Legend
Designation Explanation
X Reach from live ring center
Z Load hook height in the respective range
Admissible weight or mass value with boom in hori-
max
zontal position
L Stick short/long
The admissible weight and mass values apply to identical swiveling of the
boom over the entire swiveling range of 360°.
All table indications in kg (lbs) and horizontal position on firm and level
ground without bucket or exchangeable attachment.
The admissible weight or mass values that can be raised are defined by
the following threshold values:
• 75 % of the static tipping load and
• 87 % of the hydraulic lift capacity
Calculation basis: according to ISO 10567.
Setting pressure on boom hydraulic cylinder 22500 kPa (3,263 psi).
The weight and mass values apply to machines under the following
conditions:
• Lubricants and engine/machine fluids at the mandatory levels
• Full fuel tank
• Canopy
• Machine at operating temperature
• Driver weight 75 kg (165 lbs)
