11 Webpage Browsing and Parameter Settings The Ethernet module supports HTTP protocol and has a Web Server function making the Acuvim II series meter accessible through Ethernet at anytime from anywhere. The Ethernet module supports IE Browser 6.0 and higher editions and the Webpage Settings only support ASCII characters.
Page 177 2. Module Status Webpage By selecting the "Module Status" link, users can view the status and change the settings of the Ethernet module. Fig 5-43...
Page 178 3. Settings Webpage By selecting the "Settings" link, users can access "Network Settings", "Mail Settings", "Webpage Settings", "Management" and "Password Setting". When accessing the "Settings" link, users will be prompted to enter a password. The default password is 12345678. a. “Password” Webpage Fig 5-44: “Password”...
Page 179 b. “Network Settings” Webpage Fig 5-45: “Network Settings” webpage. There are three sections for you to set: Ethernet setting, SNTP setting and SNMP trap setting. In Ethernet setting section, it supports two network setting modes: Manual or Auto. There are two port settings: HTTP port and Modbus-TCP port.
Page 180 Fig 5-45...
Page 181 Note: Mail Server part includes "SMTP Server", "User Name" and "Password". For the "SMTP Server" users can input either domain name such as "mail. accuenergy.com" or an IP address such as "222.128.6.73" which is from "mail. accuenergy.com" resolved. A user name and password will be required to log in.
Page 182 Fig 5-46...
Page 183 “Management" webpage Fig 5-48: "Management" webpage. Users can easily update the software online by selecting the updated file, which can be got from Accuenergy Corporation. The "Reboot NET module" option resets the module itself.When selecting "Load Default Setting", it will show as follows: IP Address:192.168.1.254...
Page 184 DNS Primary: 202.106.0.20 DNS Secondary: 202.106.196.115 MODBUS Port: 502 HTTP Port: 80 Fig 5-48...
Page 185 f. “Password Setting” Webpage Fig 5-49: “Password Setting” webpage.To change the password, users need to input the current password first. Fig 5-49...
Page 186 "Metering" webpage includes the data of real-time parameters for Acuvim II series meter. There are thirty nine parameters, such as Volts AN, I A, Watt A. "Energy" webpage includes the energy data for Acuvim II series meter. There are twenty-four parameters, such as Delivered kWh, kVAh.
Page 187 VB to VA. "Max and Min" webpage includes the max and min data of parameters for Acuvim II series meter. There are twenty-five parameters, such as Volts AN, I A , and Watt Total (Demand). "Alarm Record" webpage includes alarm records for Acuvim II series meter. There are sixteen records.
Page 188 5.2.13 SNTP Function Ethernet communication supports SNTP (Simple Network Time Protocol) protocol, so meters can get update time to Coordinated Universal Time (UTC). Please find the SNTP Settings – Network Settings by Internet Explorer. Fig 5-51...
Page 189: Profibus Module (Axm-Proi)
5.3 ProfiBus Module (AXM-PRO) 5.3.1 Introduction of PROFIBUS Technology PROFIBUS (Process Field bus) is an international field bus standard which is widely used in automation technology of manufactures and flow industry. It is a widely used, open digital communication system, which is suitable for high- speed, time-critical, and high reliability communications.
Page 190 module as well. * The PROFIBUS module can only be used as slave in PROFIBUS network. Its slave address ranges from 0 to 126, which can only be set by the panel. If the address is changed, it will take effect immediately. * The PROFIBUS module’s baud rate can be adaptive between 9.6Kbps to 12Mbps in PROFIBUS network.
Page 191 5.3.3 Appearance and Dimensions 90mm 55.6mm (Top View) (Bottom View)
Page 192 22 mm (Side View) Fig 5-52 5.3.4 Installation Method Fig 5-53 PROFIBUS is linked to Acuvim II meter by communication plug. It can also be linked to other extended modules such as IO modules. 1. Insert the installation clips to the counterpart of Acuvim II meter, and then press the PROFIBUS module lightly, so linking is established.
Page 193 5.3.5 Definition of DP Interface The PROFIBUS module uses standard 9-pin D-type connector to access PROFIBUS network. The mechanical and electrical characteristics of connector are consistent with the requirements of IEC 807-3. The connector of PROFIBUS is a socket, and the counterpart connector of cable is a plug. Connector pins are distributed as follows: Table 5-16 Pins...
Page 194 STATION 3 STATION 4 STATION 1 STATION 2 DGND DGND Fig 5-54 Connection of many DP stations The bus terminal is composed of three resistors and connection wire, where Vp is the supply positive voltage and DGND is the Digital Ground. When the bus is idle, the bus terminal makes the data P level higher than data N, so the bus’s idle signal is always 1.
Page 195 5.3.8 Address Setting The PROFIBUS module can only be used as a slave in the PROFIBUS network. Its slave address ranges from 0 to 126, which can only be set by the front panel of the meter (in SYS sub menu of Acuvim II Setting menu). If the address is changed, it will take effect immediately.
Page 196 5.3.10 GSD Files A PROFIBUS-DP master can exchange data with various slave devices. In order to indentify a slave device, it is necessary to obtain the technical data of the device itself. The file where the data is described is called Device Description Data File (GSD).
Page 197 2. There is a specific relationship between numerical value in register of Acuvim II meter and the real physical value. 3. Different parameters may have different data length and data type. These three points are also suitable for the PROFIBUS-DP protocol in PROFIBUS module.
Page 198 Response Below is the response that a slave device would send to a master. Table 5-18 Frame Bytes Caption Byte1 The channel of inquiry frame Byte2 Byte3 byte count Byte4 coil status Byte5~32 The coils in the response message are packed as one coil per bit of the data field. Status is indicated as 1=ON and 0=OFF.
Page 199 5.3.13 Format of function code 05H The message with function code (05H) in MODBUS-RTU forces a single relay either on or off. The data value FFOOH will set the relay on and the value 0000H will turn it off. All other values are invalid and will not affect that relay. In PROFIBUS-DP, the format of function code 05H is defined as follows: Query Table 5-20...
Page 200 Example: setting Relay2 on. Table 5-22 Query Byte1 Byte2 Byte3 Byte4 Byte5 Byte6 Byte7~32 Response Byte1 Byte2 Byte3 Byte4 Byte5 Byte6 Byte7~32 5.3.14 Format of function code 02H Function code 02H is used to read DI status in MODBUS-RTU. In PROFIBUS-DP, the format of function code 02H is defined as follows: Query Table 5-23...
Page 201 Byte5 inputs status2 (or 0) Byte6 inputs status3 (or 0) Byte7 inputs status4 (or 0) Byte8~32 The digital inputs in the response message are packed as one input per bit of the data field. Status is indicated as 1=ON; 0=OFF. The LSB of the first data byte contains the input addressed in the query.
Page 202 5.3.15 Format of function code 03H This function code is used in MODBUS-RTU to read the contents of a continuous block of holding registers in Acuvim II meter. In PROFIBUS-DP, the format of function code 03H is defined as follows: Table 5-26 Query Frame Bytes...
Page 203 with the binary contents correctly justified with each byte. For each register, the first byte contains the high order bits and the second contains the low order bits. It is important to note: The response has a 16-word frame. so the maximum “quantity of registers”...
Page 204 Table 5-29 Query Frame Bytes Caption Byte1 Byte2 Byte3 starting address high byte Byte4 starting address low byte Byte5 quantity of registers high byte Byte6 quantity of registers low byte Byte7 byte count Byte8 register value 1 high byte Byte9 register value 1 low byte Byte10 register value 2 high byte...
