UPDATE LOCK WITH COPYING CARD

In the case you want to do a quick update of the lock settings for a larger number of locks, the copying card can be used. You
first need to update 1 lock to the desired settings and then follow the steps below.
1
NOTE: No information of registered User Cards will be read onto the Copying Card. When using the Copying Card to update
2
1
the lock no User Cards will be removed or added. For adding/removing User Cards, see lock programming, section 1.
3
2
STEP 1: Clear the Copy Card
1 4 1
3
This is necessary in order to get step 3 to work properly.
2 C 2
4 (During clearing of card)
Ex: On any lock, present the switch card followed by the Copying Card to clear it from any data.
3 3
C
4 4
STEP 2: Read the setup of an updated lock and record it to the Copying Card (same as in section C)
C C (During reading)
Ex: Present a Copying Card followed by the Master Card and present the Copying Card again for reading the setup of the lock. 1
2
STEP 3: Update the setup of a programmed lock (repeat for all locks that needs to be updated)
3
NOTE: For security reasons, this requires that at least one Master Card that is registered on the lock that is to be updated, is
4
also copied onto the Copying Card.
C
(During update)
Ex: Present a Copying Card to update the lock settings.
(Card cleared)
(Complete reading)
(Update complete)
