3. Using Peripherals

3. Using Peripherals

3.1. Ready-to-Use Functionality on Dev Board

Table 3.1 contains instructions on how to enable built-in functionality of the Development Board. Refer
to TWN4 MultiTech API documentation for detailed instructions on programming these devices. Refer to
Section 2.1 for help locating components on the board.
Peripheral
Speaker
Debug LEDs
COM-Side LEDs
COM Port 2
SAM Slots 1,2
COM Port 1
RS232 Port

3.2. I/O Extender

The I/O Extender serves to provide additional Interfaces to the Nano Module for the customer to interact
with. These include Wiegand, RS485/422, CAN and Relais. An LCD Screen is also available to assist with
application bring-up.
The I/O Extender can be connected to the TWN4 MultiTech Nano Module via the Expansion slot on the
Development Board. Please see the I/O Extender Technical Handbook for more information.
Instructions to Enable
"COM2-LED & Speaker" DIP Switch bit 2:
There is a bank of 4 LEDs available next to the "LED Connect" DIP
Switch. Use the DIP Switch to enable individual LEDs. These LEDs
are driven by Nano Module GPIO ports 0-3.
There are 5 LEDs next to the COM ports. These include "Nano Module
Power-ON", and RX/TX traffic indicators for both COM 1 and 2 ports. To
enable these LEDs, set "COM2-LED & Speaker" DIP Switch bit 1 to ON.
For COM2 port, see also entry directly below.
COM2 port is functional without any extra board changes. To enable
traffic LEDs on COM2 port, set "COM2-LED & Speaker" DIP Switch bits
3 and 4 to ON. See Table B.4 for details.
No additional steps needed to activate. Simply insert card.
Can be used as a general-purpose port if the main interface to Host is
USB (Micro or DF11). Set "COM1 & Power-ON" DIP Switch bits:
1=ON, 2=OFF, 3=ON, 4=OFF.
Also disable RS232 transceiver by floating Pin 8 (MGND) of DF11 port.
Can be used as a general-purpose port if the main interface to Host is
USB (Micro or DF11). Set "COM1 & Power-ON" DIP Switch bits:
1=ON, 2=ON, 3=ON, 4=ON.
The same connector can be used for both USB and RS232.
See Table B.1 for instructions.
Table 3.1.: Ready-to-Use Functionality on Dev Board
ON to use Speaker.
