Sharp VC-A413U Service Manual

Table of Contents

Quick Links

VC-A412U/H812U

VC-A413U/H813U

1. GENERAL INFORMATION............................................................................................................ 5

2. DISASSEMBLY AND REASSEMBLY ............................................................................................ 7

3. FUNCTION OF MAJOR MECHANICAL PARTS ......................................................................... 10

4. ADJUSTMENT, REPLACEMENT AND ASSEMBLY OF MECHANICAL UNITS ........................ 12

5. ELECTRICAL ADJUSTMENT ...................................................................................................... 31

6. MECHANISM OPERATION FLOWCHART AND TROUBLESHOOTING GUIDE ...................... 33

7. TROUBLESHOOTING ................................................................................................................. 39

8. BLOCK DIAGRAM ....................................................................................................................... 50

9. SCHEMATIC DIAGRAM AND PWB FOIL PATTERN .................................................................. 58

10. PARTS LIST ................................................................................................................................ 73

11. EXPLODED VIEW OF MECHANICAL PARTS ............................................................................ 82

12. PACKING OF THE SET .............................................................................................................. 87

SHARP CORPORATION

SERVICE MANUAL

MODELS

In the interests of user-safety (Required by safety regula-

tions in some countries) the set should be restored to its

original condition and only parts identical to those specified

be used.

CONTENTS

VC-A412U/A413U/H812U

VC-A412U/A413U/H812U/H813U .............. Models for U.S.A.

This document has been published to be used for

after sales service only.

The contents are subject to change without notice.

VIDEO CASSETTE RECORDER

VC-A412U

VC-A413U

VC-H812U

VC-H813U

.............. Models for Canada

VC-A412U/A413U

VC-H812U/H813U

S10V4VC-A412U

Page

Table of Contents

Need help?

Do you have a question about the VC-A413U and is the answer not in the manual?

