heat-timer DiGi-SPAN Elite Series Assembly, Installation And Operation Instructions page 3

Wiring the System Output to a Pump
MCA Modulating a Voltage Actuator
• The HWE-MOV will control the System Pump up to a maximum output of 1 Amp inductive or 1/8 HP.
• Wire the two Yellow wires to the System Pump circuit.
• The HWE-MOV Elite does not source any output power to the pump. The relay makes when
®
energized to switch the power to the pump.
SYSTEM = 147F
TARGET = 150F
SYS DHW
DECREASE Boiler INCREASE SYSTEM
Pump Pump
Wiring Motorized Valve
• The output relays are dry-contacts only. They do not source any power.
SET
• The Red wire is Common. If the valve has only three wires, it is necessary to wire in a
power source for the valve. One side of the valve power source is connected to the valve
Common, and the other side is connected to the HWE-MOV Red wire Common. Check
C O R P O R A T I O N
wiring instructions for the specific valve before making any connections.
• The White wire connects to the valve Open terminal.
• The Blue wire connects to the valve Close terminal.
