Summary of Contents for Ross AirCleaner-2
- Page 1 AirCleaner-2 User Manual...
- Page 2 Ross has become well known for the Ross Video Code of Ethics. It guides our interactions and empowers our employees. I hope you enjoy reading it below. If anything at all with your Ross experience does not live up to your expectations be sure to reach out to us at solutions@rossvideo.com.
- Page 3 Express, Mira Express, Tria News, Kiva, and any related marks are trademarks or registered trademarks of Ross Video Limited. All other trademarks are the property of their respective companies. PATENTS ISSUED and PENDING. All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, mechanical, photocopying, recording or otherwise, without the prior written permission of Ross Video.
- Page 4 Important: Changes or modifications to this equipment not expressly approved by Ross Video Limited could void the user's authority to operate this equipment. Canada This Class “...
- Page 5 Changes or modifications to this product not authorized by Ross ® Video Limited could void the FCC Compliance and negate authority to operate the product. This product was tested for FCC compliance under conditions that included the use of Ross ® Abekas ®...
- Page 6 To avoid the potential release of those substances into the environment and to diminish the need for the extraction of natural resources, Ross Video encourages you to use the appropriate take-back systems. These systems will reuse or recycle most of the materials from your end-of-life equipment in an environmentally friendly and health conscious manner.
- Page 7 Technical Support At Ross Video, we take pride in the quality of our products, but if a problem does occur, help is as close as the nearest telephone. Our 24-Hour Hot Line service ensures you have access to technical expertise around the clock. After-sales service and technical support are provided directly by Ross Video personnel.
-
Page 8: Table Of Contents
Video Reaction Times.........................................26 To Set the Video Reaction Time..................................26 Audio Reaction Times.........................................26 To Set the Audio Reaction Time..................................26 Trigger Stretch............................................27 Video Setup..............................28 Video Connections..........................................28 Supported Video Formats........................................28 To Set the Video Format from DashBoard...............................28 viii • Contents — AirCleaner-2 User Manual (v01) - Page 9 To Check the Model and Software Version..................................41 To Factory Default the System......................................41 Software Upgrades.............................42 To Upgrade the Software and Firmware..................................42 Specifications..............................43 Resources............................................43 Operating Temperature........................................43 Video/Audio Input Specifications.....................................43 Video/Audio Output Specifications....................................44 Power Rating............................................44 GPI Port..............................................44 Index..........................46 AirCleaner-2 User Manual (v01) — Contents • ix...
-
Page 10: Overview
The Panic Button Control Panel communicates to the AirCleaner ® chassis over a standard GPI connection. The Panic Button Control Panel ships with a 33-foot shielded cable for connection to the GPI connector on the AirCleaner ® chassis. 10 • Overview — AirCleaner-2 User Manual (v01) -
Page 11: Panic Button Control Panel Y-Cable
The Y-cable is connected to the rear of the AirCleaner ® chassis and then the control cables for each of the two Panic Button Control Panels are connected to the Y-cable. AirCleaner-2 User Manual (v01) — Overview • 11... -
Page 12: Operation
The current video that the screener is looking at is safe, with no violations. There are violations coming (marker with an X) in the next 5 seconds. Each box in the figures below represent 1 second. The 0 frame will also advance through the delay. 12 • Operation — AirCleaner-2 User Manual (v01) - Page 13 After four more seconds the screener is still seeing a violation on their monitor and is still pressing the panic button. Time 11:00 After another second the violation is over. The screener must now react and release the panic button. AirCleaner-2 User Manual (v01) — Operation • 13...
- Page 14 If the Defocus Ramp is set, AirCleaner starts the fade (ramp) to the defocus level before the frame marked as the start of the violation so that the defocus is fully applied for that frame. 14 • Operation — AirCleaner-2 User Manual (v01)
- Page 15 Time 52:00 After another second the panic button release marker has reached the trigger point and if a defocus is being applied the real-time defocus engine starts to fade out. AirCleaner-2 User Manual (v01) — Operation • 15...
