MUNGO560
User's Guide
Manual PN: 930-0029-00-C
2007
January
www.kontron.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MUNGO560 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Kontron MUNGO560

Summary of Contents for Kontron MUNGO560

  • Page 1 MUNGO560 User’s Guide Manual PN: 930-0029-00-C 2007 January www.kontron.com...
  • Page 2 This user’s guide may contain or reference information and products protected by copyrights or patents and does not convey any license under the patent rights of Kontron, nor the rights of others.

  • Page 3: Table Of Contents

    Connector List ..........2-8 MUNGO560 User’s Guide...
  • Page 4 FLASH Memory ..........4-4 MUNGO560 User’s Guide...
  • Page 5 Security Menu ..........5-36 MUNGO560 User’s Guide...
  • Page 6 Common Problems ......... . 8-4 MUNGO560 User’s Guide...

  • Page 7: Safety Instructions

    Safety Instructions Contents Before You Begin ..........ix When Working Inside a Computer .
  • Page 8 This page intentionally left blank. MUNGO560 User’s Guide viii...

  • Page 9: Before You Begin

    Before You Begin Before handling the MUNGO560 , read the instructions and safety guidelines on the following pages to prevent damage to the product and to ensure your own personal safety. Refer to the “Advisories” section in the Preface for advisory conventions used in this user’s guide, including the distinction between Warnings, Cautions, Important Notes, and Notes.

  • Page 10: When Working Inside A Computer

    Also, before connecting a cable, make sure both connectors are correctly oriented and aligned. CAUTION Do not attempt to service the system yourself except as explained in this user’s guide. Follow installation and troubleshooting instructions closely. MUNGO560 User’s Guide...

  • Page 11: Preventing Electrostatic Discharge

    Static electricity can harm system boards. Perform service at an ESD workstation and follow proper ESD procedure to reduce the risk of damage to components. Kontron strongly encourages you to follow proper ESD procedure, which can include wrist straps and smocks, when servicing equipment.
  • Page 12 This page intentionally left blank. MUNGO560 User’s Guide...

  • Page 13: Preface

    Preface Contents How to Use This Guide ........xv Customer Comments.
  • Page 14 This page intentionally left blank. MUNGO560 User’s Guide...

  • Page 15: How To Use This Guide

    Chapter 6, System Resource Allocation, provides additional information on IRQs, DMA Channels, and memory mapping. Chapter 7, Block Diagram, details components and the flow of the MUNGO560. Chapter 8, Troubleshooting, provides help for basic technical issues. How to Use This Guide...

  • Page 16: Customer Comments

    “Contact Us” on our web site (www.kontron.com) under “Technical Support.” Detail any errors you find. We will correct the errors or problems as soon as possible and post the revised user’s guide in our online Support Library.

  • Page 17: Advisory Conventions

    Disclaimer: We have tried to identify all situations that may pose a warning or caution condition in this user’s guide. However, Kontron does not claim to have covered all situations that might require the use of a Caution or Warning.

  • Page 18: Unpacking

    2) Remove all items from the box. If any items listed on the purchase order are missing, notify Kontron customer service immediately. 3) Inspect the product for damage. If there is damage, notify Kontron customer service immediately. Refer to “Guarantee and Warranty Policy” for the return procedure.

  • Page 19: Regulatory Compliance Statements

    (domestic environment) is likely to cause harmful interference, in which case the user will be required to correct the interference (take adequate measures) at their own expense. Changes or modifications not expressly approved by Kontron could void the user's authority to operate the equipment.
  • Page 20 This page intentionally left blank. MUNGO560 User’s Guide...

  • Page 21: Guarantee And Warranty Policy

    Effective April 1, 1998, all products carry a 2-year limited warranty. Within 2 years of purchase, Kontron will repair or replace, at our option, any defective product. Kontron will service the warranty for all standard catalog products for the first two years from the date of shipment.

  • Page 22: Return Procedure

    Kontron or its authorized agent; or if the failure is caused by accident, acts of God, or other causes beyond the control of Kontron or the manufacturer. Neglect, misuse, and abuse shall include any installation, operation, or maintenance of the product other than in accordance with the user’s guide.

  • Page 23: Limitation Of Liability

    Limitation of Liability In no event shall Kontron be liable for any defect in hardware, software, loss, or inadequacy of data of any kind, or for any direct, indirect, incidental, or consequential damages in connection with or arising out of the performance or use of any product furnished hereunder. Kontron’s liability shall in no event exceed the purchase price of the product purchased hereunder.

