Table Of Contents - Interchange SBCS5016 Operator's Manual

16 Ga. Wide Crown Staplers
Drives Wide Crown Staples (5/8" to 2" / 16 to 50mm)
Index
Information
Important Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Tool Information
Safety Information
Operating the Stapler
Maintenance and Inspection . . . . . . . . . . . . . . . . . . . . . . . . . .15
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Parts Drawing/Schematics, Parts List, Parts Kits
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Back Cover
2
Interchange Brands
Stapler Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Staple Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Parts Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-9
Employer's Responsibilities . . . . . . . . . . . . . . . . . . . . . . .9
Staple Loading . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Methods of Operation . . . . . . . . . . . . . . . . . . . . . . . . . .10
Adjusting the Stapling Depth . . . . . . . . . . . . . . . . . . . . . . 11
Operation in Cold or Hot Weather . . . . . . . . . . . . . . . . . 11
Air Supply, Operating Pressure,
Lubrication & Connections . . . . . . . . . . . . . . . . . . . . 12-13
Testing the Stapler . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Parts Kits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Parts Drawing/Schematics . . . . . . . . . . . . . . . .18 and 20
Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19 and 21
SAVE THIS MANUAL
FOR FUTURE REFERENCE!
Model No. SGSW5016 Item No. 64415
Model No. SBCS5016 Item No. 64419
Operator's Manual
Page