- Page 16 One second later the aux in video feed has been cut out or the real-time defocus engine has been removed from the video pathway. The video output now shows the normal unprocessed video. The 40 seconds video delay is still applied. 16 • Operation — AirCleaner-2 User Manual (v01)
-
Page 17: Menu System
• XX Seconds — the menu will lock automatically after the set amount of time. (10 to 60 Seconds) 4. Use the SELECT knob to select Save Changes and press the SET knob to select OK. AirCleaner-2 User Manual (v01) — Menu System • 17... -
Page 18: Dashboard Interface
Under the Abekas node in DashBoard there is a Settings and Buttons node. Settings Node The Settings node provides a graphical user interface to many of the AirCleaner-2 ™ settings. Along the top of the menu are listed to the model and software/firmware versions installed on the system. -
Page 19: To Connect To The Server From Dashboard
3. In the Display Name field, enter the name you want to use to identify the server in DashBoard. This should be a unique name for the server you are setting up. 4. Select JSON. AirCleaner-2 User Manual (v01) — DashBoard Interface • 19... - Page 20 5. In the Port field, enter 5254. 6. Click Finish. The server appears in the Tree View. 20 • DashBoard Interface — AirCleaner-2 User Manual (v01)
-
Page 21: Video Reference
The input video format must be at the same frame-rate as the input reference signal. To Set the Video Format from DashBoard You can set the reference type and SDI video output timing in DashBoard. 1. From the DashBoard tree view for the AirCleaner-2 ™ , expand the Abekas node and double-click Settings. -
Page 22: To Set The Video Reference Type
7. Use the SET knob to adjust the vertical picture position of the PGM OUT and TAP OUT SDI video signals relative to the reference source. (0 to 50) 8. Use the SELECT knob to select Save Changes and press the SET knob to select OK. 22 • Video Reference — AirCleaner-2 User Manual (v01) -
Page 23: Screeners
• Two — the total program delay is split between the two screeners. Screener 1 monitors the incoming audio/video and screener 2 monitors the audio/video output from the TAP OUT BNC. When you select two screeners, separate delay and reaction times are available for each screener. AirCleaner-2 User Manual (v01) — Screeners • 23... -
Page 24: Delays And Offsets
• +X.XX.X — to delay the audio relative to video (which increases the audio delay) a value up to the value of the current Total PGM Delay parameter can be selected, or to a maximum of +10 seconds (whichever is smaller). 7. Click Apply. 24 • Delays and Offsets — AirCleaner-2 User Manual (v01) -
Page 25: Total Pgm Delay
2. 1. Use the SELECT knob to select Screener 2 Delay. Tip: The number of screeners must be set to two for this menu item to appear. AirCleaner-2 User Manual (v01) — Delays and Offsets • 25... -
Page 26: Video Reaction Times
Although it may be tempting to program an extremely large reaction time, there are pitfalls of doing so. A very large reaction time can cause the violation trigger to be advance so far ahead of the actual violation that a large amount of non-violation content will be lost. 26 • Delays and Offsets — AirCleaner-2 User Manual (v01) -
Page 27: Trigger Stretch
Reaction Time to back-time the button release to compensate for the time it takes the screener to see or hear the end of a violation and then release either the Video or Audio Panic Button. Note: Ross Video recommends leaving this setting on (YES). AirCleaner-2 User Manual (v01) — Delays and Offsets • 27... -
Page 28: Video Setup
To Set the Video Format from DashBoard You can set the video format the system is operating in from DashBoard. ™ 1. From the DashBoard tree view for the AirCleaner-2 , expand the Abekas node and double-click Settings. 2. Click Video. -
Page 29: To Set The Video Format
3. Use the SET knob to select the video format you want the system to operate in. 4. Use the SELECT knob to select Save Changes and press the SET knob to select OK. AirCleaner-2 User Manual (v01) — Video Setup • 29... -
Page 30: Audio Setup
Analog Audio Vol parameter controls the volume. To Configure Audio Setting from DashBoard Some audio output setting can be configured from DashBoard. ™ 1. From the DashBoard tree view for the AirCleaner-2 , expand the Abekas node and double-click Settings. 2. Click Audio. -
Page 31: To Select The Audio Source For Pgm In