  • Page 24: Maintaining Your Computer

    If the system has been exposed to abnormally cold temperatures, allow a two-hour warm-up period to bring it up to normal operating temperature before turning it on. Failure to do so may cause damage to internal components, particularly the hard disk drive. MUNGO560 User’s Guide xxiv...

  • Page 25: Power Protection

    Surge protectors prevent voltage spikes from entering a system through the AC power cord. Surge protectors, however, do not offer protection against brownouts, which occur when the voltage drops more than 20 percent below the normal AC line voltage level. MUNGO560 User’s Guide...
  • Page 26 UPS systems that provide only 5 minutes of battery power let you conduct an orderly shutdown of the system, but are not intended to provide continued operation. Surge protectors should be used with all UPS systems, and the UPS system should be Underwriters Laboratories (UL) safety approved. MUNGO560 User’s Guide xxvi...

  • Page 27: Introduction

    Chapter 1 Introduction Contents Overview ..........1-3 I/O Performance .

  • Page 29: Overview

    AGP interface with support for LVDS flat panels. The most unique feature of the MUNGO560 is its PICMG edge that supports risers to bring out 64- bit PCI-X slots for high performance I/O applications. Also included is a mini-PCI socket for add- on I/O with 64-bit extension for custom mini-PCI-X solutions, or just conventional 32-bit mini- PCI.

  • Page 30: Checklist

    Checklist MUNGO560 embedded board If this item is damaged, please contact Kontron. Save all packing materials for future replacement and maintenance. MUNGO560 User’s Guide...

  • Page 31: Jumpers & Connectors

    Chapter 2 Jumpers & Connectors Contents Overview ..........2-3 Jumpers .

  • Page 33: Overview

    This chapter provides the definitions and locations of jumpers, headers, and connectors. The MUNGO560 has multiple jumpers, which you can configure. Jumpers on the MUNGO560 single board computer are shipped with the default settings. The default settings are marked with an asterisk (*).

  • Page 34: Jumper Locations

    Jumper Locations The following diagram shows the layout of the MUNGO560 jumpers. For additional information, see the MUNGO560 Quick Reference on the Kontron Web site. MUNGO560 User’s Guide...

  • Page 35: Jumper Pinouts

    Jumper Pinouts Asterisks mark the default setting for each of the jumpers. LCD Power Selection (J1) Jumper Jumper <+5V for LCD PWR> <+3V for LCD PWR> RTC CMOS Clear (J4) Jumper Jumper <Normal>* <Clear CMOS> Jumper Pinouts MUNGO560 User’s Guide...

  • Page 36: Clear Cmos Operation

    4) Reconnect the system power and turn on the system. The message “CMOS settings wrong” and “CMOS date/time not set” will be displayed and the system will hold up. Follow the displayed messages to reload the BIOS default settings. MUNGO560 User’s Guide...

  • Page 37: Connectors

    I/O peripheral devices are connected to the connectors as described in this section. Jumpers are not shown in this diagram. For jumper information, see the preceding section on Jumpers. A complete list of SBC components and matching reference designators are on the next page. Connectors MUNGO560 User’s Guide...

  • Page 38: Connector List

    10-pin shrouded header Chassis Fan I/F 3-pin header with Tach Monitoring COM Port 2 10-pin shrouded header AC ‘97 Audio Signals 10-pin header USB Ports 3 & 4 10-pin header CPU Fan I/F 3-pin header with Tach Monitoring MUNGO560 User’s Guide...
  • Page 39 10-pin header Ethernet Ports 1 & 2 Power Input 6-pin locking connector 10/100 ACT/Link 3-pin header 10/100/1000 ACT/Link 3-pin header Mini-PCI (backside) 124-pin SODIMM socket 64-bit Mini-PCI extension 60-pin dual row SMT stack (back side) Connector List MUNGO560 User’s Guide...

  • Page 40: Connector Pinouts

    Connector Pinouts The following tables detail the pinout of each of the MUNGO560 components. SATA Port 0(J8) Signal SATA Port 1 (J9) Signal MUNGO560 User’s Guide 2-10...

  • Page 41: Chassis Intrusion(J10)

    Chassis Intrusion(J10) Switch Description <J10> Chassis Intrusion Switch Connector Pinouts 2-11 MUNGO560 User’s Guide...