Questions and answers

Summary of Contents for Sharp VC-A413U

Page 1: Table Of Contents
VC-A412U/A413U VC-A412U/A413U VC-H812U/H813U VC-H812U/H813U SERVICE MANUAL S10V4VC-A412U VIDEO CASSETTE RECORDER VC-A412U VC-A413U VC-A412U/H812U VC-H812U VC-H813U MODELS VC-A413U/H813U In the interests of user-safety (Required by safety regula- tions in some countries) the set should be restored to its original condition and only parts identical to those specified be used.
Page 2 VC-A412U/A413U VC-H812U/H813U IMPORTANT SERVICE NOTES BEFORE RETURNING THE VIDEO CASSETTE etc.) and measure the AC voltage drop across the RECORDER resistor. Reverse the AC plug on the set and repeat AC voltage measurements for each exposed part. Any reading of 0.45V rms (this corresponds to 0.3mA Before returning the video cassette recorder to the user, perform the following safety checks.
Page 3 VC-A412U/A413U VC-H812U/H813U NOTES DE SERVICE IMPORTANTES AVANT DE RENDRE LE MAGNETOSCOPE pièces métalliques exposées ayant un parcours de retour au châssis (connexions d’antenne, coffret Avant de rendre le magnétoscope à l’utilisateur, effectuer métallique, tétes de vis, boutons et arbres de commande, etc.) et mesurer la chute de tension CA les vérifications de sécurité...
Page 4 VC-A412U/A413U VC-H812U/H813U PRECAUTIONS IN PART REPLACEMENT When servicing the unit with power on, be careful to the section marked white all over. This is the primary power circuit which is live. When checking the soldering side in the tape travel mode, make sure first that the tape has been loaded and then turn over the PWB with due care to the primary power circuit.
Page 5: General Information
Dimensions (approx.): 360 (W) x 92.5 (H) x 256 (D) mm (14-3/16" x 3-41/64" x 10-5/64") (VC-A412U/H812U) 360 (W) x 92.5 (H) x 254.5 (D) mm (14-3/16" x 3-41/64" x 10-1/32") (VC-A413U/H813U) Accessories included: 75 ohm coaxial cable, Operation manual, Infrared remote control, Battery (2 pcs.), Warranty Card Note: Specifications are subject to change without notice.
Page 6 VC-A412U/A413U VC-H812U/H813U 1-3 LOCATION OF MAJOR COMPONENTS AND CONTROL...
Page 7: Disassembly And Reassembly
Remove 1 screw w with top cabinet fix angle. ANTENNA ANTENNA TERMINAL TERMINAL COVER COVER VC-H812U/H813U VC-A412U/A413U MECHANISM/ MAIN PWB ASSEMBLY VC-H812U/H813U VC-A413U/H813U FRONT PANEL TOP CABINET FIX ANGLE VC-A412U/H812U MAIN FRAME FRONT PANEL OPERATION PWB...
Page 8 VC-A412U/A413U VC-H812U/H813U 2-2 DISASSEMBLING THE MECHANISM/MAIN PWB ASSEMBLY 2. Removing the mechanism and cassette housing. 1. When removing the mechanism from the main PWB, Remove 2 screws 4 fixing the cassette housing to the remove the antenna cover 1 screw 1, and remove the mechanism, and remove the cassette housing.
Page 9 VC-A412U/A413U VC-H812U/H813U 2-3 CARES WHEN REASSEMBLING cassette housing. (Conditions: When mechanism and PWB INSTALLING THE CASSETTE HOUSING have been installed) When the cassette housing is installed on the mechanism, the initial setting is essential condition. 2. Mechanical initial setting There are two initial setting methods, namely electrical and Feed the pulley feed gear of loading motor with screw mechanical.
Page 10: Function Of Major Mechanical Parts
VC-A412U/A413U VC-H812U/H813U 3. FUNCTION OF MAJOR MECHANICAL PARTS (TOP VIEW) Function Function Full erase head Take-up main brake Supply pole base ass’y Pinch drive cam Tension arm A/C head ass’y Idler wheel ass’y Reverse guide lever ass'y Pinch drive lever ass’y Casecon drive gear Supply reel disk Take-up reel disk...
Page 11 VC-A412U/A413U VC-H812U/H813U FUNCTION OF MAJOR MECHANICAL PARTS (BOTTOM VIEW) Function Function Drum ass’y Reel belt Loading motor Clutch lever Drum drive motor Limiter pulley ass'y Take-up pole base ass’y Shifter Slow brake lever Master cam Capstan D.D. motor...
