BRUKER
BSMS/2
BSMS/2 Mainframe
Technical Manual
Version 001
Bruker

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BSMS/2 and is the answer not in the manual?

Questions and answers

Related Manuals for Bruker BSMS/2

Summary of Contents for Bruker BSMS/2

  • Page 1 BRUKER BSMS/2 BSMS/2 Mainframe Technical Manual Version 001 Bruker...
  • Page 2 The information in this manual may be altered without notice. BRUKER accepts no responsibility for actions taken as a result of use of this ma- nual. BRUKER accepts no liability for any mistakes contained in the manual, lea- ding to coincidental damage, whether during installation or operation of the instrument.

  • Page 3: Table Of Contents

    Contents General Description .............. 5 Introduction .................. 5 Caution ..................5 Troubleshooting ................5 BSMS/2 Chassis and Buses ........... 7 Introduction .................. 7 Installation ..................8 VMEBus and USERBus ..............9 Technical Data ................10 Power Supply Modules ............11 Introduction ................
  • Page 4 Power Supply PSB2 place plan ........... 48 Variant Scheme PSB1 / PSB2 ............49 Bruker BSMS/2 Mainframe Version 001...

  • Page 5: General Description

    Chapter General Description Introduction This manual describes the basic system of the BSMS/2 (Bruker Smart Magnet con- trol System). The mainframe is a modular system providing slots for functional boards to be plugged in. The BSMS consists of the following hardware: 1.
  • Page 6 2. Check the power supplies to verify that all the power LED’s (green) are lit. The ready LED on the CPU should either be lit or blinking. The ready LED’s on the BSMS/2 function boards should be lit. If this is not the case check the power supply modules (see Troubleshooting on page 16).

  • Page 7: Bsms/2 Chassis And Buses 2

    BSMS/2 Chassis and Buses 2 Introduction The BSMS/2 (Bruker Smart Magnet control System / 2) chassis consists of two 19"- racks called front - and back rack. These are shown in Figure 1. The front rack has 16 slots (shown in Figure 2) for boards the size of extended Eurocards. These boards are plugged on to the backplane, which contains two bus systems: a standard VMEBus and a deddicated USERBus (shown in Figure 3).

  • Page 8: Installation

    BSMS/2 Chassis and Buses Figure 2: Slots in the BSMS/2 (Front View) 14 15 SLCB SCB13L SCB13M SCB13R L-TX ... L-RX ... 2H-TX SCB7M SCB13R Installation There are no special requirements for installation. Bruker BSMS/2 Mainframe Version 001...

  • Page 9: Vmebus And Userbus

    VMEBus and USERBus Figure 3: Backplane of the BSMS/2 (Front View) BSMS/2 VMEBus Slot number 1 2 3 4 5 10 11 12 13 14 15 USERBus VMEBus 2.3.1 The VMEBus is a 14 slot A16/A24 D16 board corresponding to the VME standard.

  • Page 10: Technical Data

    BSMS/2 Chassis and Buses Technical Data Table 1. Technical Data of the BSMS/2 Chassis BSMS/2 Chassis General Height Dimensions for the chassis. Width Depth Weight For chassis equipped with 1×CPU, 1×SLCB, 2×SCB, 1×LCB, 1×L-TX, 1×L-RX, PSB1, PSB2 and 1×PNK - module.

  • Page 11: Power Supply Modules

    Chapter Power Supply Modules Introduction The power requirements of the BSMS/2 are met by two modules PSB1 and PSB2 in the back rack.The transformer is fixed on the left wall of the rack. Wiring has been reduced to a minimum.
  • Page 12 H0_GND H0_N Inter- XGND face GND28 AGND DGND 22uH PSB2 VDD28 H0_P Frame Ground H0_N LOCK_P5V LOCK_N5V X5V/X10V LOCK_P15V LOCK_N15V VPWR_P1 VPWR_N1 SCB13-R VPWR_P1 VPWR_GND1 VPWR_N1 AGND DGND Inter- XGND face USER-Bus supply VME supply Bruker BSMS/2 Mainframe Version 001...
  • Page 13 HEAT_GND 2H-TX DGND DGND XGND XGND PNEU_24V PNEU_GND VDD28 VDD28 GND28 GND28 AGND DGND Pneumatic VDD24 Module GND24 PNK.. DGND AGND PNEU_24V BSMS PNEU_GND Keyboard VDD12 VSS12 X10V Router Inter- Display XGND Interface face Computer Bruker BSMS/2 Mainframe Version 001...