  • Page 42: Lvds (J12)

    ENAVDD TX1_1N TX1_1P ENAVEE TX1_2N TX1_2P GND(0) CLK_1N CLK_1P GND(1) TX1_3N TX1_3P DATA TX2_0N TX2_0P TX2_1N TX2_1P GND(2) TX2_2N TX2_2P GND(3) CLK_2N CLK_2P GND(4) TX2_3N TX2_3P +5V(0) +5V(1) +5V(2) +5V(3) ENABLK BKLGND(0) BKLGND(1) +12V(0) +12V(1) +12V(2) MUNGO560 User’s Guide 2-12...

  • Page 43: Reset & Power Switch(J13, J14)

    This also serves as secondary IDE. Signal Signal Pull-Up Data 3 Data 11 Data 4 Data 12 Data 5 Data 13 Data 6 Data 14 Data 7 Data 15 CS0# CS1# IOR# IOW# +3.3V +3.3V +3.3V CF_BOO T_EN# RST# Connector Pinouts 2-13 MUNGO560 User’s Guide...
  • Page 44 IORDY +3.3V CF_ACT# Data 0 Data 1 Data 8 Data 2 Data 9 Pull-Down Data 10 Pull-Up MUNGO560 User’s Guide 2-14...

  • Page 45: Primary Ide (J16)

    Data 15 Ground Removed for keying DMA REQ Ground IOW # Ground IOR # Ground IOCHRDY Pull-down DMA ACK # Ground INT REQ CBL_DET HDC CS0 # HDC CS1 # HDD Active # Ground Connector Pinouts 2-15 MUNGO560 User’s Guide...

  • Page 46: Chassis Speaker Header (J21)

    Signal Signal Data Carrier Detect (DCD) Data Set Ready (DRS) Receive Data (RXD) Request to Send (RTS) Transmit Data (TXD) Clear To Send (CTS) Data Terminal Ready (DTR) Ring Indicator (RI) Ground (GND) Remove for keying MUNGO560 User’s Guide 2-16...

  • Page 47: Vga (J29)

    VGA (J29) Signal +5V (FUSED) DDCDAT HSYNC VSYNC DDCCLK Chassis Fan I/F (J30) Signal FAN CNTL +12V FAN TACH Connector Pinouts 2-17 MUNGO560 User’s Guide...

  • Page 48: Com Port 2 (J31)

    AC ‘97 Audio (J32) Signal Signal SDIN SDOUT +3.3V +12V AC97_EN# SPKR_IN AC97_RST# BIT_CLK SYNC USB 2.0 Port 3 & 4(J33) Signal Signal +5V (fused) GND Shield USBP4- Ground USBP4+ USBP3+ Ground USBP3- GND Shield +5V (fused) MUNGO560 User’s Guide 2-18...

  • Page 49: Cpu Fan I/F (J34)

    CPU Fan I/F (J34) Signal FAN CNTL +12V FAN TACH USB 2.0 Port 1 & 2 (J35) Signal +5V (fused) USBP1- USBP1+ Ground +5V (fused) USBP2- USBP2+ Ground Connector Pinouts 2-19 MUNGO560 User’s Guide...

  • Page 50: 10/100/1Gb Ethernet Ports 1 & 2 (J36)

    Bottom RJ45 PORT1_MDX4+ Bottom RJ45 PORT1_MDX4- Bottom RJ45 PORT1_MDX1+ Top RJ45 10/100 PORT1_MDX1- Top RJ45 10/100 PORT1_MDX2+ Top RJ45 10/100 Top RJ45 10/100 Top RJ45 10/100 PORT1_MDX2- Top RJ45 10/100 Top RJ45 10/100 Top RJ45 10/100 MUNGO560 User’s Guide 2-20...

  • Page 51: Power (J37)

    LAN Activity Header 1 (J38) This pinout is for the 10/100 ATC ACT/Link header. Signal ACT# +3.3V LINK# LAN Activity Header 2 (J39) This pinout is for the 10/100/1000 ACT/Link header. Signal ACT# +3.3V LINK# Connector Pinouts 2-21 MUNGO560 User’s Guide...