Page 12: Adjustment, Replacement And Assembly Of Mechanical Units
VC-A412U/A413U VC-H812U/H813U 4. ADJUSTMENT, REPLACEMENT AND ASSEMBLY OF MECHANICAL UNITS The explanation given below relates to the on-site general service (field service) but it does not relates to the adjustment and replacement which need high-grade equipment, jigs and skill. For example, the drum assembling, replacement and adjustment service must be performed by the person who have finished the technical courses.
Page 13 VC-A412U/A413U VC-H812U/H813U 4-2 MAINTENANCE CHECK ITEMS AND EXECUTION TIME Perform the maintenance with the regular intervals as follows so as to maintain the quality of machine. Maintained 1000 1500 2000 Possible symptom Remarks hrs. hrs. hrs. hrs. encountered Parts Abnormal rotation or significant Guide roller ass’y vibration requires replacement.
Page 14 VC-A412U/A413U VC-H812U/H813U 4-3. REMOVING AND INSTALLING THE CAS- Notes: SETTE HOUSING 1. When fitting the S/E sensor holder to the cassette controller frame L/R, take care. • Removal 2. Misengagement of teeth of casecon drive gear and drive 1. In the cassette removing mode, remove the cassette. angle gear causes malfunction.
Page 15 VC-A412U/A413U VC-H812U/H813U 4-5. REEL DISK REPLACEMENT AND HEIGHT 4. Assemble the Supply main brake ass'y. CHECK Notes: • Removal 1. When installing the reel disk, take due care so that the 1. Remove the cassette housing control assembly. tension band ass'y is not deformed and grease does no 2.
Page 16 VC-A412U/A413U VC-H812U/H813U Note: Notes: Whenever replacing the reel disk, perform the height check- 1. Hold the torque gauge by hand so that it is not moved. ing and adjustment. 2. Do not keep the reel disk in lock state. Do not allow long- time measurement.
Page 17 VC-A412U/A413U VC-H812U/H813U Notes: 4-9. CHECKING AND ADJUSTMENT OF TAKE- 1. Hold the torque gauge by hand so that it is not moved. UP TORQUE IN VIDEO SEARCH REWIND 2. Do not keep the reel disk in lock state. Do not allow long- MODE time measurement.
Page 18 VC-A412U/A413U VC-H812U/H813U 4-10. CHECKING THE VIDEO SEARCH REWIND BACK TENSION • Remove the cassette housing control assembly. • After short-circuiting TP803 and TP802 provided at Tension gauge Pinch roller operation PWB, plug in the power cord. 900 - 1,200gf • Checking 1.
Page 19 VC-A412U/A413U VC-H812U/H813U 2. Visually check to see if the right edge of the tension pole Tension pole adjuster adjusting range is within the 2.3 ± 0.25 from the right edge of the Sup guide shaft. Tension pole adjuster Sup guide shaft Tension pole 2.3 ±...
Page 20 VC-A412U/A413U VC-H812U/H813U • Adjustment • Checking the brake torque at the take-up side 1. If the indication of torque cassette meter is lower than the setting, shift the tension spring engagement to the part A. Torque gauge 2. If the indication of torque cassette meter is higher than the setting, shift the tension spring engagement to the part B.
Page 21 VC-A412U/A413U VC-H812U/H813U 4-15. REPLACEMENT OF A/C (Audio/Control) 3. Align the left end of gear of A/C head arm with the punched mark of chassis, tentatively tighten the screws HEAD 1 and 2 so as to ensure smooth motion of A/C head 1.
Page 22 VC-A412U/A413U VC-H812U/H813U 4-16. A/C HEAD HEIGHT ROUGH ADJUSTMENT 4-17. HEIGHT ADJUSTMENT OF REVERSE GUIDE • Setting Azimuth screw 1. Adjust the height from the mechanism chassis to the reverse guide lower flange to 13.38 mm, using the reverse guide height adjustment jig, in tape loading state.
