CHARACTERISTICS:

The HD67E02-x-A1 are EtherCAT / Modbus Slave - Converters.
It allows for the following characteristics:
Isolation between EtherCAT – Modbus – Power Supply;
Two-directional information between EtherCAT bus and Modbus bus;
Mountable on 35mm Rail DIN;
Wide power supply input range: 8...24V AC or 12...35V DC;
Wide temperature range: -40°C / 85°C [-40°F / +185°F].

CONFIGURATION:

You need Compositor SW67E02 software on your PC in order to perform the following:
Define the parameters of EtherCAT line;
Define the parameters of Modbus line;
Define EtherCAT variables to read and write;
Export the ESI file for configuration of EtherCAT Master;
Update the device.
ADFweb.com S.r.l.
User Manual EtherCAT Slave / Modbus Slave
Document code: MN67E02_ENG Revision 1.000 Page 7 of 29