Page 205 Table 5-30 Frame Bytes Caption Byte1 Byte2 Byte3 starting address high byte Byte4 starting address low byte Byte5 quantity of registers high byte Byte6 quantity of registers low byte Byte7~32 Example: presetting import active enengy (EP_imp) to 17807783.3Kwh. Based on the relationship between the register value and the physical value, we can get that the register value in hex is 0A9D4089H.
Page 206 Example Projects To facilitate your understanding of the PROFIBUS module, we have developed a PLC-based DEMO engineering application program. Please read DEMO procedure documentation for the specific information. This DEMO is available upon request, please call Technical Support. 5.3.17 32 Word Output Interface The 32 word output interface is fixed parameter.
Page 207: Rs485 Module (Axm-Rs485)
5.4.2 Function Description of RS485 module AXM-RS485 module uses RS485 serial communication and the Modbus-RTU protocol, just like the onboard RS485 port of the Acuvim II series meter. It provides a second RS485 port for serial communication, and it can be working with the onboard RS485 serial communication simultaneously.
Page 208 • Use good quality shielded twisted pair cable, AWG22 (0.5mm ) or higher. • The overall length of the RS485 cable connecting all devices should not exceed 1200m (4000ft). • Every A(+) should be connected to A(+), B(-) to B(-), or it will influence the network, or even damage the communication interface.
Page 209 (bottom View) Fig 5-56 5.4.4 Installation Method Fig 5-57 The RS485 module is linked to the meter by a communication plug. It also can be linked to other extended modules. 1.Insert the installation clips to the counterpart of the meter, and then press the RS485 module lightly, so linking is established.
Page 210 The shield of each segment of the RS485 cable must be connected to the ground at one end only. Fig 5-58 The default baud rate of RS485 module is 38400 bps. Users can change the baud rate in system settings S03 of the Acuvim II series meter.
Page 211 The data format is start bit + 8n data bit + parity + stop bit. NON1, NON2, odd and even can be selected for parity mode on S32 of Setting page of Acuvim IIR and Acuvim IIE meter (Not support Acuvim II meter). NON1 represents non-parity, single stop bit;...
Page 212: Bacnetmodule(Axm-Bacnet)
Acuvim II Series Power Meter's BACnet IP and BACnet MS/TP has 56 predefined BACnet objects that let you track up to 56 measurements. The Acuvim II Series Power Meter has native BACnet/IP that lets it act as a BACnet server in any BACnet application. The Acuvim II Series Power Meter’s BACnet IP also comes with a Web interface that is very easy to browse the parameter data by using a standard browser.
Page 213 Present_Value, watt, tot (value in watts) For more detailed information, visit the BACnet website at www.bacnet.org. 5.5.4 Using the Acuvim II Series Power Meter’s BACnet Serial and Ethernet versions There are a couple of different serial and Ethernet based-versions of BACnet.
Page 214 Table 5-32 BACnet MS/TP facts Network Type Serial RS-485 with a Master/Slave Token Passing protocol Topology Line topology Any cable with at least 3 conductors can be used. Distance Installation : between nodes depends on baud rate. Speed 9600 kbit/s,19200 kbit/s, 38400 kbit/s and 76800 kbit/s max.
Page 215 The BACnet module is linked to the Acuvim II meter by a communication plug. It can also be linked to other extended modules like IO modules. 1) Insert the installation clips to the counterpart of the meter, and then press the BACnet module lightly, so linking is established.
Page 216 Table 5-34 Script Content Tranceive Data+ Tranceive Data- Receive Data+ Not connected Not connected Receive Data- Not connected Not connected The BACnet MS/TP module uses a standard 485 connector to access the network. Item Network Status LED Module Status LED BACnet connector BACnet Connector Table 5-35...
Page 217 the keys on the meter front. The following process shows how to configure BACnet module settings by using the front panel: The initial structure module parameter steps: a) Pressing “H” key and “V/A” key simultaneously on the meter will go to the menu selecting mode.
Page 218 Fig 5-63 Fig 5-64 c) Press "V/A" key to go to the System setting page. The initial page is S01 the meter address page. Press “P” key or “E” key to move to S34 page .Then press "V/ A" key to go to the BACnet protocol enable setting page. Press “P” key or “E” key to select configuration mode, press “V/A”...
Page 219 Fig 5-65 2) BACnet/IP module set BACnet/IP Module's default settings are as follows: IP Address (0.0.0.0);Subnet Mask (0.0.0.0);Gateway (0.0.0.0); DNS1 (0.0.0.0); DNS2 (0.0.0.0); This information can be found by using the keys on the meter front. The following process shows how to configure BACnet module settings by using the front panel: a).
Page 220 Fig 5-66 b). Press “P” key or “E” key to move the cursor to "Setting". Press “V/A” key to go to the meter parameter setting mode. Device address page is the first page of “Setting” mode. It shows the Modbus address of the device for several seconds, and then the screen goes to Access Code page.
Page 221 Fig 5-68 Fig 5-69 c). Set configuration mode in the first setting page. “AUTO” means that users configure module settings with DHCP protocol while “MANU” means that users configure module settings with manual setting. Press “V/A” key, to go to the setting state and the area pointed out in Fig 5-77 will flash.
Page 222 Note: If you select the “AUTO” mode, please go to step 10 directly and reset module. Wait until the reset is finished and find the new IP address in the following step. Fig 5-70 d). Set IP Address in the second setting page, such as 192.168.1.100 as shown below.
Page 223 Fig 5-71 e). Set Subnet Mask in the third setting page, such as 255.255.255.0. Press “V/A” key to go to the setting page. Users may set the parameters in the area pointed out in Fig 5-79. The cursor starts at the first digit. After setting the Subnet Mask, press the "V/A"...
Page 224 f ). Set Gateway in the fourth setting page, such as 192.168.1.1. Press the "V/ A" key to go to the setting page. Users may set the parameters pointed out in Fig 5-80. The cursor starts at the first digit. After setting the Gateway, press the "V/ A"...
Page 225 Fig 5-74 h). Set DNS Secondary Server in the sixth setting page, such as 202.106.196.115. Press the "V/A" key to go to the setting page. Users may set the parameters pointed out in Fig 5-82. The cursor starts at the first digit. After setting the DNS Secondary Server, press the "V/A"...
Page 226 i). Set BACnet/IP port in the seventh setting page, such as 47808. Press the "V/ A" key to go to the setting page. Users may set the parameters pointed out in Fig 5-83. The cursor starts at the first digit. The BACnet/IP port’s default value is 47808, and the user defined range of port is 1~65535.
Page 227 Fig 5-77 k). After configuring AXM-BACnet settings completely, press “H” key and “V/ A” key simultaneously to return to menu selecting mode. 3). BACnet MS/TP module set BACnet MS/TP Module's default settings are as follows: MAC Addr(0); BACnet Bps(9600); Max Info Pram(1). This information can be found by using the keys on the meter front.
Page 228 Fig 5-78 b). Press “P” key or “E” key to move the cursor to "Setting". Press “V/A” key to go to the meter parameter setting mode. Device address page is the first page of “Setting” mode. It shows the Modbus address of the device for several seconds, and then the screen goes to Access Code page.
