Puerto Rico - Single Trunk
Dimensions
Width - 92cm
Depth - 49.6cm
Height - 45.6cm
Important –
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400 800
- Please keep for future reference
641/8720
641/8737
Issue 1 - 19/07/10
Advertisement
Table of Contents
Related Manuals for Argos Puerto Rico 641/8720
Summary of Contents for Argos Puerto Rico 641/8720
- Page 1 Puerto Rico - Single Trunk Assembly Instructions - Please keep for future reference 641/8720 641/8737 Dimensions Width - 92cm Depth - 49.6cm Height - 45.6cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400 800 Issue 1 - 19/07/10...
- Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly Check you have all the This product has been produced We do not components and tools listed on from natural timber; you may recommend the notice some variation in the grain pages 2 and 3.
- Page 3 Components - Panels Please check you have all the panels listed below 5 Base panel 1 Top panel (87.5 x 45.5cm) (91.6 x 46.2cm) 6 Front plinth (91.8 x 9.2cm) Bottom 2 Front panel (87.8 x 36.8cm) 7 Back plinth (91.8 x 9.2cm) Bottom 3 Back panel...
- Page 4 Components - Fittings If you have damaged or missing components, call the Customer Helpline: 08456 400 800 Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 Assembly Instructions Step 1 Fixing panels. Note: A flat surface is required. Two people required for an easier assembly. Fit front panel back panel to the side Bottom panels Attach side panes the front panel back panel using screws Step 2 Fix front plinth to the bottom front panel...
- Page 6 Assembly Instructions Step 3 Fixing base panel. Fit base panel at the cabinet, after attach using screws Bottom Step 4 Fixing top panel. Important: With help, carefully face the product up. Fit top panel at the cabinet. Attach hinges to the pre drilled holes in the top panel using screws Fix the hinges in the...
- Page 7 Assembly Instructions Step 5 Two people required for an easier assembly. pen top panel 90º 90º Attach closing system to the pre drilled holes in the side panels using screws 90º Attention: Ensure top panel 90º prior to fixing. Attach closing system to the top panel using screws...
- Page 8 Assembly Instructions Step 6 Attach 2 side handles to the pre drilled holes in side panels using screws Attach lock to the pre drilled holes in top panel using screws Attach lock plate in front panel using screws Step 7 Attach corner brackets to the pre drilled holes side panels and front...