  • Page 52: Mini-Pci (J40)

    Mini-PCI (J40) The mini-PCI is located on the back of the board. Signal Signal INTB# +3.3V INTA# RSVD RSVD +3.3VAUX RST# +3.3V REQ# GNT# +3.3V AD31 PME# AD29 RSVD AD30 AD27 +3.3V AD25 AD28 MUNGO560 User’s Guide 2-22...
  • Page 53 AD26 CBE3# AD24 AD23 IDSEL AD21 AD22 AD19 AD20 AD17 AD18 CBE2# AD16 IRDY# +3.3V FRAME# CLKRUN# TRDY# SERR# STOP# +3.3V PERR# DEVSEL# CBE#1 AD14 AD15 AD13 AD12 AD11 AD10 CBE0# +3.3V +3.3V RSVD Connector Pinouts 2-23 MUNGO560 User’s Guide...
  • Page 54 RSVD RSVD M66EN MUNGO560 User’s Guide 2-24...

  • Page 55: Pcb Edge Connector (32 Bit)

    PCB Edge Connector (32 Bit) This is a 32-bit PCI backplane. Signal Signal -12V TRST# +12V INTA# INTB# INTC# INTD# REQ3# REQ1# +5V(I/O) GNT3# CLKD CLKA GNT1# RST# CLKB +5V(I/O) GNT0# REQ0# +5V(I/ REQ2# AD31 AD30 AD29 +3.3V Connector Pinouts 2-25 MUNGO560 User’s Guide...
  • Page 56 C/BE3# GNT2# AD23 +3.3V AD22 AD21 AD20 AD19 +3.3V AD18 AD17 AD16 C/BE2# +3.3V FRAME# IRDY# +3.3V TRDY# DEVSEL# STOP# LOCK# +3.3V PERR# SDONE +3.3V SBO# SERR# +3.3V C/BE1# AD15 AD14 +3.3V AD13 AD12 AD11 AD10 MUNGO560 User’s Guide 2-26...
  • Page 57 AD09 Connector Key Connector Key AD08 C/BE0# AD07 +3.3V +3.3V AD06 AD05 AD04 AD03 AD02 AD01 AD00 +5V(I/O) +5V(I/O) ACK64# REQ64# Connector Pinouts 2-27 MUNGO560 User’s Guide...

  • Page 58: Pcb Edge Connector (64 Bit)

    This is a 64-bit PCI backplane. Signal Signal RSVD C/BE7# C/BE6# C/BE5# C/BE4# PAR64 AD63 AD62 AD61 AD60 AD59 AD58 AD57 AD56 AD55 AD54 AD53 AD52 AD51 AD50 AD49 AD48 AD47 AD46 AD45 AD44 AD43 AD42 AD41 MUNGO560 User’s Guide 2-28...
  • Page 59 AD40 AD39 AD38 AD37 AD36 AD35 AD34 AD33 AD32 RSVD RSVD RSVD RSVD Connector Pinouts 2-29 MUNGO560 User’s Guide...
  • Page 60 This page intentionally left blank. MUNGO560 User’s Guide 2-30...

  • Page 61: Hardware

    Chapter 3 Hardware Contents Overview ..........3-3 Installing the Pentium M Processor .

  • Page 63: Overview

    3) With the processor installed, secure the heatsink and fan assembly to the backplate, using the four screws on the assembly. 4) Plug the CPU fan power to Connector J34. Overview MUNGO560 User’s Guide...

  • Page 64: Installing Memory

    Installing Memory The MUNGO560 embedded board provides one 184-pin DIMM sockets to support on-board main memory. The maximum memory size for 2.5V DDR-200/266/333 SDRAM is 2GB. For system compatibility and stability, do not use generic DIMM. Use single- or double-sided DDR-200/266/333 DIMM modules.

  • Page 65: Adding A Dimm Card

    The module release levers will return to their upright position when the DIMM card is completely seated in the socket. The pegs on the tips of the release levers should align with the notches on both ends of the DIMM card. Installing Memory MUNGO560 User’s Guide...
  • Page 66 This page intentionally left blank.

  • Page 67: Specifications

    Chapter 4 Specifications Contents Overview ..........4-3 Processor .
  • Page 68 Power Specifications ........4-9 Input Power Requirements .

  • Page 69: Overview

    Overview The following information provides details on the technical specifications of the MUNGO560. Processor Supports mPGA478 socket Intel® Pentium® M or Intel Celeron® M processors (Banias and Dothan) up to 2.16GHz PCB support of non-socket soldered Intel Pentium M or Intel Celeron M processors...