Page 229 Fig 5-80 Fig 5-81 c). Set module address in the first setting page. Press the "V/A" key to go to the setting page. Users may set the parameters pointed out in Fig 5-89. The cursor starts at the first digit. The BACnet MS/TP Address’s default value is 0, and the user defined range of address is 0~127.
Page 230 Fig 5-82 d). Set Baud Rate in the second setting page, such as 38400.The module can support the baud rate such as 9600,19200,38400,76800. Press the "V/A" key to go to the setting page. Users may set the parameters pointed out in Fig 5-90. After setting the BACnet MS/TP Baud rate, press the "V/A"...
Page 231 e). Set MAX INFO FRAM in the third setting page, such as 1. The BACnet MS/ TP MAX INFO FRAM default value is 1, and the user defined range of MAX INFO FRAM is 1~255. Users may set the parameters pointed out in Fig 5-91. After setting the BACnet MS/TP MAX INFO FRAM, press the "V/A"...
Page 232 5.5.6 Acuvim II Series Power Meter’s BACnet Objects The Acuvim II Series Power Meter's BACnet IP has 56 predefined objects of electrical measurements. No programming or mapping is necessary to use the BACnet objects. The object’s names easily identify the measurements they contain.
Page 233 Object ObjectType Instance Name Value Descriptor DataType AnalogValue Uab_rms FLOAT ADI6 Voltage A-B AnalogValue Ubc_rms FLOAT ADI7 Voltage B-C AnalogValue Uca_rms FLOAT ADI8 Voltage C-A AnalogValue Ulag_rms FLOAT ADI9 Line Voltage Avg AnalogValue Ia_rms FLOAT ADI10 Current A AnalogValue Ib_rms FLOAT ADI11 Current B...
Page 234 Object ObjectType Instance Name Value Descriptor DataType AnalogValue Active_Energy_IMP UINT32 ADI40 Active_Energy_ IMP AnalogValue Active_Energy_EXP UINT32 ADI41 Active_Energy_EXP AnalogValue Reactive_Energy_IMP UINT32 ADI42 Reactive_Energy_ IMP AnalogValue Reactice_Energy_EXP UINT32 ADI43 Reactice_Energy_EXP AnalogValue Active_Energy_TOTAL UINT32 ADI44 Active_Energy_TOTAL AnalogValue Active_Energy_NET SINT32 ADI45 Active_Energy_NET AnalogValue Reactive_Energy_TOTAL UINT32 ADI46...
Page 235 Fig 5-86 5) Click the Network interface, you will see network information. Fig 5-87...
Page 236 6) Click the Network configuration, you will see network configure page, it is something about the IP setting parameter. Fig 5-88 7) Click the Network statistics, you will see network status page, it is something about the module network parameter status.
Page 237 Fig 5-89 Fig 5-90...
Page 238 8) At the main page. Click the Paramater data, you will see all the parameter data, it is real time parameter data for communication. Fig 5-91...
Page 239: Chapter 6 Communication
Chapter 6 Communication 6.1 Modbus Protocol Introduction 6.2 Communication Format 6.3 Data Address Table and Application Details 6.3.1 System Parameter Setting 6.3.2 System Status Parameter 6.3.3 Date and Time Table 6.3.4 Over/Under Limit Alarming Setting 6.3.5 I/O Modules Settings 6.3.6 100ms Refresh Metering Parameter 6.3.7 Metering Parameter Address Table 6.3.8 Data Logging 6.3.9 Time of use...
Page 240 6.1 Modbus Protocol Introduction Modbus RTU protocol is used for communication in Acuvim II series meters. Data format and error check methods are defined in Modbus protocol. The half duplex query and respond mode is adopted in Modbus protocol. There is only one master device in the communication network.
Page 241 addresses are in the range of 0~247 decimal. A master addresses a slave by placing the slave address in the address field of the message. When the slave sends its response, it places its own address in this address field of the response to let the master know which slave is responding.
Page 242 in the data field, and the data to be written into the registers. If no error occurs, the data field of a response from a slave to a master contains the data requested. If an error occurs, the field contains an exception code that the master application can use to determine the next action to be taken.
Page 243 bytes of the message have been applied,the final contents of the register, which should exchange the high-byte and the low-byte, is the CRC value. When the CRC is appended to the message, the low-order byte is appended first, followed by the high-order byte. 6.2 Communication Format Explanation of frame Table 6-3 Explanation of frame...
Page 244 2. Read Status of DI Function Code 02 1=On 0=Off DI1’s address is 0000H, DI2’s address is 0001H, and so on. The following query is to read the Status of 4 DIs of Acuvim II series meter with communication address 17.
Page 245 This function allows the master to obtain the measurement results from the Acuvim II series meter. Table 6-8 is an example of reading the measured data (F, V1 and V2) from slave device number 17, the data address of F is 4000H, 4001H;...
Page 246 The data value FF00H will set the relay on and the value 0000H will turn it off; all other values are invalid and will not affect that relay. The example below is a request to the Acuvim II series meter with the address of 17 to turn on Relay1.
Page 247 Acuvim II series meter can have their contents changed by this message. The example below is a request to an Acuvim II series meter with the address of 17 to preset Ep_imp as "17807783.3KWh", while its HEX value is 0A9D4089H.
Page 248 6.3 Data Address Table and Application Details There are several rules to follow in using the meter: 1. Data type: “bit” refers to binary. “word” refers to 16-bit unsigned integer using one data address and 2 bytes of memory, it varies from 0 to 65535. “int”...
Page 249 relationship listed below to count primary value, the value of CT2 should not be 333, but 1. 3)When you select 100mv/50Hz,or 120mv/60Hz Rope-CT,the value of CT2 is 100,and using relationship listed below to count primary value,the value of CT2 should not be 100,but 1; 4)When you select 80/100/200 mA CT,the value of CT2 is 80, 100 or 200, and using relationship listed below to count primary value,the value of CT2 should not be 80, 100 or 200, but 1.
Page 250 Parameters Relationship Unit Format code Total odd HD HDo=(Rx/10000) X 100% No unit Total even HD HDe=(Rx/10000) X 100% No unit Crest factor CF=Rx/1000 No unit K factor KF=Rx/10 No unit THFF THFF=(Rx/10000) X 100% No unit Phase angle Phase angle=Rx/10 Degree Important Note: Regions from “System parameters settings”...
Page 251 Table 6-15 Data Address Parameter Default Range Property type 0 : 50Hz 1 : 60Hz 0FFDH Frequency Word 2: 400Hz First communication 0:MODBUS Protocol 0FFEH Word Protocol 1:DNP3.0 Protocol 0: E VEN 1: odd 2:NON2 0FFFH Parity Setting1 word 3:NON1 1000H Password 0~9999 word...
Page 252 Data Address Parameter Default Range Property type 0: Positive 1012H Current I1 direction word 1: Negative 0: Positive 1013H Current I2 direction word 1: Negative 0: Positive 1014H Current I3 direction word 1: Negative 1015H VAR/PF convention 0: IEC, 1: IEEE word 1016H Energy clear Only 1 works...
Page 253 with the user, and if the three-phase signals are added, then n is 3. U and I generally equal to user settings PT2, CT2, ie, rated voltage and tated current . 3)0x1017H: When selecting 400Hz type,only support full-wave. 6.3.2 System Status Parameters “System status”...
Page 254 Format Data Address Parameter Range Property code type 0: EVEN 1: odd 2:NON2 1030H Parity Setting2 word 3:NON1 Communication 1031H 1~247 word address2 0: no alarming record Alarming group 1032H 1~16: last alarming record word number group number 0: no SOE record 1033H SOE group number 1~20: last SOE group...
