Sharp VC-A592U Service Manual

Hide thumbs Also See for VC-A592U:
Table of Contents

Advertisement

Quick Links

VC-A592U/H992U
VC-A593U/H993U
VC-A5933U
VC-H994U
1. GENERAL INFORMATION .............................. 5
1-1 FEATURES ................................................. 5
1-2 SPECIFICATIONS ..................................... 5
AND CONTROL ......................................... 6
MAIN PWB ASSEMBLY ............................. 8
PARTS ............................................................ 10
ADJUSTMENT JIG .................................. 12
5. ELECTRICAL ADJUSTMENT ........................ 31
POINT ....................................................... 32
SHARP CORPORATION
SERVICE MANUAL
MODELS
In the interests of user-safety (Required by safety regula-
tions in some countries) the set should be restored to its
original condition and only parts identical to those specified
be used.
CONTENTS
Page
7. TROUBLESHOOTING ................................... 40
8. BLOCK DIAGRAM ..........................................52
10.PARTS LIST .................................................... 79
12.PACKING OF THE SET ................................. 94
VC-A593U/A5933U/H992U .............. Models for Canada
VC-A592U/A593U/H993U/H994U .... Models for U.S.A.
This document has been published to be used for
after sales service only.
The contents are subject to change without notice.
1
VIDEO CASSETTE RECORDER
VC-A592U
VC-A593U
VC-A5933U
VC-H992U
VC-H993U
VC-H994U
OF STILL PICTURE ................................. 32
5-3 CHECKING OF OFF TRACK ................... 32
SEPARATION ...........................................33
AND TROUBLESHOOTING GUIDE .............. 34
PATTERN ....................................................... 60
PARTS ............................................................ 88
VC-A592U/A593U
VC-A592U/A593U
VC-A5933U/H992U
VC-A5933U/H992U
VC-H993U/H994U
VC-H993U/H994U
S39D7VC-A592U
Page

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VC-A592U and is the answer not in the manual?

Questions and answers

Steven eibl
January 26, 2025

how to set up for tv

0
1 comments:
Mr. Anderson
February 10, 2025

To set up the Sharp VC-A592U for TV:

1. Connect the Antenna/Cable – Use the included 75-ohm coaxial cable to connect the VCR’s ANT IN jack to your TV antenna or cable source.
2. Connect to TV – Use another coaxial cable to connect the VCR’s OUT TO TV jack to your TV’s antenna input.
3. Power On – Plug in the VCR and turn it on.
4. TV Channel Setup – Set your TV to the correct channel (usually 3 or 4) or use AV input if connected via RCA cables.
5. Remote Control Setup – Insert the included batteries into the remote.
6. Set Clock and Channels – Follow the on-screen setup to adjust the clock and scan for available channels.

Now, the VCR is ready for playback and recording.

This answer is automatically generated

0

Related Manuals for Sharp VC-A592U

Summary of Contents for Sharp VC-A592U

  • Page 1: Table Of Contents

    5. ELECTRICAL ADJUSTMENT ......31 5-1 ADJUSTMENT OF HEAD SWITCHING POINT ............32 VC-A593U/A5933U/H992U ....Models for Canada VC-A592U/A593U/H993U/H994U ..Models for U.S.A. This document has been published to be used for SHARP CORPORATION after sales service only. The contents are subject to change without notice.
  • Page 2 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U IMPORTANT SERVICE NOTES etc.) and measure the AC voltage drop across the BEFORE RETURNING THE VIDEO CASSETTE resistor. Reverse the AC plug on the set and repeat RECORDER AC voltage measurements for each exposed part. Before returning the video cassette recorder to the user, Any reading of 0.45V rms (this corresponds to 0.3mA...
  • Page 3 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U NOTES DE SERVICE IMPORTANTES AVANT DE RENDRE LE MAGNETOSCOPE pièces métalliques exposées ayant un parcours de retour au châssis (connexions d’antenne, coffret Avant de rendre le magnétoscope à l’utilisateur, effectuer métallique, tétes de vis, boutons et arbres de commande, etc.) et mesurer la chute de tension CA...
  • Page 4 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U PRECAUTIONS IN PART REPLACEMENT When servicing the unit with power on, be careful to the section marked white all over. This is the primary power circuit which is live. When checking the soldering side in the tape travel mode, make sure first that the tape has been loaded and then turn over the PWB with due care to the primary power circuit.

  • Page 5: General Information

    Power Consumption: 20 W Weight: 2.8 kg (6.2 lbs) Dimensions (approx.): 360 (W) x 92 (H) x 253 (D) mm (14-3/16" x 3-5/8" x 9-31/32") (VC-A592U/H992U) 360 (W) x 92 (H) x 255 (D) mm (14-3/16" x 3-5/8" x 10-3/64") (VC-A593U/H993U) 360 (W) x 92 (H) x 256 (D) mm (14-3/16"...

  • Page 6: Location Of Major Components And Control

    VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U 1-3 LOCATION OF MAJOR COMPONENTS AND CONTROL...

  • Page 7: Disassembly And Reassembly

    VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U 2. DISASSEMBLY AND REASSEMBLY TOP CABINET 2-1 DISASSEMBLY OF MAJOR BLOCKS : Remove 2 screws 1. TOP CABINET : Remove button 2. FRONT PANEL Remove 2 screws 3 and 7 clips 4. : Remove 1 screw 5.