  • Page 70: Flash Memory

    4 USB 2.0 (two as dual stack and two via 10-pin header) Supports bootable USB Serial Ports 2 RS-232 1 RS-232/422/485 Serial ATA Two drives supported ATA/IDE Primary 44-pin 2.5-inch master/slave drive support up to UDMA/100 Ethernet One 10/100 BASE-T LAN One 10/100/1000 GB LAN MUNGO560 User’s Guide...

  • Page 71: Compactflash

    Adding net gain of three more USB 2.0 ports 4-port module uses one existing USB port Audio Speaker Support for external speaker Audio Expansion Port AC 97 audio signals 10-pin header Supports daughter card with Audio Codec, AMP and audio connectors CompactFlash MUNGO560 User’s Guide...

  • Page 72: Video

    PCI bus, Serial ports, Watchdog, RTC, health monitoring, IDE, USB keyboard, boot without keyboard, USB boot, drive boot, CD-ROM, 10/100 and 10/100/1000 LAN, IDE CompactFlash card auto-detect on boot, Wakeon- LAN, BIOS setups default restore, console redirection, graphics disable for add-on PCI video card MUNGO560 User’s Guide...

  • Page 73: Os Support

    OS Support Linux® Windows®2000/XP Others by special request Mechanical Dimensions (W x D) Standard 5.25-inch form factor: 5.75 x 8-inch (146.1 x 203.2mm) OS Support MUNGO560 User’s Guide...

  • Page 74: Environmental Specifications

    -40 ° to 70 °C (-40 ° to 158 °F) Operating Humidity 5 to 90% RHNC Non-operating Humidity 5 to 95% RHNC @ (50 °F) Operating Altitude 13,123-feet (4000-meters) Non-operating Altitude 49,212-feet (15,000-meters) Operating Vibration 5 to 500Hz, 1g, each axis MUNGO560 User’s Guide...

  • Page 75: Non-Operating Vibration

    +5 V DC +/- 5%, max i/p current: 5.5A +/- 5% +12 V DC +/- 5%, max i/p current: 0.27A +/- 5% Input Power The maximum steady state input power shall be 30.74W +/- 15%. Power Specifications MUNGO560 User’s Guide...
  • Page 76 This page intentionally left blank.

  • Page 77: Bios

    Exit Menu ..........5-44 MUNGO560 User’s Guide...
  • Page 78 MUNGO560 User’s Guide...

  • Page 79: Overview

    Overview The MUNGO560 single board computer is equipped with an AMI BIOS, which is stored in Flash ROM. This AMI BIOS features a built-in setup program, allowing users to modify the system configuration. The system configuration is stored in CMOS RAM, and so it is retained during power-off periods.

  • Page 80: Menu Bar

    Use this menu to configure power management. Exit Exits the system setup and saves settings to CMOS. Use the left and right arrow keys to make a selection. See the section below, "Exiting Setup," for a description on exiting the Main Menu. MUNGO560 User’s Guide...

  • Page 81: Legend Bar

    To display a submenu, use the arrow keys to move the cursor to the submenu you want. Then press [Enter]. A pointer ( ) marks all submenus. Main Menu MUNGO560 User’s Guide...
  • Page 82 You can make the following selections on the Main Menu itself. Use the submenus for other selections. System Time This allows you to change the system time stored in the AMI BIOS. System Date This allows you to change the system date stored in the AMI BIOS. MUNGO560 User’s Guide...