Page 23 VC-A412U/A413U VC-H812U/H813U Notes: 4-18. ADJUSTMENT OF TAPE DRIVE TRAIN 1. Previously set the tracking control in the center position, 1. Tape run rough adjustment and adjust the envelop waveform to maximum with X 1 Remove the cassette housing control assembly. value adjustment nut.
Page 24 VC-A412U/A413U VC-H812U/H813U 3 Next, Press the tracking button (+), (–) and change the envelope waveform from max to min and from PB CHROMA min to max. At this time adjust the height of supply Envelope and take-up side guide roller with the adjustment driver (JiGDRiVERH-4) so that the envelope wave- form changes nearly parallel.
Page 25 VC-A412U/A413U VC-H812U/H813U 4-20. REPLACEMENT OF DRUM D.D. MOTOR 4-19. REPLACEMENT OF THE CAPSTAN D.D. 1. Set the ejection mode. (DIRECT DRIVE) MOTOR 2. Withdraw the main power plug from the socket. • Remove the mechanism from the main PWB (refer to 2- 2 "item 1 When removing the mechanism from the main •...
Page 26 VC-A412U/A413U VC-H812U/H813U 4-21. REPLACING THE UPPER AND LOWER 4-22. ASSEMBLING OF PHASE MATCHING DRUM ASSEMBLY MECHANISM COMPONENTS • Assemble the phase matching mechanism compo- • Replacement (Perform in the numerical order) nents in the following order. 1 Remove the motor as stated in 4-20 D.D. motor replace- 1.
Page 27 VC-A412U/A413U VC-H812U/H813U 1Insert Reverse Guide Lever Ass’y Insert reverse guide lever ass'y 2 Insert pinch drive cam Align here. Turn the reverse guide lever assembly counterclockwise Fit the pinch drive cam so that the notch of pinch to the stopper. drive cam aligns with the dent of pinch drive lever assembly.
Page 28 VC-A412U/A413U VC-H812U/H813U 1. Make sure that the loading gear is at the Phase-Match- 4-23. INSTALLING THE SHIFTER ing point 1 as shown below. 2. Install, paying attention to insert point 5 and release point 3. Drum 3. For the phase matching at the insert point 1, see the Capstan Phase-Matching point 2 as shown below.
Page 29 VC-A412U/A413U VC-H812U/H813U 4-24. NSTALLING THE MASTER CAM (AT 4-25. REPLACEMENT OF LOADING MOTOR • Removal REAR SIDE OF MECHANISM CHASSIS) 1. Make sure beforehand that the shifter is at the point as shown below. 2. Place the master cam in the position as shown below. E ring (XRESJ30-06000) Master cam...
Page 30 VC-A412U/A413U VC-H812U/H813U 4-26. ASSEMBLY OF CASSETTE HOUSING 1. Drive Gear and R Drive angle ass’y MSPRT0381AJFJ Apply grease Apply grease Apply grease Figure 4-47. 2. Synchro Gear, Drive Gear L and Drive Gear R LANGF9592AJFW Top surface should be free from scratches or soil. Drive angle Drive gear R Frame...
Page 31: Electrical Adjustment
VC-A412U/A413U VC-H812U/H813U 5. ELECTRICAL ADJUSTMENT Notes: • Before the adjustment: Electrical adjustments discussed here are often required after replacement of electronic components and mechanical parts such as video heads. Check that the mechanism and all electric components are in good working condition prior to the adjustments,otherwise adjustments can not be completed.
Page 32 VC-A412U/A413U VC-H812U/H813U SERVO CIRCUIT ADJUSTMENT 5-2 ADJUSTMENT OF FV (False Vertical Sync) OF STILL PICTURE 5-1 ADJUSTMENT OF HEAD SWITCHING Measuring Color TV monitor POINT instrument Measuring Dual-trace oscilloscope Mode Playback still instrument Cassette Self-recorded tape (SP mode) Mode Playback (See Note below 2) Cassette Alignment tape (VROEFZHS)
Page 33 VC-A412U/A413U VC-H812U/H813U...
Page 34 VC-A412U/A413U VC-H812U/H813U...
Page 35 VC-A412U/A413U VC-H812U/H813U...
Page 36 VC-A412U/A413U VC-H812U/H813U...
Page 37 VC-A412U/A413U VC-H812U/H813U...
Page 38 VC-A412U/A413U VC-H812U/H813U...
Page 39 VC-A412U/A413U VC-H812U/H813U...
Page 40 VC-A412U/A413U VC-H812U/H813U...
Page 41 VC-A412U/A413U VC-H812U/H813U...
Page 42 VC-A412U/A413U VC-H812U/H813U...
Page 43 VC-A412U/A413U VC-H812U/H813U...
Page 44 VC-A412U/A413U VC-H812U/H813U...
