Summary of Contents for Avantco APPT71
- Page 1 User Manual Commercial Refrigerator And Freezer User’s Manual 09/2017 Refrigerated Pizza Prep Units APPT71 Refrigerated Sandwich Prep Units 178APT27, 178APT48, 178APT60 Please read the manual thoroughly prior to equipment set-up, operation and maintenance. - 1 -...
-
Page 2: Installation
User Manual Installation Important!!! Please Read Before Installation • If the unit has recently been transported on its side, please let unit stand still for a minimum of 24 hours before plugging it in. • Make sure that the unit drops down to desired temperature before loading the unit with product. •... - Page 3 User Manual Temperature Controls • Refrigerant LED - Compressor is on • Fan LED - Fan is on • Defrost LED - Defrost cycle is running Functions Adjusting the Temperature Your new refrigerator or freezer is already factory-set to run at optimum temperatures for food safety and should require no adjustments.
-
Page 4: Safety Warning
User Manual Loading Product Before loading shelves, please be sure that all shelf clips are completely fastened in their correct locations. It is important that all shelves rest completely level before stocking your cabinet with product. In order to maintain correct air flow inside the unit, please be sure to leave two to four (2 to 4) inches of space between the back wall and stored product. - Page 5 User Manual Attention • To minimize shock and fire hazards, be sure not to overload outlet. Please designate one outlet for your unit. • Do not use extension cords. • Do not put your hands under the unit while it is being moved. •...
- Page 6 User Manual Food Pan Layouts: 178APT27 (6) 1/6 Size, (2) 1/9 Size 24.25” 6.5” 6.5” 6.5” 4.33” 178APT48 (12) 1/6 Size, (6) 1/3 Size 42.5” 7” 7” 7” 7” 7” 7” 178APT60 (16) 1/6 Size, (8) 1/3 Size 56.25” 7” 7”...
- Page 7 User Manual Food Pan Layouts: PICL Food Pan Divider Bars: ITEM # SIZE APT27 APT48 APT60 APPT71 13 15/16” x 9/16” 178SCLB15354 12 7/8” x 9/16” 178SCLB15327 13 15/16" x 1" 178SCLB25354 12 7/8" x 1" 178SCLB25327 13” x 9/16”...
-
Page 8: Regular Maintenance
User Manual Regular Maintenance WARNING: DISCONNECT POWER CORD BEFORE CLEANING ANY PARTS OF THE UNIT. Cleaning The Condenser Coil • For efficient operation, it is important that the condenser surface be kept free of dust, dirt, and lint. • We recommend cleaning the condenser coil and fins at least once per month. •... -
Page 9: Troubleshooting
User Manual Troubleshooting Compressor Not Running Fuse blown or circuit breaker tripped. Replace fuse or reset circuit breaker. Power cord unplugged. Plug in power cord. Thermostat set too high. Set thermostat to lower temperature. Cabinet in defrost cycle. Wait for defrost cycle to finish. Condensing Units Run For Long Periods of Time. -
Page 10: Warranty Information
5 Year Compressor Warranty In addition to the 1 year parts and labor warranty above, Avantco Refrigeration warrants the compressor on select units to be free of defects in material and workmanship for a period of 5 years from the date of delivery.