  • Page 83: Advanced Menu

    This menu Enables or Disables USB support for legacy products. Hardware Health This menu shows the system’s hardware health Configuration monitor screen. Use the legend keys to make your selections and exit to the Main Menu. An asterisk represents the default value Advanced Menu MUNGO560 User’s Guide...
  • Page 84 This option allows you to set the speed of the CPU. Maximum Speed Sets CPU speed to maximum. Minimum Speed Sets CPU speed to minimum. Automatic* Allows operating system to control CPU speed. Disabled The default CPU speed is used. MUNGO560 User’s Guide...
  • Page 85 This function specifies the performance of S-ATA channels. Yes* Set this value to enable S-ATA enhanced mode. This is the optimal and fail-safe default setting. Set this value to allow the BIOS to boot legacy operating systems. Advanced Menu MUNGO560 User’s Guide...
  • Page 86 This is the optimal and fail-safe default setting. Primary/Secondary/Third/Fourth IDE Master Select a hard disk detected by the system and press ENTER. Primary/Secondary/Third/Fourth IDE Slave Select a hard disk detected by the system and press ENTER. MUNGO560 User’s Guide 5-10...
  • Page 87 Set this option to stop the BIOS from searching the IDE bus for IDE devices in 30 seconds. This is the default setting and is recommended for all IDE devices that are set to AUTO in the BIOS setting. Advanced Menu 5-11 MUNGO560 User’s Guide...
  • Page 88 Each P-ATA interface supports one master drive and one optional slave drive. Each S-ATA interface supports one master drive. The MUNGO560 has one IDE connector which is the primary IDE interface. The secondary IDE interface is connected to the Compact Flash connector, which only supports a single drive, either master or slave.
  • Page 89 Masters or Slaves on your machine. Some older drives, however, do not use Autotyping and require selecting type User and entering a pre-defined fixed-disk type value, such as 1 to 39, or specifying the drive parameters Advanced Menu 5-13 MUNGO560 User’s Guide...
  • Page 90 CMOS, you cannot access the data on your drive. CAUTION Incorrect settings can cause your system to malfunction. To correct mistakes, return to Setup and restore the Setup Defaults with [F9] and re-enter the correct drive parameters. MUNGO560 User’s Guide 5-14...
  • Page 91 This option indicates that an IDE CD-ROM drive is attached to the specified channel. The BIOS will not search for additional IDE drives on this channel. ARMD This options specifies an ATAPI removable media device, such as: LS-120 Advanced Menu 5-15 MUNGO560 User’s Guide...
  • Page 92 Set this value to allow the BIOS to auto-detect multi-sector transfer on the specified channel. This is the default setting. The data to and from the device will occur multiple sectors at a time. This is the optimal and fail-safe default setting. MUNGO560 User’s Guide 5-16...
  • Page 93 Set this value to prevent the BIOS from using the SMART feature. Auto* Set this value to allow the BIOS to auto detect hard disk drive support. Use this setting if the IDE disk drive support cannot be determined. This is the default setting. Advanced Menu 5-17 MUNGO560 User’s Guide...

  • Page 94: Peripheral Configuration Submenu

    Set this value to allow the serial port to use 2E8 as its I/O port address and IRQ 3 for the interrupt address. If the system will not use a serial device, it is best to set this port to Disabled. MUNGO560 User’s Guide 5-18...
  • Page 95 Set this value to allow the serial port to use 2E8 as its I/O port address and IRQ 3 for the interrupt address. If the system will not use a serial device, it is best to set this port to Disabled. Advanced Menu 5-19 MUNGO560 User’s Guide...
  • Page 96 Repost Video on S3 Resume This option determines whether to invoke the VGA BIOS POST on S3 (STR) resume. No is the optimal and fail-safe default setting. The asterisk represents the default value. Options: No, Yes* MUNGO560 User’s Guide 5-20...
  • Page 97 Disabled* This option disables adding the SCI IRQ into the ACPI APIC table. This is the optimal and fail-safe default setting. Enabled This option enables adding the SCI IRQ into the ACPI APIC table. Advanced Menu 5-21 MUNGO560 User’s Guide...
  • Page 98 ACPI Machine Language (AML) is a binary code format that the operating system's ACPI AML interpreter parses to discover the machine's properties. On boot up, the BIOS startup code copies it into system memory, where it can be interpreted by the operating system’s ACPI AML interpreter. MUNGO560 User’s Guide 5-22...
  • Page 99 This selection enables the event log to log all PCI errors that occur. Disabled* Set this value to disable the PCI Error Logging function. This is the optimal and fail-safe default setting. Enabled Set this value to enable PCI Error Logging. Advanced Menu 5-23 MUNGO560 User’s Guide...
  • Page 100 Select the flow control for console redirection. Options: None*, Hardware, Software Redirection after BIOS Post Options: Always*, Disabled, Boot Loader, Terminal Type Select the target terminal type. Options: ANSI*, VT100, VT-UT58 VT UTF8 Combo Key Select Options: Disabled*, Enabled MUNGO560 User’s Guide 5-24...
  • Page 101 DOS. Port 64/60 Emulation This choice enables I/O Port 60h/64h emulation support. Enable this for USB keyboard legacy support for non-USB aware OSes. Options: Disabled*, Enabled Advanced Menu 5-25 MUNGO560 User’s Guide...
  • Page 102 A dummy FDD device is created that will be associated with the hotplugged FDD later. Auto option creates this dummy device only if there is no USB FDD present. The asterisk represents the default value. Options: Auto*, Enabled, Disabled MUNGO560 User’s Guide 5-26...
  • Page 103 This function enables system health monitoring. Disabled Set this value to disable the hardware health function. Enabled* Set this value to monitor the system’s health status. This is the optimal and fail-safe default setting. Advanced Menu 5-27 MUNGO560 User’s Guide...

