- Page 1 Installation and Operation Manual CSE OTS W6 PUMP STATION CSE OTS W6...
-
Page 2: Flow Direction
1. Introduction CSE OTS W6 pump station is designed to be installed in unmixed hydraulic circuits in heating systems where a non return valve is not required. The pump station provides circulation through the concerned heating circuit. 2. Description of the Pump Station The pump station consists of a Wilo Para SC pump including a power cable, two fittings with a shut-off ball valve, thermometer and insulation. -
Page 3: General Information
8 - LED indication of operation/fault 9 - Display of the selected pump operating mode 10 - Display of the selected pump curve (I, II, III) 4.3. Permitted and Prohibited Pump Positions CSE OTS W6 PUMP STATION - www.regulus.eu │... -
Page 4: Pump Wiring
The settings can be changed using the operating button, see below. OPERATING BUTTON Briefly press the operating button to: select the pump operating mode: constant speed, Δp-v or Δp-c and the pump performance curve (I,II,III) CSE OTS W6 PUMP STATION - www.regulus.eu │... - Page 5 LEDs show pump settings (operating mode / performance curve). LED indicators Operating mode Performance curve constant speed constant speed Δp-v variable Δp-v variable Δp-v variable Δp-c constant Δp-c constant Δp-c constant constant speed CSE OTS W6 PUMP STATION - www.regulus.eu │...
-
Page 6: Manual Restart
To cancel the manual restart, hold down the operating button for 5 seconds. If the pump does not get unblocked, contact a qualified technician. CSE OTS W6 PUMP STATION - www.regulus.eu │... -
Page 7: Factory Settings
To return to the factory settings, press and hold the operating button for at least 4 seconds (all LEDs flash for 1 second) and turn off the pump by unplugging. When switched on again, the pump will run at the factory settings. CSE OTS W6 PUMP STATION - www.regulus.eu │... -
Page 8: Pump Operating Modes
Wilo-Para 25/6 Δp-v (variabilní) H[m] p/kPa Wilo-Para 25/6 Δp-v (variable) Δp-v (variabilní) Q/m³/ h Q/l/s Q [m / h] Q/m³/ h Q/Igpm Q/l/s Q/Igpm Q [m / h] Q/m³/ h Q/m³/ h CSE OTS W6 PUMP STATION - www.regulus.eu │... -
Page 9: Constant Differential Pressure Δp-C
Δp-c (konstantní) H[m] p/kPa Wilo-Para 25/6 Δp-c (constant) Δp-c (konstantní) Q/m³/ h Q/l/s Q [m / h] Q/m³/ h Q/Igpm Q/l/s max. Q/Igpm max. Q [m / h] Q/m³/ h Q/m³/ h CSE OTS W6 PUMP STATION - www.regulus.eu │... -
Page 10: Constant Speed
Konstantní otáčky I, II, III constant speed I, II, III Konstantní otáčky I, II, III Q/m³/ h Q [m / h] Q/m³/ h Q/l/s Q/Igpm Q/l/s Q/Igpm Q [m / h] Q/m³/ h Q/m³/ h CSE OTS W6 PUMP STATION - www.regulus.eu │... -
Page 11: Technical Data
3 / 43 W Current (min./max.) 0.04 / 0.44 A Max. speed 4300 rpm Speed control frequency converter Energy Efficiency Index ≤ 0.21 by EN 16 297/3 IP rating IPX4D Motor protection integrated CSE OTS W6 PUMP STATION - www.regulus.eu │... - Page 12 Set the operating mode to Δp-c If the fault cannot be rectified, contact a qualified technician. v1.0-11/2020 ©2020 We reserve the right to errors, changes and improvements without prior notice. REGULUS spol. s r.o. E-mail: sales@regulus.eu Web: www.regulus.eu...
