Sharp DV-NC100S Service Manual
Sharp DV-NC100S Service Manual

Sharp DV-NC100S Service Manual

Vcr/dvd combination
Hide thumbs Also See for DV-NC100S:

Advertisement

Quick Links

1st Edition
DV-NC100
OPERATE
PULL OPEN
STOP/
REW
FF
EJECT
PLAY
REC
TIMER
NTSC/PAL
MAIN SECTION
1. SPECIFICATIONS ................................................................................................................................................ 1-1-1
2. LASER BEAM SAFETY PRECAUTIONS ............................................................................................................. 1-2-1
3. IMPORTANT SAFEGUARDS AND PRECAUTIONS ............................................................................................ 1-3-1
4. STANDARD NOTES FOR SERVICING ................................................................................................................ 1-4-1
5. PREPARATION FOR SERVICING ....................................................................................................................... 1-5-1
6. OPERATING CONTROLS AND FUNCTIONS ...................................................................................................... 1-6-1
7. CABINET DISASSEMBLY INSTRUCTIONS ........................................................................................................ 1-7-1
8. ELECTRICAL ADJUSTMENT INSTRUCTIONS ................................................................................................... 1-8-1
9. FIRMWARE RENEWAL MODE ............................................................................................................................ 1-9-1
10. TROUBLESHOOTING ........................................................................................................................................ 1-10-1
11. BLOCK DIAGRAMS ............................................................................................................................................ 1-11-1
12. FUNCTION INDICATOR SYMBOLS ................................................................................................................... 1-11-9
13. SCHEMATIC DIAGRAMS/ CBA'S AND TEST POINTS ..................................................................................... 1-12-1
14. WAVEFORMS ..................................................................................................................................................... 1-13-1
15. WIRING DIAGRAM ............................................................................................................................................. 1-14-1
16. IC PIN FUNCTION DESCRIPTIONS .................................................................................................................. 1-15-1
17. LEAD IDENTIFICATIONS ................................................................................................................................... 1-16-1
18. EXPLODED VIEWS ............................................................................................................................................ 1-17-1
19. MECHANICAL PARTS LIST ............................................................................................................................... 1-18-1
20. ELECTRICAL PARTS LIST ................................................................................................................................ 1-19-1
1. STANDARD MAINTENANCE ............................................................................................................................... 2-1-1
2. SERVICE FIXTURE AND TOOLS ........................................................................................................................ 2-2-1
3. MECHANICAL ALIGNMENT PROCEDURES ...................................................................................................... 2-3-1
4. DISASSEMBLY / ASSEMBLY PROCEDURES OF DECK MECHANISM ............................................................ 2-4-1
5. ALIGNMENT PROCEDURES OF MECHANISM .................................................................................................. 2-5-1
6. DECK EXPLODED VIEWS ................................................................................................................................... 2-6-1
7. DECK PARTS LIST ............................................................................................................................................... 2-7-1
SHARP CORPORATION
DV-NC100S/DV-NC100S(S)/DV-NC100S(Q)/DV-NC100S(Y)/DV-NC100S(R)
SERVICE MANUAL
VCR/DVD COMBINATION
OPEN/CLOSE
OUTPUT
CH
VCR
DVD
STOP
PLAY
(TRACKING)
CONTENTS
MODEL
In the interests of user-safety (Required by safety
regulations in some countries) the set should be
restored to its original condition and only parts
identical to those specified be used.
This document has been published to be used for
after sales service only.
The contents are subject to change without notice.
1
S23X9DV-SL20U
DV-NC100S
DV-NC100S(S)
DV-NC100S(Q)
DV-NC100S(Y)
DV-NC100S(R)