  • Page 104: Pci/Pnp Menu

    This option sets the PCI latency to 160 PCI clock cycles. This option sets the PCI latency to 192 PCI clock cycles. This option sets the PCI latency to 224 PCI clock cycles. This option sets the PCI latency to 248 PCI clock cycles. MUNGO560 User’s Guide 5-28...
  • Page 105 Set this value to allow or prevent the use of PCI IDE busmastering. Disabled* Set this value to prevent PCI busmastering. This is the default setting. Enabled This option specifies that the IDE controller on the PCI local bus has mastering capabilities. PCI/PnP Menu 5-29 MUNGO560 User’s Guide...
  • Page 106 Use this setting only if there is an IDE adapter card installed in PCI Slot 6. This option is available even if the system does not have a PCI Slot 6. If the system does not have a PCI Slot 6, do not use this setting. MUNGO560 User’s Guide 5-30...
  • Page 107 This setting allows the specified DMA to be used by PCI/ DMA Channel 1 PnP device. DMA Channel 3 DMA Channel 5 Reserved This setting allows the specified DMA to be used by a DMA Channel 6 legacy ISA device. DMA Channel 7 PCI/PnP Menu 5-31 MUNGO560 User’s Guide...

  • Page 108: Boot Menu

    Operating System. Removable Devices, Hard Drive, and Network Boot are the generic types of devices on your system from which you can boot an operating system. You may have more than one device of each MUNGO560 User’s Guide 5-32...

  • Page 109: Boot Settings Configuration

    OEM logo. Enabled Set this value to allow the computer system to display the OEM logo. This is the default setting. Disabled* Set this value to allow the computer system to display the POST messages. Boot Menu 5-33 MUNGO560 User’s Guide...
  • Page 110 This allows the immediate use of 10-keys numeric keypad located on the right side of the keyboard. To confirm this, the Number Lock LED light on the keyboard will be lit. This is the default setting. MUNGO560 User’s Guide 5-34...
  • Page 111 When enabled, this function allows option ROMs to trap INT 19h. Disabled* Set this value to disable this function. This is the default setting. Enabled Set this value to allow the system to trap INT19h. Boot Menu 5-35 MUNGO560 User’s Guide...

  • Page 112: Security Menu

    To access the submenu for the following items, select the item and press <Enter>: Change Supervisor Password Change User Password Clear User Password The submenus are documented on the following pages. MUNGO560 User’s Guide 5-36...
  • Page 113 Select this option and press <Enter> to access the sub menu. You can use the submenu to change the user password. Clear User Password Select this option and press <Enter> to access the sub menu. You can use the sub menu to clear the user password. Security Menu 5-37 MUNGO560 User’s Guide...
  • Page 114 Possible VIRUS: Continue (Y/N)? _ The following appears after any attempt to format any cylinder, head, or sector of any hard disk drive via the BIOS INT 13 Hard disk drive Service: Format!!! Possible VIRUS: Continue (Y/N)? _ MUNGO560 User’s Guide 5-38...

  • Page 115: Chipset Menu

    This allows you to select the type of boot screen. The asterisk represents the default value. Options, VBIOS Default*, CRT, LFP, CRT + LFP, EFP, TV, CRT + EFP, CRT + TV, EFP + EFP2, EPP + TV Chipset Menu 5-39 MUNGO560 User’s Guide...
  • Page 116 PAL Minor Standards: PAL B*, /G, /D, /H, /I, /M, /N, /60 SECAM Standards: SECAM L*, /L1, /B, /D, /G, /H Flat Panel Scaling This option allows you to choose the flat-panel scaling. The asterisk represents the default value. Options, Auto*, Force Scaling, Disabled MUNGO560 User’s Guide 5-40...

  • Page 117: South Bridge Configuration

    Options: Auto*, disabled Onboard FPGA When enabled, the BIOS will enable and program the FPGA device to enable extended functionality, which can include additional GPIO, LPT port, COM port and/or custom functions. Options: Enabled*, Disabled Chipset Menu 5-41 MUNGO560 User’s Guide...