Page 255 Note: 1) Please refer to Chapter 3 and Chapter 4 for more details about parameter settings. 2) When 1038H is 2, second communicaton is set to MESH, you should set 9600bps and NON1 for the second communication. When 1038H is 1, second communication protocol is set to BACnet protocol, while second communication should select BACnet module.
Page 256 Global alarming settings Table 6-18 Address Parameter Range Data type Property 1046H Global alarming enable 0:disable;1:enable word 1047H Alarming flash enable 0:disable;1:enable word 0~65535 Bit0:channel 1 Alarming channel enable 1:enable; 0:disable 1048H word setting Bit1: channel 2 …… Bit15: channel 16 0~255 Bit0: first logic switch Logic “And ”...
Page 257 Format Data Address Parameter Range Property code type 1: greater than; 2: First group: comparison 104FH equal to; 3: less word mode than Related with 1050H First group: setpoint value F10~F18 word parameters 1051H First group: delay 0~3000(*10ms) word 0:none, 1052H First group: output to relay word...
Page 258: I/O Modules Settings
Setting Setting Setting Alarming object Alarming object Alarming object value value value THD_V1(V1 or THD_V2(V2 or THD_V3(V3 or V23) V12) V31) Average THD_V THD_I1 THD_ I2 Average THD_ I3 AI1 sampling value THD_I AI2 sampling AI3 sampling AI4 sampling value value value Active power...
Page 259 AXM-IO11 Table 6-21 Address Parameter Default Range Data type Property Bit0: DI1, Bit1: DI2 Bit2: DI3, Bit3: DI4 109EH DI1~6 type word Bit4: DI5, Bit5: DI6 0: DI,1: pulse counter 109FH DI pulse constant 1~65535 word Working mode of relay 1 0: control output, 10A0H word...
Page 260 AXM-IO31 Table 6-23 Address Parameter Default Range Data type Property Bit0: DI11,Bit1: DI12, 10AAH DI11~14 type Bit2: DI13, Bit3: DI14 word 0: DI, 1: pulse counter 10ABH DI pulse constant 1~65535 word Working mode of relay 3 0: control output, 10ACH word and 4...
Page 261 AXM-IO22 Table 6-25 Address Parameter Default Range Data type Property Bit0: DI21, Bit1: DI22, 10B5H DI21~24 type Bit2: DI23, Bit3: DI24 word 0: DI, 1: pulse counter 10B6H DI pulse constant 1~65535 word W o r k i n g m o d e o f 0: pulse output, 10B7H word...
Page 262 AO transforming select Table 6-27 Address Parameter Default Range Data type Property AO1 transforming 10C2H Refer to following table word parameter AO2 transforming 10C3H Refer to following table word parameter AO3 transforming 10C4H Refer to following table word parameter AO4 transforming 10C5H Refer to following table word...
Page 263 Table 6-29 Address Parameter Default Range Data type Property AO1 Gradient 1: 1 Gradient Number Selection of 10D0H 2: 2 Gradient input/output transfer 3: 3 Gradient curve AO1 following value 10D1H range setting start Please see Note point AO1 following value 10D2H range setting point 2 AO1 following value...
Page 264 When number is 1, only AO following value range setting start point, AO following value range setting end point, AO1 output range setting start point and AO1 output range setting end point should be set. When number is 2, only AO following value range setting start point, AO1 following value range setting point 2, AO following value range setting end point, AO1 output range setting start point , AO1 output range setting point 2 and AO1 output range setting end point should be set.
Page 265 Current I1, I2, I3 and average current: 0~10A, real setting value is 0~10000 Power Pa, Pb and Pc: -4800~4800W, real setting value is -4800~4800 System power: -14400~14400W, real setting value is -14400~14400. Reactive power Qa, Qb and Qc: -4800~4800 Var, real setting value is-4800~4800. System reactive power: -14400~14400 Var.
Page 266: 100Ms Refresh Metering Parameter
6.3.6 100ms Refresh Metering Parameter Table 6-30 Data Address Parameter Code Relationship Property type 3000H~3001H Frequency float 3002H~3003H Phase voltage V1 U=Rx×(PT1/PT2) float 3004H~3005H Phase voltage V2 U=Rx×(PT1/PT2) float 3006H~3007H Phase voltage V3 U=Rx×(PT1/PT2) float 3008H~3009H Average voltage Vavg U=Rx×(PT1/PT2) float 300AH~300BH Line voltage V12 U=Rx×(PT1/PT2)
Page 267: Metering Parameter Address Table
In secondary mode, the relationship between the numerical value in the register and the real physical value is shown in the following table. (Rx is the numerical value in register of Acuvim II series meter) Function code: 03H for reading.
Page 268 Table 6-31 Data Address Parameter Code Relationship Property type 4000H~4001H Frequency F = Rx float 4002H~4003H Phase voltage V1 U=Rx×(PT1/PT2) float 4004H~4005H Phase voltage V2 U=Rx×(PT1/PT2) float 4006H~4007H Phase voltage V3 U=Rx×(PT1/PT2) float 4008H~4009H Average voltage Vavg U=Rx×(PT1/PT2) float 400AH~400BH Line voltage V12 U=Rx×(PT1/PT2) float 400CH~400DH Line voltage V23...
Page 269 Data Address Parameter Code Relationship Property type Phase C apparent 4030H~4031H S=Rx×(PT1/PT2)×(CT1/CT2) float power Sc System apparent 4032H~4033H S=Rx×(PT1/PT2)×(CT1/CT2) float power Ssum Phase A power factor 4034H~4035H PF = Rx float Phase B power factor 4036H~4037H PF = Rx float Phase C power factor 4038H~4039H PF = Rx...
Page 270 refer to F7, F8, and F9 for more details about the relationship between numerical value in the register and the real physical value. Table 6-32 Address Parameter Code Range Data type Property 4048H~4049H Energy IMP F4/F7 0~999999999 dword 404AH~404BH Energy EXP F4/F7 0~999999999 dword...
Page 271 463AH~463BH Phase B Apparent energy F6/F9 0-999999999 dword 463CH~463DH Phase C Apparent energy F6/F9 0-999999999 dword On1 number of electric power Sequence with system 463EH~466DH electricity+Split phase 0-999999999 dword electricity On 2 number of electric power Sequence with system 466EH~469DH electricity+Split phase 0-999999999 dword...
Page 272 Table 6-33 Address Parameter Code Range Data type Property The following are the THD of voltage and current 405AH THD_V1 of V1(V12) >=0 word 405BH THD_V1 of V2(V31) >=0 word 405CH THD_V1 of V3(V23) >=0 word 405DH Average THD_V >=0 word 405EH THD_I1...
Page 273 Address Parameter Code Range Data type Property 40E7H Even HD of I1 >=0 word 40E8H K Factor of I1 0~65535 word 40E9H~4109H Parameters of I2 Same as I1 word Harmonics of I2 4580H~459FH >=0 word (the 32 to 63 410AH~412AH Parameters of I3 Same as I1 word Harmonics of I3...
Page 274 Address Parameter Code Range Data type Property Time stamp: yyyy:mm: 415AH~415FH time dd:hh:mm:ss 4160H MAX of I1 -32768~32767 Time stamp: yyyy:mm: 4161H~4166H time dd:hh:mm:ss 4167H MAX of I2 -32768~32767 Time stamp: yyyy:mm: 4168H~416DH time dd:hh:mm:ss 416EH MAX of I3 -32768~32767 Time stamp: yyyy:mm: 416FH~4174H time...
