Commercial Refrigerator
And Freezer User's Manual
Refrigerated Pizza Prep Units
178PICL1HC, 178PICL2HC, 178PICL3HC
Refrigerated Sandwich Prep Units
178SSPT27HC, 178SSPT36HC, 178SSPT48HC, 178SSPT60HC,
178SSPT71HC, 178SSPT27MHC, 178SSPT36MHC, 178SSPT48MHC,
178SSPT60MHC, 178SSPT71MHC
Please read the manual thoroughly prior to equipment set-up,
operation and maintenance.
User Manual
- 1 -
05/2017
Advertisement
Table of Contents
Related Manuals for Avantco 178PICL1HC
Summary of Contents for Avantco 178PICL1HC
- Page 1 User Manual Commercial Refrigerator And Freezer User’s Manual 05/2017 Refrigerated Pizza Prep Units 178PICL1HC, 178PICL2HC, 178PICL3HC Refrigerated Sandwich Prep Units 178SSPT27HC, 178SSPT36HC, 178SSPT48HC, 178SSPT60HC, 178SSPT71HC, 178SSPT27MHC, 178SSPT36MHC, 178SSPT48MHC, 178SSPT60MHC, 178SSPT71MHC Please read the manual thoroughly prior to equipment set-up, operation and maintenance.
- Page 2 User Manual Warning DANGER – RISK OF FIRE OR EXPLOSION. FLAMMABLE REFRIGERANT USED. TO BE REPAIRED ONLY BY TRAINED SERVICE PERSONNEL. DO NOT PUNCTURE REFRIGERANT TUBING. PELIGRO - RIESGO DE INCENDIO O EXPLOSION. REFRIGERANTE INFLAMABLE UTILIZADO. PARA SER REPARADO SOLAMENTE POR PERSONAL DE SERVICIO CALIFICADO. NO PINCHAR LA TUBERÍA REFRIGERANTE.
-
Page 3: Installation
User Manual Installation Important!!! Please Read Before Installation • If the unit has recently been transported on its side, please let unit stand still for a minimum of 24 hours before plugging it in. • Make sure that the unit drops down to desired temperature before loading the unit with product. •... - Page 4 User Manual Temperature Controls • Refrigerant LED - Compressor is on • Fan LED - Fan is on • Defrost LED - Defrost cycle is running Functions Adjusting the Temperature Your new refrigerator or freezer is already factory-set to run at optimum temperatures for food safety and should require no adjustments.
-
Page 5: Safety Warning
User Manual Loading Product Before loading shelves, please be sure that all shelf clips are completely fastened in their correct locations. It is important that all shelves rest completely level before stocking your cabinet with product. In order to maintain correct air flow inside the unit, please be sure to leave two to four (2 to 4) inches of space between the back wall and stored product. - Page 6 User Manual Attention • To minimize shock and fire hazards, be sure not to overload outlet. Please designate one outlet for your unit. • Do not use extension cords. • Do not put your hands under the unit while it is being moved. •...
- Page 7 User Manual Food Pan Layouts: SSPT 178SSPT27 178SSPT36 (6) 1/6 Size, (2) 1/9 Size (10) 1/6 Size 33” 24.25” 6.5” 6.5” 6.5” 4.33” 6.5” 6.5” 6.5” 6.5” 6.5” 178SSPT48 (12) 1/6 Size, (6) 1/3 Size 42.5” 7” 7” 7” 7” 7”...
- Page 8 User Manual Food Pan Layouts: SSPT-M 178SSPT27M 178SSPT36M (9) 1/6 Size, (3) 1/9 Size (15) 1/6 Size 24.25” 33” 6.5” 6.5” 6.5” 4.33” 6.5” 6.5” 6.5” 6.5” 6.5” 178SSPT48M (18) 1/6 Size 42.25” 6.5” 6.5” 6.5” 6.5” 6.5” 6.5” 2.5” 178SSPT60M (24) 1/6 Size 56.25”...
- Page 9 User Manual Food Pan Layouts: PICL 178PICL1 (6) 1/3 Size 42.3” 7.15” 7” 7” 7” 7” 7.15” 6” 6” 6” 178PICL2 (9) 1/3 Size 63.3” 7.15” 7” 7” 7” 7” 7” 7” 7” 7.15” 6” 6” 6” 178PICL3 (12) 1/3 Size 84.5”...
- Page 10 User Manual Food Pan Divider Bars: SS-PT ITEM # SIZE SS-PT-27 SS-PT-36 SS-PT-48 SS-PT-60 SS-PT-71 13 15/16” x 9/16” 178SCLB15354 12 7/8” x 9/16” 178SCLB15327 13 15/16" x 1" 178SCLB25354 12 7/8" x 1" 178SCLB25327 12 7/8" x 3 9/16" 178SCLB90354 Food Pan Divider Bars: SS-PT-M ITEM #...
-
Page 11: Regular Maintenance
User Manual Regular Maintenance WARNING: DISCONNECT POWER CORD BEFORE CLEANING ANY PARTS OF THE UNIT. Cleaning The Condenser Coil • For efficient operation, it is important that the condenser surface be kept free of dust, dirt, and lint. • We recommend cleaning the condenser coil and fins at least once per month. •... -
Page 12: Troubleshooting
User Manual Troubleshooting Compressor Not Running Fuse blown or circuit breaker tripped. Replace fuse or reset circuit breaker. Power cord unplugged. Plug in power cord. Thermostat set too high. Set thermostat to lower temperature. Cabinet in defrost cycle. Wait for defrost cycle to finish. Condensing Units Run For Long Periods of Time. -
Page 13: Warranty Information
Next, call 1-800-678-5517. Be sure to have the model number, cabinet serial number, and service plate number available when contacting service technicians. This warranty does not apply to, and Avantco is not responsible for, any warranty claims made on products sold or used outside of the United States.