Page 45 VC-A412U/A413U VC-H812U/H813U...
Page 46 VC-A412U/A413U VC-H812U/H813U...
Page 47 VC-A412U/A413U VC-H812U/H813U...
Page 48 VC-A412U/A413U VC-H812U/H813U...
Page 49 VC-A412U/A413U VC-H812U/H813U...
Page 50: Block Diagram
VC-A412U/A413U VC-A412U/A413U VC-H812U/H813U VC-H812U/H813U 8. BLOCK DIAGRAM SYSTEM SERVO BLOCK DIAGRAM 50~51...
Page 51 VC-A412U/A413U VC-A412U/A413U VC-H812U/H813U VC-H812U/H813U SIGNAL FLOW BLOCK DIAGRAM(VC-A412U/A413U) Playback luminance signal Playback chroma signal Audio playback signal E-E signal Audio recording signal E-E signal(Audio) Recording luminance signal Recording chroma signal 52~53...
Page 52 VC-A412U/A413U VC-A412U/A413U VC-H812U/H813U VC-H812U/H813U SIGNAL FLOW BLOCK DIAGRAM(VC-H812U/H813U) Playback luminance signal Playback chroma signal Audio playback signal E-E signal Recording luminance signal Recording chroma signal Audio recording signal E-E signal(Audio) 54~55...
Page 53 VC-A412U/A413U VC-H812U/H813U POWER CIRCUIT BLOCK DIAGRAM...
Page 54 VC-A412U/A413U VC-H812U/H813U SCHEMATIC DIAGRAM • The indicated voltages in the following diagram IMPORTANT SAFETY NOTICE: are measured with an SSVM, upon receiving color bars (400 Hz sound signal) in either the PARTS MARKED WITH " å " ( ) ARE record mode or the play mode voltage is indi- IMPORTANT FOR MAINTAINING THE SAFETY cated as follows.
Page 55: Schematic Diagram And Pwb Foil Pattern
VC-A412U/A413U VC-A412U/A413U VC-H812U/H813U VC-H812U/H813U 9. SCHEMATIC DIAGRAM AND PWB FOIL PATTERN MAIN CIRCUIT(1) * VOLTAGE MEASUREMENT MODE PB ..Parentheses ( REC ..Without Parentheses 58~59...
Page 56 VC-A412U/A413U VC-A412U/A413U VC-H812U/H813U VC-H812U/H813U MAIN CIRCUIT(2) * VOLTAGE MEASUREMENT MODE PB ..Parentheses ( REC ..Without Parentheses 60~61...
Page 57 VC-A412U/A413U VC-A412U/A413U VC-H812U/H813U VC-H812U/H813U MAIN CIRCUIT(3) * VOLTAGE MEASUREMENT MODE PB ..Parentheses ( REC ..Without Parentheses 62~63...
Page 58 VC-A412U/A413U VC-A412U/A413U VC-H812U/H813U VC-H812U/H813U MAIN CIRCUIT(4) * VOLTAGE MEASUREMENT MODE PB ..Parentheses ( REC ..Without Parentheses 64~65...
Page 59 VC-A412U/A413U VC-H812U/H813U OPERATION CIRCUIT * VOLTAGE MEASUREMENT MODE PB ..Parentheses ( REC ..Without Parentheses...
Page 60 VC-A412U/A413U VC-H812U/H813U PWB FOIL PATTERN OPERATION PWB Component Side Wiring Side...
Page 61 VC-A412U/A413U VC-A412U/A413U VC-H812U/H813U VC-H812U/H813U MAIN PWB Component Side 68~69...
Page 62 VC-A412U/A413U VC-A412U/A413U VC-H812U/H813U VC-H812U/H813U MAIN PWB Wiring Side 70~71...
Page 63 VC-A412U/A413U VC-H812U/H813U - M E M O -...
Page 64: Parts List
Pour que votre commande soit rapidement et correctement remplie, 3. PART NO. 4. DESCRIPTION veuillez fournir les renseignements suivants. In USA: Contact your nearest SHARP Parts Distributor to order. 1. NUMERO DU MODELE 2. NO. DE REF For location of SHARP Parts Distributor, 3. NO. DE PIECE 4.
Page 65 VC-A412U/A413U VC-H812U/H813U Ref. No. Part No. Description Code Ref. No. Part No. Description Code Q651 VS2SD1306-E1E V 2SD1306-E D992 VHD1SS119//-1 V 1SS119 (VC-H812U/H813U) Q652 VS2SD1306-E1E V 2SD1306-E D992 RH-DX0475CEZZ V DX0475CE å IC901 (VC-H812U/H813U) RH-FX0034CEZZ V PC817 Q653 VSKRA104S//-1 V KRA104S å...
Page 66 VC-A412U/A413U VC-H812U/H813U Ref. No. Part No. Description Code Ref. No. Part No. Description Code C163 VCEA9M1HW474M V 0.47 50V Electrolytic C501 VCEA9M0JW107M V 100 6.3V Electrolytic (VC-H812U/H813U) C502 VCKYCY0JF105Z 6.3V Ceramic C164 VCKYCY1CB104K V 0.1 16V Ceramic C503 VCKYCY1HB472K V 4700p 50V Ceramic (VC-H812U/H813U) C504 VCEA9M1HW225M V 2.2...