Page 275 Address Parameter Code Range Data type Property Time stamp: yyyy:mm: 41A0H~41A5H time dd:hh:mm:ss MAX of apparent power 41A6H -32768~32767 demand Time stamp: yyyy:mm: 41A7H~41ACH time dd:hh:mm:ss MAX of voltage 41ADH -32768~32767 unbalance factor Time stamp: yyyy:mm: 41AEH~41B3H time dd:hh:mm:ss M A X o f c u r r e n t 41B4H -32768~32767 unbalance factor...
Page 276 Note: The MAX and MIN Frequency value should use word data type(0~65535). Sequence component U1 (U12), I1 are consisting of real part and complex part. They have positive sequence, negative sequence and zero sequence. Data type is “int”. Function code: 03H for reading. Table 6-35 Data Address...
Page 277 phase angle of V3 to V1 V1/ V3(3$4) 42A1H 0~3600 word phase angle of V31 to V12 V12/V31 (3$3) phase angle of I1 to V1 V1/ I1(3$4) 42A2H 0~3600 word phase angle of I1 to V12 V12/I1 (3$3) phase angle of I2 to V1 V1/ I2(3$4) 42A3H 0~3600...
Page 278 First group: Time stamp: 42ACH~42B2H word yyyy:mm:dd:hh:mm:ss:ms 42B3H~42BCH Second group Same as the first group 42BDH~42C6H Third group Same as the first group 42C7H~42D0H Fourth group Same as the first group 42D1H~42DAH Fifth group Same as the first group 42DBH~42E4H Sixth group Same as the first group 42E5H~42EEH...
Page 279 Address Parameter Code Range Data type Property 4353H~4354H DI6 pulse counter number 0~4294967295 dword AXM-IO21 4355H~4356H DI7 pulse counter number 0~4294967295 dword 4357H~4358H DI8 pulse counter number 0~4294967295 dword 4359H~435AH DI9 pulse counter number 0~4294967295 dword 435BH~435CH DI10 pulse counter number 0~4294967295 dword AXM-IO31...
Page 280 Table 6-39 Address Parameter Code Range Data type Property 4385H AI1 sampling value 0~4095 word 4386H AI2 sampling value 0~4095 word 4387H AI3 sampling value 0~4095 word 4388H AI4 sampling value 0~4095 word AO output The output of AO is the actual value of output. There are 2 output options for AO - V or mA.
Page 281 0:none; 1:AXM-IO11; 2:AXM-IO21; 4439H I/O module of SOE 3:AXM-IO31; word 4:AXM-IO12; 5:AXM-IO22; 6:AXM-IO32 Current demand Include real-time current demand, the maximum current demand and time of occurance. Function code: 03H for reading. Table 6-42 Address Parameter Code Range Data type Property 4600H-4601H Phase A current demand I=Rx×(CT1/CT2)
Page 282 DI Status Current DI status, if related I/O module isn’t connected, the DI status will be set to 0. Function code: 02H for reading. Table 6-43 Address Parameter Range Data type AXM-IO11 0000H 1=ON,0=OFF 0001H 1=ON,0=OFF 0002H 1=ON,0=OFF 0003H 1=ON,0=OFF 0004H 1=ON,0=OFF 0005H...
Page 283: Data Logging
Address Parameter Range Data type 0016H DI23 1=ON,0=OFF 0017H DI24 1=ON,0=OFF AXM-IO32 0018H DI25 1=ON,0=OFF 0019H DI26 1=ON,0=OFF 001AH DI27 1=ON,0=OFF 001BH DI28 1=ON,0=OFF Relay status Function code: 01H for reading, 05H for controlling output. Table 6-44 Address Parameter Range Data type AXM-IO11 0000H...
Page 284 parameters occupy two registers, to supplement this, the programmable settings for the historical logs contain a list of descriptors. Each descriptor lists the number of Modbus registers for the specified parameter. By combining these two lists, the historical log record can be interpreted. For example: Registers 4002H and 4003H are programmed to be recorded by the historical log.
Page 285 Registers: The number of registers to log in the record range from {0-117}. The size of the record in memory is [12 + (Registers x 2)]. Sectors: The number of memory sectors allocated to this log. Each sector is 64kb in size. 100 sectors are available for allocation among the three historical logs.
Page 286 Registers: 1177H– 11B1H Size: 1 byte per item, 117 bytes (59 registers) While the register list describes what to log, the Item descriptor list describes how to interpret that information. Each descriptor describes how many Modbus addresses are used to describe a parameter. Either 1 or 2 addresses will be used for each parameter.
Page 287 Registers 11B3H-11B5H(start time) 11B6H-11B8H(end time) Size 2 Registers Byte value month year hour second minute Log Status Block The Log Status Block describes the current status of the log in question. Table 6-47 Address Parameter Range Data type Property 6100H~6101H Max Records 0~468104 dword...
Page 288 Log Retrieval Block The log retrieval block consists of 2 parts: the header and the window. The header is used to verify the data shown within the requested log window. The window is a sliding block of data that can be used to access any record in the specified log.
Page 289 Status: The status of the current window. Since the time to prepare a window may exceed an acceptable Modbus delay (1 second), this acts as a ready status flag to notify when the window is ready for retrieval. When this value indicates that the window is not ready, the data in the window should be ignored.
Page 290 Records" field from the last reading before retrieving the information and reading the window. If the current "Used Records" field is greater than the "Used Records" field from the last reading and if the "Offset" field is less than the difference between the current and previous "Used Records"...
Page 291 • No new records are recorded to the log during the log retrieval process. a) Data logging settings Now set the data log 1 according to the assumptions: 1. Set the data log with VAN, VBN, VCN, here we should set their modbus address 0x4002,0x4003,0x4004,0x4005,0x4006 and 0x4007 to 0x1102, 0x1103, 0x1104, 0x1105, 0x1106 and 0x1107.
Page 292 • Compute the next expected record offset by adding Records Per Window and go to step 2. • If there are no remaining records after the current record window, stop reading. 6.3.9 Time of use Data address of TOU energy The data address save the parameter of energy, which includes Data address of last month TOU energy, Data address of current month TOU energy, Data address of TOU parameter setting and Data address of TOU default parameter.
Page 293 Table 6-49 Type of address parameter range Data type access Current month accumulation TOU energy 7200H~7201H 0~999999999 Dword Ep_imp(sharp) 7202H~7203H 0~999999999 Dword Ep_exp(sharp) Eq_im(sharp) 7204H~7205H 0~999999999 Dword Eq_exp(sharp) 7206H~7207H 0~999999999 Dword Es(sharp) 7208H~7209H 0~999999999 Dword 720AH~720BH 0~999999999 Dword Ep_imp(peak) 720CH~720DH 0~999999999 Dword Ep_exp(peak)
Page 294 Type of address parameter range Data type access Current month accumulation TOU energy 7232H~7233H 0~999999999 Dword Ep_imp(sharp) 7234H~7235H 0~999999999 Dword Ep_exp(sharp) Eq_imp(sharp) 7236H~7237H 0~999999999 Dword Eq_exp(sharp) 7238H~7239H 0~999999999 Dword Es(sharp) 723AH~723BH 0~999999999 Dword 723CH~723DH 0~999999999 Dword Ep_imp(peak) 723EH~723FH 0~999999999 Dword Ep_exp(peak) 7240H~7241H Eq_imp(peak)
Page 295 Table 6-50 Type of address parameter range Data type access Current month TOU energy 7300H~7301H Ep_imp(sharp) 0~999999999 Dword 7302H~7303H Ep_exp(sharp) 0~999999999 Dword 7304H~7305H Eq_im(sharp) 0~999999999 Dword 7306H~7307H Eq_exp(sharp) 0~999999999 Dword 7308H~7309H Es(sharp) 0~999999999 Dword 730AH~730BH Ep_imp(peak) 0~999999999 Dword 730CH~730DH Ep_exp(peak) 0~999999999 Dword 730EH~730FH...
