A Plus Reach-In
Refrigerators & Freezers
Refrigerator Models:
#447AP23R
27 ½" Single Solid Door
#447AP49R
55 3/8" Double Solid Door
Freezer Models:
#447AP23F
27 ½" Single Solid Door
#447AP49F
55 3/8" Double Solid Door
Note:
Read this manual in its entirety prior to equipment setup, operation, and maintenance.
www.AvantcoRefrigeration.com
User Manual
01/2025
447AP23R
447AP49F
Advertisement
Related Manuals for Avantco A Plus 447AP23R
Summary of Contents for Avantco A Plus 447AP23R
- Page 1 User Manual 01/2025 447AP23R 447AP49F A Plus Reach-In Refrigerators & Freezers Refrigerator Models: #447AP23R 27 ½" Single Solid Door #447AP49R 55 3/8" Double Solid Door Freezer Models: #447AP23F 27 ½" Single Solid Door #447AP49F 55 3/8" Double Solid Door Note: Read this manual in its entirety prior to equipment setup, operation, and maintenance.
-
Page 2: Table Of Contents
User Manual A Plus Reach-In Refrigerators & Freezers Table of Contents Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Installation . -
Page 3: Warnings
User Manual A Plus Reach-In Refrigerators & Freezers Warnings DANGER – RISK OF FIRE OR EXPLOSION . FLAMMABLE REFRIGERANT USED . TO BE REPAIRED ONLY BY TRAINED SERVICE PERSONNEL . DO NOT PUNCTURE REFRIGERANT TUBING . PELIGRO – RIESGO DE INCENDIO O EXPLOSION . REFRIGERANTE INFLAMABLE UTILIZADO . PARA SER REPARADO SOLAMENTE POR PERSONAL DE SERVICIO CALIFICADO . -
Page 4: Installation
User Manual A Plus Reach-In Refrigerators & Freezers Installation Read this manual thoroughly prior to equipment setup, operation, and maintenance. This unit is intended for use in a temperature-controlled environment of less than 75°F and 60% relative humidity. Before Installation •... - Page 5 A Plus Reach-In Refrigerators & Freezers Field Convertible Doors The Avantco AP-23R and AP-23F ship with a right-hinged door design . These single door models have the ability to be switched to a left-hinged door design . Please follow instructions below: Tools Needed: •...
-
Page 6: Cabinet Location Guidelines
User Manual A Plus Reach-In Refrigerators & Freezers Cabinet Location Guidelines • Install the unit on a strong and leveled surface . • If the surface is uneven, the unit may be noisy . • The unit may malfunction if the surface is uneven . •... -
Page 7: Temperature Controls
User Manual A Plus Reach-In Refrigerators & Freezers Temperature Controls Adjusting the Temperature • Your new refrigerator or freezer is already factory set to run at optimum temperatures for food safety and should require no adjustments . • Refrigerators are set to cycle between a minimum temperature of 32°F and a maximum temperature of 38°F . -
Page 8: Automatic Alarms
User Manual A Plus Reach-In Refrigerators & Freezers Automatic Alarms Automatic alarms are programmed to sound on your unit in the following instances: Refrigerator Cabinet High / Low Temperature Alarm • When the temperature reaches 8°F above your set point for 30 minutes . •... -
Page 9: Manual Defrost
User Manual A Plus Reach-In Refrigerators & Freezers Manual Defrost This unit is pre-programmed to run automatic defrost cycles at preset intervals . However, if you would like to run a manual defrost cycle at any time, follow the steps below: 1. -
Page 10: Maintenance
User Manual A Plus Reach-In Refrigerators & Freezers Maintenance DISCONNECT POWER CORD BEFORE CLEANING ANY PARTS OF THE UNIT. It is strongly recommended that any servicing of the unit be performed by an authorized service technician. Fan Blades & Motor •... -
Page 11: Cleaning The Condenser Coil
User Manual A Plus Reach-In Refrigerators & Freezers Never Use the Following Products to Clean Stainless Steel What Chloride-Based Cleaners Using chlorine / bleach could result in pin holes . Sharp Objects Sharp edges can puncture the surface . Onion / Olive Juice A galvanic chemical reaction transfers to the metal and causes pin holes . -
Page 12: Troubleshooting
User Manual A Plus Reach-In Refrigerators & Freezers Troubleshooting Problem Possible Cause Possible Solution Fuse blown or circuit breaker tripped . Replace fuse or reset circuit breaker . Power cord unplugged . Plug in power cord . Compressor not running . Thermostat set too high .