You can embed the audio out into the SDI video output on the PGM OUT and TAP OUT output BNCs. 1. From the Main Menu, use the SELECT knob to select Options Menu and press the SET knob. 2. Use the SELECT knob to select Embed. Audio OUT. AirCleaner-2 User Manual (v01) — Audio Setup • 31... - Page 32 3. Use the SET knob to select whether the audio is embedded in the PGM and TAP SDI outputs (ON), or not (OFF). 4. Use the SELECT knob to select Save Changes and press the SET knob to select OK. 32 • Audio Setup — AirCleaner-2 User Manual (v01)
-
Page 33: Panic Setup
To Configure Video Panic Setting from DashBoard The video panic settings tell the system how to react when the video panic button is pressed. 1. From the DashBoard tree view for the AirCleaner-2 ™ , expand the Abekas node and double-click Settings. -
Page 34: To Configure Audio Panic Setting From Dashboard
To Configure Audio Panic Setting from DashBoard The audio panic settings tell the system how to react when the audio panic button is pressed. 1. From the DashBoard tree view for the AirCleaner-2 ™ , expand the Abekas node and double-click Settings. -
Page 35: To Configure Audio Panic Setting
• Custom Jumble — aural violation is masked by jumbling the audio signal on selected tracks. • Swap — aural violation is masked by jumbling the audio signal. Note: Configuration of the Custom Jumble and Swap can only be set from DashBoard. AirCleaner-2 User Manual (v01) — Panic Setup • 35... -
Page 36: User Profiles
Do not save or recall a setup while live on-air. To Save a User Profile from DashBoard Save the current settings as a user profile. 1. From the DashBoard tree view for the AirCleaner-2 ™ , expand the Abekas node and double-click Settings. -
Page 37: To Load A Setup
2. Use the SELECT knob to select the Load Setup X? memory register you want to load the setup from. 3. Press LOAD and OK to load the setup from the selected memory register. 4. Use the SELECT knob to select Finished and press the SELECT knob to select YES. AirCleaner-2 User Manual (v01) — User Profiles • 37... -
Page 38: Network Setup
DashBoard control. To Set the IP Address You can set the IP address and network setting from DashBoard. 1. From the DashBoard tree view for the AirCleaner-2 ™ , expand the Abekas node and double-click Settings. -
Page 39: Software Options
You can add software licences to AirCleaner-2 ™ to increase the delay capacity and support UHDTV1. 1. Contact your Ross Video sales representative to purchase a license for the option you want to install. Tip: You can also email (solutions@rossvideo.com) or call (+1-613-652-4886) for sales options. -
Page 40: Maintenance
To Set the Manual Bypass Mode from DashBoard The manual bypass button can either trip an internal bypass relay, or put the system in EE mode. 1. From the DashBoard tree view for the AirCleaner-2 ™ , expand the Abekas node and double-click Settings. -
Page 41: To Check The Model And Software Version
1. From the Main Menu, use the SELECT knob to select User Memory Menu and press the SET knob. 2. Use the SELECT knob to select Factory Defaults and press the SET knob. 3. Press the SELECT knob to recall the factory default settings. AirCleaner-2 User Manual (v01) — Maintenance • 41... -
Page 42: Software Upgrades
To Upgrade the Software and Firmware Upgrade the firmware and software from DashBoard. 1. Download the acl_update.tar.xz file to your DashBoard computer. 2. From the DashBoard tree view for the AirCleaner-2 ™ , expand the Abekas node and double-click Settings. -
Page 43: Specifications
Specifications Resources, video specifications, power rating, and port pinouts. The information is this section is subject to change without notice. Resources The number of resources specific to your AirCleaner-2 ™ depends on the model. Resource Model-A Model-B Model-C Video Inputs... -
Page 44: Video/Audio Output Specifications
Signal Video Panic for Screener 1 Audio Panic for Screener 1 Video Panic for Screener 2 Audio Panic for Screener 2 Manual Bypass Switch Tally 1 (Manual Bypass) Tally 2 (External Lamp) 44 • Specifications — AirCleaner-2 User Manual (v01) - Page 45 Pins 5 (Bypass Button) and 1 (Tally 1) are tied to the Manual Bypass button on the front of the AirCleaner chassis and can be used to locate the functionality of this button remotely. AirCleaner-2 User Manual (v01) — Specifications • 45...
-
Page 46: Index
System Settings in DashBoard 36, 38, Headphone Jack TAP OUT TAP OUT, Audio Licensing in DashBoard Total Program Delay Live Audio Input Trigger Stretch Live Video Input Lock, Menu Upgrade Upgrade in DashBoard Maintenance User Profiles 46 • Index — AirCleaner-2 User Manual (v01) - Page 47 Video Reaction Time Video Settings in DashBoard 21, Video Connections Violations AirCleaner-2 User Manual (v01) — Index • 47...