Page 296 Type of address parameter range Data type access Prior month TOU energy 7332H~7333H Ep_imp(sharp) 0~999999999 Dword 7334H~7335H Ep_exp(sharp) 0~999999999 Dword 7336H~7337H Eq_imp(sharp) 0~999999999 Dword 7338H~7339H Eq_exp(sharp) 0~999999999 Dword 733AH~733BH Es(sharp) 0~999999999 Dword 733CH~733DH Ep_imp(peak) 0~999999999 Dword 733EH~733FH Ep_exp(peak) 0~999999999 Dword 7340H~7341H Eq_imp(peak) 0~999999999...
Page 297 The address area include the max of Ep_imp, Ep_exp, Eq_im, Eq_exp, Es, Current demand and time stamp, When tariff setting parameter is sharp, peak, valley and normal. Function: 03H Read. Table 6-51 Type Data Address Parameter Range type access Max of Ep_imp (sharp) demand and time 7500H~7503H stamp(format: power;...
Page 298 Type Data Address Parameter Range type access Max of Ep_exp(valley) demand and time 7544H~7547H -32768~32767 Int stamp Max of Eq_im(valley) demand and time 7548H~754BH -32768~32767 Int stamp Max of Eq_exp(valley) demand and time 754CH~754FH -32768~32767 Int stamp 7550H~7553H Max of Es(valley) demand and time stamp -32768~32767 Int 7554H~7557H Max of Ia (valley)demand and time stamp -32768~32767 Int...
Page 299 The address area include Daylight saving time(DST) setting. Function: 03H Read, 10H Preset. Table 6-52 Data Type of Address Parameter Range type access 0: disable 7700H DST enable Word 1: enable 0: format 1 7701H DST format Word 1: format 2 Format 1 7702H DST Start Mon...
Page 300 Data Type of Address Parameter Range type access 7714H DST Ending First few weeks Word 7715H DST Ending Hour 0~23 Word 7716H DST Ending Min 0~59 Word 7717H DST Ending Adjust time (Unit: Min) 1~120 Default: 60 Word Data address of TOU parameter setting includes basis parameter of TOU, time zone setting parameter of TOU, time table setting parameter of TOU and holiday setting parameter of TOU.
Page 301 Type of Address Parameter Range Data type access TOU auto reset fixed 780CH 0~59 Word date:second (default is 0) TOU auto reset fixed date: 780DH 0~59 Word second (default is 0) 0: the setting of parameter is correct; 1: tariff setting error; 2: schedule setting error;...
Page 302 Type of Address Parameter Range Data type access data and Season table Of the 7835H~7837H word Season data and Season tableOf the 7838H~783AH word Season data and Season tableOf the 783BH~783DH word Season data and Season tableOf the 783EH~7840H word Season data and Season tableOf the 7841H~7843H...
Page 303 Type of Address Parameter Range Data type access Seagment and Tariff 7865H~7867H word Number of the 1 schedule Seagment and Tariff 7868H~786AH word Number of the 1 schedule Seagment and Tariff 786BH~786DH word Number of the 1 schedule From 1 to 14 Segment The same as...
Page 304 Type of Address Parameter Range Data type access From 1 to 14 Segment The same as 7A12H~7A3BH and Tariff Number of the 12 word schedule schedule From 1 to 14 Segment The same as 7A3CH~7A65H and Tariff Number of the 13 word schedule schedule...
Page 305 Type of Address Parameter Range Data type access data and the schedule Of the 7AB7H~7AB9H word holiday data and the schedule Of the 7ABAH~7ABCH word holiday data and the schedule Of the 7ABDH~7ABFH word holiday data and the schedule Of the 7AC0H~7AC2H word holiday...
Page 306 Type of Address Parameter Range Data type access 7AEAH Holiday setting enable word 7AEBH Start year holiday setting word 7AECH End year holiday setting word The address area include ten years holiday setting, Function: 03H Read 10H Preset Table 6-54 Data address of ten years holiday The 1 year Holiday address Function: 03H Read 10H Preset The 1...
Page 307 7B3FH~7B41H The 22 holiday and schedule word 7B42H~7B44H The 23 holiday and schedule word 7B45H~7B47H The 24 holiday and schedule word 7B48H~7B4AH The 25 holiday and schedule word 7B4BH~7B4DH The 26 holiday and schedule word 7B4EH~7B50H The 27 holiday and schedule word 7B51H~7B53H The 28...
Page 308 7B95H~7B97H The 20 holiday and schedule word 7B98H~7B9AH The 21 holiday and schedule word 7B9BH~7B9DH The 22 holiday and schedule word 7B9EH~7BA0H The 23 holiday and schedule word 7BA1H~7BA3H The 24 holiday and schedule word 7BA4H~7BA6H The 25 holiday and schedule word 7BA7H~7BA9H The 26...
Page 309 7BEBH~7BEDH The 18 holiday and schedule word 7BEEH~7BF0H The 19 holiday and schedule word 7BF1H~7BF3H The 20 holiday and schedule word 7BF4H~7BF6H The 21 holiday and schedule word 7BF7H~7BF9H The 22 holiday and schedule word 7BFAH~7BFCH The 23 holiday and schedule word 7BFDH~7BFFH The 24...
Page 310 7C41H~7C43H The 16 holiday and schedule word 7C44H~7C46H The 17 holiday and schedule word 7C47H~7C49H The 18 holiday and schedule word 7C4AH~7C4CH The 19 holiday and schedule word 7C4DH~7C4FH The 20 holiday and schedule word 7C50H~7C52H The 21 holiday and schedule word 7C53H~7C55H The 22...
Page 311 7C97H~7C99H The 14 holiday and schedule word 7C9AH~7C9CH The 15 holiday and schedule word 7C9DH~7C9FH The 16 holiday and schedule word 7CA0H~7CA2H The 17 holiday and schedule word 7CA3H~7CA5H The 18 holiday and schedule word 7CA6H~7CA8H The 19 holiday and schedule word 7CA9H~7CABH The 20...
Page 312 7CF3H~7CF5H The 14 holiday and schedule word 7CF6H~7CF8H The 15 holiday and schedule word 7CF9H~7CFBH The 16 holiday and schedule word 7CFCH~7CFEH The 17 holiday and schedule word 7CFFH~7D01H The 18 holiday and schedule word 7D02H~7D04H The 19 holiday and schedule word 7D05H~7D07H The 20...
Page 313 7D4CH~7D4EH The 13 holiday and schedule word 7D4FH~7D51H The 14 holiday and schedule word 7D52H~7D54H The 15 holiday and schedule word 7D55H~7D57H The 16 holiday and schedule word 7D58H~7D5AH The 17 holiday and schedule word 7D5BH~7D5DH The 18 holiday and schedule word 7D5EH~7D60H The 19...