  • Page 14: Installation

    For Example: 230 V stable mains power ⇒ 220-245VAC position. 230 V unstable mains power ⇒ 210-230VAC position. Figure 7: Primary Voltage Selection Switch MAINS SLECTOR 210-230VAC 220-245VAC 195-215VAC Back Side of the BSMS/2 Bruker BSMS/2 Mainframe Version 001...
  • Page 15 AC-plugs. 3. Re-mount the cover plate. 4. Insert the BSMS/2 CPU into SLOT 1 (far left of front rack). Connect the BSMS keyboard to the CPU. 5. Plug in the mains cable and turn on the BSMS/2.

  • Page 16: Troubleshooting

    In this case the fuse doesn’thave to be blown.(For fan replacement see Figure 8) 2. Switch the BSMS/2 of and disconect the mains power cable. 3. Verify that the primary voltage selection switch on the power supply module is in the correct position (see Installation on page 14).

  • Page 17: Replacement Of A Power Supply Board

    => - pull rubber fittings till they snap in cut the rubber fittings fix the line module screws Replacement of a Power Supply Board Bruker BSMS/2 Mainframe Version 001...
  • Page 18 Power Supply Modules Figure 11: Replacement step by step Remove all eight screws of the BSMS/2 rack. Loosen the four screws and remove the cooling air channel. Make shure that the mains switch is turned off and Pull the BSMS/2 approximately 15cm (6 inch) the mains cable is pluged out ! out of the cabinet.

  • Page 19: Fuses

    Fuses Open the backpanel of the BSMS/2. The fuses are located on each PSB behind the corresponding LED’s. To exchange a fuse, it is not necessary to plug out the PSB. The DC-supply names are printed on the backpanel. For ratings of the fuses refer to Figure 11.
  • Page 20 SCB R in SLOT 12 (VPWR_VSS) PSB2 VPWR_P1 SCB R in SLOT 12 (VPWR_VDD) PSB1 VPWR_P2 GAB, SCB L, M in SLOT 6, 8, 10 (VPWR_VDD) PSB1 VPWR_N2 GAB, SCB L, M in SLOT 6, 8, 10 (VPWR_VSS) Bruker BSMS/2 Mainframe Version 001...

  • Page 21: Technical Data

    AGND 15 +/– 0.6 V 1.0 A 20 mV AGND –15 +/– 0.6 V 1.0 A 20 mV VDD28 VDD28 27.8 +/- 1.1V 2.0 A 20mV XGND 5 +/– 0.3 V 1.0 A 20 mV Bruker BSMS/2 Mainframe Version 001...
  • Page 22 VPWR-N2 VPWR_GND2 20 - 25 V 6.0 A 1000 HE_P HE_GND 35 - 42 V 0.4 A 1000 PNEU_24V PNEU_GND 21 - 27 V 1.0 A 1500 X10V X10VGND 8.5 - 11.5 V 1.5 A Bruker BSMS/2 Mainframe Version 001...

  • Page 23: Central Processing Board Cpu

    Central Processing Board Introduction The CPU/3 is a BSMS/2 subsystem. It plays a central role in the overall operation of the BSMS/2. First, it relates all messages from the computer or BSMS keyboard to the corresponding board (i.e., it serves as the master of the VMEbus). Second, it ma- nages all functions in which more than one board are involved (i.
  • Page 24 Thermo Switch COMP RS - 232 COMP (galvanically isolated) RS - 485 Fan (On/Off) KEYB (galvanically USERBus isolated) Relay (On/Off) Router Display ROUTER Lines READY ERROR VDD24 +/-15V Supply Voltages +/-12V SYSRESET SYSRESET Logic RESET Bruker BSMS/2 Mainframe Version 001...

  • Page 25: Installation

    CPU Controller Section The Controller Section on the BSMS/2 CPU/3 consists of the single chip microcon- troller MC68306. The MC68306 is an integrated processor containing an MC68EC000 core and parallel and serial interfaces. The VMEbus interface on the BSMS/2 CPU/3 is realised with a programmable device and some ABT drivers.
  • Page 26 7. Supervision of the transformer temperature. The thermoswitch of the BSMS transformer is monitored by the CPU. Should the transformer overheat, an alarm sounds and an error message appears on the BSMS keyboard. 8. Different options such as fan control and programmable relay control. Bruker BSMS/2 Mainframe Version 001...

  • Page 27: Technical Data

    EEPROM kByte non-volatile memory FLASH non-volatile memory Timer Units Real Time Clock Units VMEbus interface A24/A16, Type D8/D16 Option I/O General purpose I/O under software control Expansion Port Units General purpose port for CPU expansion Bruker BSMS/2 Mainframe Version 001...
  • Page 28 Central Processing Board CPU Bruker BSMS/2 Mainframe Version 001...