  • Page 118: Power Menu

    Select Power Button functionality. The asterisk represents the default value. Options: On/Off*, Suspend Resume after AC Power Loss Configure the system to power on or stay off when power resumes after AC power loss. The asterisk represents the default value. Options, Always On*, Stay Off MUNGO560 User’s Guide 5-42...

  • Page 119: Advanced Resume Event Controls

    Enable or disable PME wake from sleep states. The asterisk represents the default value. Options: Disabled*, Enabled RI Resume Enable or disable RI wake from sleep states. The asterisk represents the default value. Options: Disabled*, Enabled Power Menu 5-43 MUNGO560 User’s Guide...

  • Page 120: Exit Menu

    Values (as described below) or try to change the selections that caused the boot to fail. Discard Changes and Exit Use this option to exit Setup without storing in CMOS any new selections you may have made. The selections previously in effect remain in effect. MUNGO560 User’s Guide 5-44...
  • Page 121 You can make other changes before saving the values to CMOS. Load Failsafe Defaults This option allows you to load the system’s failsafe defaults. The program prompts with this message: Load Failsafe Defaults? [OK] [CANCEL] Exit Menu 5-45 MUNGO560 User’s Guide...
  • Page 122 This page intentionally left blank.
  • Page 123 Chapter 6 System Resource Allocations Contents IRQ Lines ..........6-3 DMA Channels .

  • Page 125: Irq Lines

    If disabled in setup, you can use this IRQ for other devices You can configure LPT using IRQ5, too. Numeric processor EIDE Channel 1 Compact If disabled in setup, you can use this Flash IRQ for other devices IRQ Lines MUNGO560 User’s Guide...

  • Page 126: Dma Channels

    DMA Channels Available Comment This can serve as a possible alternative DMA channel for the LPT in ECP mode. The DMA channel is only used for the ECP mode of LPT; it is available in other modes. Cascade MUNGO560 User’s Guide...

  • Page 127: I/O Addresses

    I/O Addresses I/O port addresses of the MUNGO560 are functionally identical to a standard PC/AT. All addresses not mentioned in this table should be available. Kontron recommends that you do not use I/O addresses below 0110hex with additional hardware for compatibility reasons, even if available.

  • Page 128: Memory Map

    VGA BIOS Free for ISA bus or shadow RAM. C0000h - C7FFFh is mainly used by external ISA VGA cards. CC000h - EFFFFh Free of ISA bus or shadow RAM in standard configurations. F0000h - FFFFFh System BIOS MUNGO560 User’s Guide...
  • Page 129 Chapter 7 Block Diagram Contents Overview ..........7-3...
  • Page 131 Overview This block diagram shows the details of the operating relations of the embedded board’s components. Overview MUNGO560 User’s Guide...
  • Page 132 This page intentionally left blank.
  • Page 133 Chapter 8 Troubleshooting Contents Troubleshooting ..........8-3 Common Problems .
  • Page 135 If these quick and simple steps fail to resolve the problem, contact Kontron Technical Support for further advanced troubleshooting or reference the “Support” pages on the Kontron web site (www.kontron.com).
  • Page 136 Note: In the case of a short, the power supply will sense the short and shut off. When the short is removed, the power supply should automatically sense the removal of the short and restore operation. If cables become damaged, contact Kontron for repair or replacement. MUNGO560 User’s Guide...
  • Page 137 If video comes up, replace each board one at a time. A faulty board will prevent the system from booting. d) Ensure the CPU and RAM are seated properly on the SBC. Consult the SBC manual for jumper settings. Common Problems MUNGO560 User’s Guide...
  • Page 138 When System cannot find a Install an operating system on the hard drive attempting to proper bootable sector or boot from a floppy disk. boot the system, on the boot device "No ROM BASIC" is displayed MUNGO560 User’s Guide...
  • Page 139 “Format A:/S”. This will format and move the boot missing or the disk is damaged required boot files to the floppy disk for DOS. Other operating systems may require re- installation. Common Problems MUNGO560 User’s Guide...
  • Page 140 BIOS settings are Verify the BIOS settings are correct on the incorrect SCSI controller. If uncertain of the controller BIOS settings, most controllers have an option to “Reset” the BIOS to default configuration. MUNGO560 User’s Guide...

Table of Contents