Page 314 7DA2H~7DA4H The 11 holiday and schedule word 7DA5H~7DA7H The 12 holiday and schedule word 7DA8H~7DAAH The 13 holiday and schedule word 7DABH~7DADH The 14 holiday and schedule word 7DAEH~7DB0H The 15 holiday and schedule word 7DB1H~7DB3H The 16 holiday and schedule word 7DB4H~7DB6H The 17...
Page 315 7DF8H~7DFAH The 9 holiday and schedule word 7DFBH~7DFDH The 10 holiday and schedule word 7DFEH~7E00H The 11 holiday and schedule word 7E01H~7E03H The 12 holiday and schedule word 7E04H~7E06H The 13 holiday and schedule word 7E07H~7E09H The 14 holiday and schedule word 7E0AH~7E0CH The 15...
Page 316 7E4EH~7E50H The 7 holiday and schedule word 7E51H~7E53H The 8 holiday and schedule word 7E54H~7E56H The 9 holiday and schedule word 7E57H~7E59H The 10 holiday and schedule word 7E5AH~7E5CH The 11 holiday and schedule word 7E5DH~7E5FH The 12 holiday and schedule word 7E60H~7E62H The 13...
Page 317 Table 6-55 Data Factory Address Parameter Property Range Default Type Setting Manual 0XAA:Enable; 8000H Triggering word 0:Disable Waveform bit1bit0: DI1; bit3bit2: DI2; bit5bit4: DI3; bit7bit6: DI4; bit9bit8: DI5; bit11bit10: DI6; DI Triggering — 8001H word 00: Disable; AXM-11 01: From OFF to ON; 10: From ON to OFF;...
Page 318 Data Factory Address Parameter Property Range Default Type Setting Voltage Swell 1: Enable; 8008H Triggering word 0: Disable Waveform Voltage Swell 8009H word 50---140(%) Threshold 800AH Reserved word Current Rated 800BH word 500—5000(mA) 5000 5000 Value Over-current 1: Enable; 800CH Triggering word 0: Disable...
Page 319 The relationship between current waveform value and real value: 1)5A, 1A: Real Value(Unit: A) = Waveform Value/1683.153; 2)333mV: Real Value(Unit: A) = Waveform Value/K (firmware above 3.21,K=14427.15; other: K = 15869.87); 3)100mV(Rope-CT):Real Value(Unit: A) = Waveform Value/K (firmware above 3.21,K=20291.1; firmware 3.20, K=22068.8,other: K = 15869.87); 4)mA CT:Real Value(Unit:A) = Waveform Value/K (80mA CT:K=7414.289;...
Page 320 Power Quality Event Retrieve Address Power quality event includes timestamp, triggering condition and related settings. Every group uses the same data format. Only 10 groups of data are saved in the registers. When retrieving the event data, its parameters must be correctly set in order to get correct information.
Page 321 Factory Address Parameter Data Type Property Range Default Settings Voltage Sag or 0: disabled 8D04H Voltage Swell word 1: Voltage Sag condition 2: Voltage Swell 50V ~ 400V or 8D05H Rated Value word 50V ~ 690V (only in 3LL) Voltage Sag: 20- 100 (%) 8D06H Threshold...
Page 322 6.4.1 Overview This document describes the DNP3.0 communications protocol employed by Acuvim II Series Power Meter. This protocol can be selected for the serial communication port which can consist of RS232/RS485. It is assumed that the reader is familiar with the DNP3.0 protocol and serial communications in general.
Page 323 The baud rate can be set to any supported value. 6.4.3 Data Link Layer The Acuvim II Series Power Meter always acts as a Slave device .The device address can be set from 0 to 65534. The link layer comply with the stand FT3 frame format.
Page 324 In the Acuvim II Series Power Meter, the DNP3.0 supports the Read function , the Direct Operate function and the Direct Operate Unconfirmed function. The Read function ( 0X01 ) The read function is the basic code used for requesting data objects from an Outstation.
Page 325 the Power Meter. Learning more about the measurement data, please refer to the Data Address Table. In this function, the qualifier could be selected contain 0X00, 0X01, 0X06. The qualifier 0X00 refers that there two bytes called Range followed by, one is the start address want to request, the second is the stop address, this Range would be from 0 to 255.
Page 326 ,the unsupported range , the buffer overflow or any other exception error , an error reply will be generate from the Acuvim II series Power Meter to send to the requester station . The Internal Indicator field will reflect the type of error.
Page 327 5) Data Link Layer Confirmation Supported 6) Application Layer Confirmation Supported 7) Application Layer Function Request Supported 0X01, Read Qualifier, 0X00, 0X01, 0X06. Response Supported 129, Read Response Qualifier, 0X00 Supported Error Internal Indicator Response 8) DATA OBJECT LIBRARY a) ANALOG INPUT OBJECT 30 Variation: 3, 32-BIT ANALOG INPUT WITHOUT FLAG Variation: 4, 16-BIT ANALOG INPUT WITHOUT FLAG Variation 5, 32-BIT FLOAT WITH FLAG...
Page 328 Variation: 1 SHORT FLOATING POINT d) CONTROL RELAY OUTPUT BLOCK Object 12 Variation: 01, static digital output control 6.4.8 Data Address Table Point Descriptions The following tables describe the DNP3.0 data objects provided by the Acuvim II series Power Meter. The object, variation, and point numbers are specified for each parameter, as well as the application layer function codes which may be used to operate on the parameter.
Page 329 Table 6-59 Object Point Variation Name Format Range Multiplier Units Descriptor Freq_rms Float Frequency Ua_rms Float Voltage A Ub_rms Float Voltage B Uc_rms Float Voltage C Uvag_rms Float Phrase Voltage Avg Uab_rms Float Voltage A-B Ubc_rms Float Voltage B-C Uca_rms Float Voltage C-A Ulag_rms...
Page 330 Object Point Variation Name Format Range Multiplier Units Descriptor PFc_rms Float None PF_rms Float None Total Power Factor Unbl_u2 Float None Voltage Imbalance Unbl_i2 Float None Current Imbalance Load Rlc_val Float None Characteristics P_dema Float P Demand Q_dema Float Q Demand S_dema Float S Demand...
Page 331 Object Point Variation Name Format Range Multiplier Units Descriptor Reactive_ Reactive_ UINT32 0~999999999 0.1/0.001 var/hr Energy_NET Energy_NET Apprent_ UINT32 0~999999999 0.1/0.001 VA/hr Apprent_ Energy Energy DI1Counts UINT32 0~4294967259 None DI1Counts DI2Counts UINT32 0~4294967259 None DI2Counts DI3Counts UINT32 0~4294967259 None DI3Counts DI4Counts UINT32 0~4294967259 None...
Page 332 Table 6-61 Object Point Variation Name Format Range Multiplier Units Descriptor THD_V1 UINT16 0~10000 0.01 None THD_V1 THD_V2 UINT16 0~10000 0.01 None THD_V2 THD_V3 UINT16 0~10000 0.01 None THD_V3 THD_V UINT16 0~10000 0.01 None THD_V THD_I1 UINT16 0~10000 0.01 None THD_I1 THD_I2 UINT16...
Page 333 6.4.9 DNP3.0 Message Layout The following table is the abbreviation and explain. Table 6-63 DestL The destination address low byte DestH The destination address high byte SorcL The source address low byte SorcH The source address high byte CrcL The Cyclic Redundancy Checksum low byte CrcH The Cyclic Redundancy Checksum high byte The transport layer data sequence num...