Page 67 VC-A412U/A413U VC-H812U/H813U Ref. No. Part No. Description Code Ref. No. Part No. Description Code C674 VCKYCY1CF224Z V 0.22 16V Ceramic C791 VCKYCY1HB392K V 3900p 50V Ceramic (VC-H812U/H813U) C792 VCEA9M1CW476M V 47 16V Electrolytic C675 VCKYCY1CF104Z V 0.1 16V Ceramic C794 VCKYCY1EB223K V 0.022 25V Ceramic (VC-H812U/H813U) C795...
Page 68 VC-A412U/A413U VC-H812U/H813U Ref. No. Part No. Description Code Ref. No. Part No. Description Code R202 VRS-CY1JF182J V 1.8k 1/16W Metal Oxide R654 VRS-CY1JF682J V 6.8k 1/16W Metal Oxide R203 VRS-CY1JF682J V 6.8k 1/16W Metal Oxide (VC-H812U/H813U) R207 VRS-CY1JF101J V 100 1/16W Metal Oxide R655 VRS-CY1JF473J V 47k 1/16W Metal Oxide...
Page 69 VC-A412U/A413U VC-H812U/H813U Ref. No. Part No. Description Code Ref. No. Part No. Description Code R728 VRS-CY1JF182J V 1.8k 1/16W Metal Oxide R846 VRD-RA2BE103J V 10k 1/8W Carbon R729 VRD-RA2BE154J V 150k 1/8W Carbon R847 VRD-RA2BE474J V 470k 1/8W Carbon R731 VRS-CY1JF103J V 10k 1/16W Metal Oxide R848...
Page 70 Code Ref. No. Part No. Description Code S889 QSW-K0086GEZZ J Switch, Play J202 QJAKG0006AJZZ V Jack, Front AV Jack (VC-A413U/H813U) (VC-H812U/H813U) S889 QSW-K0004AJZZ V Switch, Play P701 QPLGZ0883GEZZ J Plug, 8 Pin (VC-A413U/H813U) RMC801 RRMCU0081GEZZ J Remote Receiver S890 QSW-K0086GEZZ...
Page 71 HDECQ1970AJSA V Casstte Flap(VC-A412U) XWHJZ31-08052 V Washer, W3.1-5.2-0.8 500-3 HDECQ2146AJSA V Casstte Flap(VC-H813U) LX-RZ3015GEFJ J CS Washer 500-3 HDECQ2165AJSA V Casstte Flap(VC-A413U) 500-4 HDECQ2148AJSA V Window Dec. (VC-A413U/H813U) 500-4 HDECQ2157AJSA V Window Dec.(VC-H812U) AH CASSETTE HOUSING CONTROL PARTS 500-4 HDECQ2168AJSA V Window Dec.(VC-A412U)
Page 72 (NOT REPLACEMENT ITEM) TGAN-0001AJZZ - Warranty Card(U.S.A Only) — PACKING PARTS (NOT REPLACEMENT ITEM) SPAKC4260AJZZ - Packing Case(VC-H813U) — SPAKC4261AJZZ - Packing Case(VC-A413U) — SPAKC4264AJZZ - Packing Case(VC-H812U) — SPAKC4266AJZZ - Packing Case(VC-A412U) — SPAKX1073AJZZ - Packing Add. — (VC-A412U/H812U) SPAKX1083AJZZ - Packing Add.
Page 73: Exploded View Of Mechanical Parts
VC-A412U/A413U VC-H812U/H813U 11. EXPLODED VIEW OF MECHANICAL PARTS Ref. No. Part No. Description Code Ref. No. Part No. Description Code MECHANISM CHASSIS PARTS...
Page 74 VC-A412U/A413U VC-H812U/H813U Ref. No. Part No. Description Code Ref. No. Part No. Description Code CASSETTE HOUSING CONTROL PARTS...
Page 75 VC-A412U/A413U VC-H812U/H813U Ref. No. Part No. Description Code Ref. No. Part No. Description Code CABINET PARTS VC-H812U/H813U VC-A412U/A413U VC-H812U/H813U VC-A412U/A413U...
Page 76 VC-A412U/A413U VC-H812U/H813U Ref. No. Part No. Description Code Ref. No. Part No. Description Code FRONT PANEL PARTS(VC-A412U/H812U) 500-7 500-3 500-6 500-1 500-5 500-4 502-2 502-1 PRECAUTION ON FRONT PANEL SET-UP Cassette cover Front panel Cassette housing Cassette cover open lever Cassette cover Cassette cover Cassette cover...
Page 77 VC-A412U/A413U VC-H812U/H813U Ref. No. Part No. Description Code Ref. No. Part No. Description Code FRONT PANEL PARTS(VC-A413U/H813U) 500-7 500-3 500-9 500-6 500-10 500-8 500-4 500-1 PRECAUTION ON FRONT PANEL SET-UP Cassette cover Front panel Cassette housing Cassette cover open lever...
Page 78: Packing Of The Set
Operation Manual(for Canada) TGAN-0001AJZZ Warranty Card(U.S.A. Only) RRMCG0235AJSB Dry Battery RRMCG0235AJSC Infrared Remote Control Unit QCNW-8115AJZZ QCNW-0322AJZZ 75 ohm Coaxial Cable SPAKX1083AJZZ(VC-A413U/H813U) SPAKX1073AJZZ(VC-A412U/H812U) Packing Add. TLABK0005AJZZ No. Label SPAKC4260AJZZ (VC-H813U) SPAKC4261AJZZ (VC-A413U) SPAKC4266AJZZ (VC-A412U) SPAKC4264AJZZ (VC-H812U) Packing Case MARK Not Replacement Item...
Page 79 Code Ref. No. Part No. Description Code COPYRIGHT C 2000 BY SHARP CORPORATION ALL RIGHTS RESERVED. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without prior written permission of the publisher.
