3.2 Dimensions (mm) and Weight

3.3 Connections

LEFT Connections from and to outside are set on the left side of the unit front view
RIGHT Connections from and to outside are set on the right side of the unit front view
The factory setting is LEFT.
Fig. 3.a Connections in LEFT orientation
Intake air from outside
A
Exhaust air to outside
B
Supply air to inside
C
Extract air from inside
D
Winter condensation drainage
E
Summer condensation drainage
F
A
B
A
B
C
D
DEFAULT
D
C
Weight Kg
23
F E
3