Page 334 Application Layer Frames: Reset Energy: Table 6-65 Reset Energy Request DestL DestH SorcL SorcH CrcL CrcL CrcH Response SorcL SorcH DestL DestH CrcL CrcL CrcH Request DestL DestH SorcL SorcH CrcL CrcL CrcH Response SorcL SorcH DestL DestH CrcL CrcL CrcH Reset Energy Request...
Page 335 Table 6-66 Reset Energy Request DestL DestH SorcL SorcH CrcL CrcL CrcH Response SorcL SorcH DestL DestH CrcL CrcL CrcH Request DestL DestH SorcL SorcH CrcL CrcL CrcH Response SorcL SorcH DestL DestH CrcL CrcL CrcH Reset Energy Request CrcH CrcL CrcH Response...
Page 336 Switch to Modbus: Table 6-67 Request DestL DestH SorcL SorcH CrcL CrcL CrcH Request CrcH CrcL CrcH Request Data: Qualifier 0X06: Table 6-68 Reset Energy 0x06 Request DestL DestH SorcL SorcH CrcL CrcL CrcH Response SorcL SorcH DestL DestH CrcL Data3 Data3 Data4...
Page 337 Qualifier 0X00: Table 6-69 Reset Energy 0x00 Request DestL DestH SorcL SorcH CrcL CrcL Response SorcL SorcH DestL DestH CrcL Data4 Data4 Data4 Data4 Flag 5 Data5 Data5 Data5 Data5 Data7 Data7 Data7 CrcL CrcH Reset Energy Request CrcH CrcH Response CrcH Flag 3...
Page 338 Reset Energy Request CrcH CrcH Response CrcH Data3 Data3 Data4 Data4 Data5 Data5 CrcL CrcH Qualifier 0X01: Table 6-71 Reset Energy 0x01 Request DestL DestH SorcL SorcH CrcL Response SorcL SorcH DestL DestH CrcL Data2 Data2 Data3 Data3 Data4 Data4 Data5 Data5 Data6...
Page 339: Appendix A Technical Data And Specifications
Appendix Appendix A Technical Data and Specifications Appendix B Ordering Information Appendix C Revision History...
Page 340 Appendix A Technical Data and Specification Input ratings Energy Accuracy (Acuvim IIR) Active power (according to IEC 62053-22) Class 0.2S (according to ANSI C12.20) Class 0.2 Reactive (according to IEC 62053-23) Class 2 Harmonic Resolution (50Hz or 60Hz type) Metered Value ~ 15 (400Hz type) Voltage input...
Page 341 Accuracy Parameters Accuracy Resolution Range Voltage 0.2% 0.1V 10V~1000kV Current 0.2% 0.001A 5mA~50000A Power 0.2% -9999MW~9999MW Reactive Power 0.2% 1Var -9999MVar~9999MVar Apparent Power 0.2% 0~9999MVA Power Demand 0.2% -9999MW~9999MW Reactive Power Demand 0.2% 1Var -9999MVar~9999MVar Apparent Power Demand 0.2% 0~9999MVA Power Factor 0.2% 0.001...
Page 342 I/O Option Digital Input Input Voltage Range 20~160Vac/dc Input Current (Max) Start Voltage Stop Voltage Pulse Frequency (Max) 100Hz, 50% Duty Ratio SOE Resolution Digital Output (DO) (Photo-MOS) Voltage Range 0~250Vac/dc Load Current 100mA(Max) Output Frequency 25Hz, 50% Duty Ratio Isolation Voltage 2500Vac Relay Output (RO)
Page 343 Suitable Conditions 96x96x51 Dimensions (mm) (Cut-out 92x92 or 4-inch Round) Protection Level IP54 (Front), IP30 (Cover) Weight (g) 350g -25°C~70°C, Metering Temperature -40°C~85°C, Storage Humidity 5%~95% Non-condensing 100~415Vac, 50/60Hz; 100~300Vdc Power Supply Category III, Pollution degree 2 Power Consumption Standard Compliance Measurement Standard IEC 62053-22;...
Page 344 Communication 2-wire connection RS-485 (Standard) MODBUS RTU Protocol or DNP3.0 Protocol Up to 38400 baud rate 10M/100M BaseT MODBUS TCP/IP Protocol Ethernet (Optional) Data Browsing through HTTP Sends e-mail automatically PROFIBUS-DP/V0 Protocol Work as PROFIBUS slave, baud rate adaptive, up to 12M PROFI-BUS (Optional) Model 1:Input Bytes 32,Output Bytes: 32 Model 2:Input Bytes 64,Output Bytes:2...
Page 345: Appendix B Ordering Information
Appendix B Ordering Information Acuvim II series meter: DIN Rail Option Frequency Current Input Power Supply Acuvim II P1: 100-415Vac, 50/60Hz 100-300Vdc P2: 20-60Vdc 5A: 5Amp 1A: 1Amp 333mv: (Voltage type) 100mV/120mV(Rope-CT) mA(80mA/100mA/200mA) 50: 50Hz 60: 60Hz 400: 400Hz D: Standard with LCD display...
Page 346 I/O Option module Module 1 AXM-IO1 Module 2 A: 4-20mA Module 1 B: 0-20mA Analog Output Type AXM-IO2 C: 1-5V D: 0-5V A: 4-20mA Module 2 B: 0-20mA Analog Output Type C: 1-5V D: 0-5V A: 4-20mA Module 1 B: 0-20mA Analog Input Type AXM-IO3 C: 1-5V...
Page 347 Remote Display Option DS2: Compatible with Acuvim II Series “M” (DIN Mount) REM- models only Communication Option Module NET: Ethernet Module (AXM-NET) PROFI: Profibus Module (AXM-PROFI) AXM- RS485: Modbus®-RTU (AXM-RS485) BMS: BACnet MS/TP(AXM-BMS) BIP: BACnet IP(AXM-BIP) Note: 1. No more than 2 of the same I/O modules may be attached to the meter (example: 2 AXM-IO2).
Page 348: Appendix C Revision History
Appendix C Revision History Revision Date Description 20070915 First version P47: change the flow chart; P86: change value of address 101dH from "Reserved" to "Basic parameter mode"; 20070930 P93: change the description of "Basic analog measurement"; P101~P102: change the description "Counting number of I/ O modules".
Page 349 Revision Date Description 1.63 20120417 Change" Time of use (TOU)" Increase in" Acuvim IIW ". Update the method for generating CRC value; 1.64 20120724 Change the voltage rated value and voltage swell threshold. 1.65 20120913 Change the Weekend Setting in TOU. Add the parameter setting page and BACnet parameter setting page;...
Page 350 Make Energy Usage Smarter! Accuenergy Corporation Los Angeles-Toronto-Beijing North America Toll Free: 1-877-721-8908 Web: www.accuenergy.com Email: support@accuenergy.com...

AccuEnergy Acuvim II series User Manual

Chapter 1 Introduction

Chapter 2 Installation

Chapter 3 Meter Display and Parameter Settings

Chapter 4 Detailed Functions and Software

Chapter 5 Extended Modules

Chapter 6 Communication

Appendix A Technical Data and Specifications

Appendix B Ordering Information

Appendix C Revision History

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AccuEnergy Acuvim II series

Summary of Contents for AccuEnergy Acuvim II series

Table of Contents