  • Page 29: Bsms Keyboard Kbc

    Introduction The BSMS keyboard is a special input/output device which allows the user quick and easy access to the spectrometer parameters that are controlled by the BSMS/2. This chapter describes only technical details of the keyboard. General instructions for the use of the BSMS keyboard may be found in the BSMS User’s Manual.
  • Page 30 BSMS Keyboard KBC Figure 15: Layout of the BSMS Keyboard (Version BOSS) Release – Control knob brake (on underside) Tighten Bruker BSMS/2 Mainframe Version 001...
  • Page 31 Figure 16: Layout of the BSMS Keyboard (Version HR-20) Release – Control knob brake (on underside) Tighten Bruker BSMS/2 Mainframe Version 001...
  • Page 32 Alphanumeric Display 2 × 8 Characters Version Controller LED and Key Column Select Board VPWR LED Row (X10V) Select Keys and LED’s +12V Key Row Select Key Column Sense Reset Buzzer Version Display Board Knob Bruker BSMS/2 Mainframe Version 001...

  • Page 33: Installation

    All keys, LED’s with drivers, and the 2 × 8 alphanumeric display of the BSMS key- board are placed on the keyboard display board. It is connected with the keyboard controller board by a 64 wire flat cable. Bruker BSMS/2 Mainframe Version 001...

  • Page 34: Technical Data

    Table 7. Technical Data of the BSMS Keyboard BSMS Keyboard Power Input Voltage 9…11 Supply Input Current In Standby Mode Displaytest Serial Level RS485 (diffe- Link rential) Baudrate 9600 Baud Data Bit Parity none Stop Bit Start Bit Bruker BSMS/2 Mainframe Version 001...

  • Page 35: Buses And Wiring

    Chapter Buses and Wiring Line Modul (DC-Fan) 5x12VDC-Fan(42308) Fan Supply Board (Z13791) filter Mains Input with (14861) Earth Mains Switch (45743) Bruker BSMS/2 Mainframe Version 001...

  • Page 36: Chassis Wiring

    Buses and Wiring Chassis wiring Bruker BSMS/2 Mainframe Version 001...

  • Page 37: User Bus Wiring

    User Bus wiring Bruker BSMS/2 Mainframe Version 001...
  • Page 38 Buses and Wiring Bruker BSMS/2 Mainframe Version 001...
  • Page 39 Bruker BSMS/2 Mainframe Version 001...
  • Page 40 Buses and Wiring Bruker BSMS/2 Mainframe Version 001...
  • Page 41 Bruker BSMS/2 Mainframe Version 001...
  • Page 42 Buses and Wiring Bruker BSMS/2 Mainframe Version 001...

  • Page 43: Bvt

    BVT and BVT-Supply The BVT needs an additional supply Board, the BSMS/2 PS BD BVT3200 400VA (Z002840). The following pictures show how to install these two modules into a BSMS/2 rack. Assembling Instructions Loosen the four screws and remove the cooling air channel Remove all eight screws of the BSMS/2 rack.
  • Page 44 Pull the BSMS/2 approximately 15cm (6 inch) out of the cabinet. Make sure that the mains switch is turned off and the mains cable is plugged out ! Then remove the back pannel. Plug in the BVT and fix the screws.
  • Page 45 Plug in the BVT - Supply BSMS/2 ready to mount the back pannel Connect the mains cables. Note: For cables to or from the BVT see VTU User Manual The BSMS/2 rack is pushed back an fixed to the cabinet. Bruker BSMS/2 Mainframe Version 001...
  • Page 46 Attach the cooling air channel and tighten the screws Bruker BSMS/2 Mainframe Version 001...

  • Page 47: Schemata

    Chapter Schemata Power supply PSB1 place plan Bruker BSMS/2 Mainframe Version 001...
  • Page 48 Schemata Power Supply PSB2 place plan Bruker BSMS/2 Mainframe Version 001...
  • Page 49 Variant Scheme PSB1 / PSB2 Bruker BSMS/2 Mainframe Version 001...
  • Page 50 Schemata Bruker BSMS/2 Mainframe Version 001...
  • Page 51 Bruker BSMS/2 Mainframe Version 001...
  • Page 52 Schemata Bruker BSMS/2 Mainframe Version 001...
  • Page 53 Bruker BSMS/2 Mainframe Version 001...
  • Page 54 Schemata Bruker BSMS/2 Mainframe Version 001...
  • Page 55 Bruker BSMS/2 Mainframe Version 001...
  • Page 56 Schemata Bruker BSMS/2 Mainframe Version 001...
  • Page 57 Bruker BSMS/2 Mainframe Version 001...
  • Page 58 Schemata Bruker BSMS/2 Mainframe Version 001...
  • Page 59 Bruker BSMS/2 Mainframe Version 001...
  • Page 60 Schemata Bruker BSMS/2 Mainframe Version 001...
  • Page 61 Lastpage Bruker BSMS/2 Mainframe Version 001...
