Commercial Refrigerator
User's Manual
Refrigerated Pizza Prep Units
178APPT71HC, 178APPT49HC, 178APPT91HC
Refrigerated Sandwich Prep Units
178APT27HC, 178APT27MHC, 178APT48HC, 178APT48MHC,
178APT60HC, 178APT60MHC, 178APT71HC, 178APT71MHC
Please read the manual thoroughly prior to equipment set-up,
operation and maintenance.
User Manual
- 1 -
10/2020
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Avantco 178APPT71HC
Summary of Contents for Avantco 178APPT71HC
- Page 1 User Manual Commercial Refrigerator User’s Manual Refrigerated Pizza Prep Units 10/2020 178APPT71HC, 178APPT49HC, 178APPT91HC Refrigerated Sandwich Prep Units 178APT27HC, 178APT27MHC, 178APT48HC, 178APT48MHC, 178APT60HC, 178APT60MHC, 178APT71HC, 178APT71MHC Please read the manual thoroughly prior to equipment set-up, operation and maintenance. - 1 -...
- Page 2 User Manual Warning DANGER – RISK OF FIRE OR EXPLOSION. FLAMMABLE REFRIGERANT USED. TO BE REPAIRED ONLY BY TRAINED SERVICE PERSONNEL. DO NOT PUNCTURE REFRIGERANT TUBING. PELIGRO - RIESGO DE INCENDIO O EXPLOSION. REFRIGERANTE INFLAMABLE UTILIZADO. PARA SER REPARADO SOLAMENTE POR PERSONAL DE SERVICIO CALIFICADO. NO PINCHAR LA TUBERÍA REFRIGERANTE.
-
Page 3: Installation
User Manual Installation Important!!! Please Read Before Installation • If the shelf has a raised lip, the lip needs to be installed facing up towards the rear of the cabinet to promote proper air flow. Failure to install the shelves properly is considered user-error and is not covered by warranty. -
Page 4: Temperature Controls
User Manual Electrical • Please ensure that the required voltage of the compressor is being supplied at all times. Low or high voltage can detrimentally affect the refrigeration unit. • All units should be plugged into a grounded and properly-sized electrical outlet with appropriate overcurrent protection. -
Page 5: Loading Product
User Manual Refrigerator Control Loading Product Before loading shelves, please be sure that all shelf clips are completely fastened in their correct locations. It is important that all shelves rest completely level before stocking your cabinet with product. In order to maintain correct air flow inside the unit, please be sure to leave two to four (2 to 4) inches of space between the back wall and stored product. -
Page 6: Safety Warning
User Manual Safety / Warning Please pay close attention to the safety notices in this section. Disregarding these notices may lead to serious injury and/or damage to the unit. Attention • To minimize shock and fire hazards, be sure not to overload outlet. Please designate one outlet for your unit. - Page 7 7” 7” 178APT60HC (16) 1/6 Size, (8) 1/3 Size 56.25” 7” 7” 7” 7” 7” 7” 7” 7” 178APT71HC 178APPT71HC (18) 1/6 Size, (9) 1/3 Size (9) 1/3 Size 66” 63.3” ” 4.33” 7” 7” 7” 7” 7” 7” 7”...
- Page 8 User Manual Mega Top 178APT71MHC (30) 1/6 Size 66” 6.5” 6.5” 6.5” 6.5” 6.5” 6.5” 6.5” 6.5” 6.5” 6.5” 178APT60MHC (24) 1/6 Size 56.25” 6.5” 6.5” 6.5” 6.5” 6.5” 6.5” 6.5” 6.5” 3.3” 178APT48MHC (18) 1/6 Size 42.25” 6.5” 6.5” 6.5”...
- Page 9 7” 7” 7” 178APPT49HC 178APT60HC (16) 1/6 Size, (8) 1/3 Size 56.25” 7” 7” 7” 7” 7” 7” 7” 7” 178APPT71HC 178APPT71HC (9) 1/3 Size (9) 1/3 Size 63.3” 7” 7” 7” 7” 7” 7” 7” 7” 7” 178APPT91HC (12) 1/3 Size...
- Page 10 User Manual Food Pan Divider Bars: ITEM # SIZE APT27HC APT48HC APPT49HC APT60HC APPT71HC APT-71-HC APPT91HC 178SCLB15354 178SCLB15327 178SCLB25354 178SCLB25327 178PICB15331 178PICB25331 13” x 1” 178PICB15331 178PICB25331 13” x 1” 178PICB15331 178PICB25331 13” x 1” Food Pan Divider Bars: A-PT-M ITEM # SIZE APT-27-MHC APT-48-MHC APT-60-MHC APT-71-MHC...
-
Page 11: Regular Maintenance
User Manual Regular Maintenance WARNING: DISCONNECT POWER CORD BEFORE CLEANING ANY PARTS OF THE UNIT. Cleaning The Condenser Coil • For efficient operation, it is important that the condenser surface be kept free of dust, dirt, and lint. • We recommend cleaning the condenser coil and fins at least once per month. •... -
Page 12: Troubleshooting
User Manual Troubleshooting Compressor Not Running Fuse blown or circuit breaker tripped. Replace fuse or reset circuit breaker. Power cord unplugged. Plug in power cord. Thermostat set too high. Set thermostat to lower temperature. Cabinet in defrost cycle. Wait for defrost cycle to finish. Condensing Units Run For Long Periods of Time.