  • Page 8: Disassembling The Mechanism/Main Pwb Assembly

    VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U 2-2 DISASSEMBLING THE MECHANISM/MAIN PWB ASSEMBLY 2. Removing the mechanism and cassette housing. 1. When removing the mechanism from the main PWB, Remove 2 screws 4 fixing the cassette housing to the remove the antenna cover 1 screw 1, and remove the mechanism, and remove the cassette housing.

  • Page 9: Cares When Reassembling

    VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U 2-3 CARES WHEN REASSEMBLING cassette housing. (Conditions: When mechanism and PWB INSTALLING THE CASSETTE HOUSING have been installed) When the cassette housing is installed on the mechanism, the initial setting is essential condition. 2. Mechanical initial setting...

  • Page 10: Function Of Major Mechanical Parts

    VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U 3. FUNCTION OF MAJOR MECHANICAL PARTS (TOP VIEW) Function Function Full erase head Take-up main brake Supply pole base ass’y Pinch drive cam Tension arm A/C head ass’y Idler wheel ass’y Reverse guide lever ass'y Pinch drive lever ass’y...
  • Page 11 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U FUNCTION OF MAJOR MECHANICAL PARTS (BOTTOM VIEW) Function Function Drum ass’y Reel belt Loading motor Clutch lever Drum drive motor Limiter pulley ass'y Take-up pole base ass’y Shifter Slow brake lever Master cam Capstan D.D. motor...

  • Page 12: Adjustment, Replacement And Assembly Of Mechanical Units

    VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U 4. ADJUSTMENT, REPLACEMENT AND ASSEMBLY OF MECHANICAL UNITS The explanation given below relates to the on-site general service (field service) but it does not relates to the adjustment and replacement which need high-grade equipment, jigs and skill. For example, the drum assembling, replacement and adjustment service must be performed by the person who have finished the technical courses.
  • Page 13 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U MAINTENANCE CHECK ITEMS AND EXECUTION TIME Perform the maintenance with the regular intervals as follows so as to maintain the quality of machine. Maintained 500 1000 1500 2000 Possible symptom Remarks Parts hrs. hrs. hrs. hrs. encountered Abnormal rotation or significant vi- Guide roller ass’y...
  • Page 14 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U REMOVING AND INSTALLING THE CASSETTE Notes: HOUSING 1. When fitting the S/E sensor holder to the cassette controller frame L/R, take care. • Removal 2. Misengagement of teeth of casecon drive gear and drive 1. In the cassette removing mode, remove the cassette.
  • Page 15 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U REEL DISK REPLACEMENT AND HEIGHT 4. Assemble the Sup main brake ass'y. CHECK Notes: • Removal 1. When installing the reel disk, take due care so that the 1. Remove the cassette housing control assembly. tension band ass'y is not deformed and grease does no 2.
  • Page 16 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U Note: Notes: Whenever replacing the reel disk, perform the height check- 1. Hold the torque gauge by hand so that it is not moved. ing and adjustment. 2. Do not keep the reel disk in lock state. Do not allow long- time measurement.
  • Page 17 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U Notes: CHECKING AND ADJUSTMENT OF TAKE-UP 1. Hold the torque gauge by hand so that it is not moved. TORQUE IN VIDEO SEARCH REWIND MODE 2. Do not keep the reel disk in lock state. Do not allow long- •...
  • Page 18 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U CHECKING THE VIDEO SEARCH REWIND BACK TENSION • Remove the cassette housing control assembly. • After short-circuiting TP801 provided at the center Tension gauge Pinch roller (facing to the main PWB), plug in the power cord. 900 - 1,200gf •...
  • Page 19 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U 2. Visually check to see if the right edge of the tension pole Tension pole adjuster adjusting range is within the 2.3 ± 0.25 from the right edge of the Sup guide shaft. Tension pole adjuster Sup guide shaft Tension pole 2.3 ±...
  • Page 20 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U • Adjustment • Checking the brake torque at the take-up side 1. If the indication of torque cassette meter is lower than the setting, shift the tension spring engagement to the part A. Torque gauge 2. If the indication of torque cassette meter is higher than the setting, shift the tension spring engagement to the part B.
  • Page 21 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U REPLACEMENT OF A/C (Audio/Control) HEAD 3. Align the left end of gear of A/C head arm with the punched mark of chassis, tentatively tighten the screws 1. Remove the cassette housing control assembly. 1 and 2 so as to ensure smooth motion of A/C head 2.
  • Page 22 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U A/C HEAD HEIGHT ROUGH ADJUSTMENT HEIGHT ADJUSTMENT OF REVERSE GUIDE • Setting 1. Adjust the height from the mechanism chassis to the Azimuth screw reverse guide lower flange to 13.38 mm, using the reverse guide height adjustment jig, in tape loading state.
  • Page 23 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U Notes: ADJUSTMENT OF TAPE DRIVE TRAIN 1. Previously set the tracking control in the center position, 1. Tape run rough adjustment and adjust the envelop waveform to maximum with X 1 Remove the cassette housing control assembly.
  • Page 24 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U 3 Next, change the alignment tape to VROEFZCS or VROEFZHS to playback. Press the tracking button PB CHROMA (+), (–) and change the envelope waveform from Envelope max to min and from min to max. At this time adjust...
  • Page 25 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U REPLACEMENT OF DRUM D.D. MOTOR REPLACEMENT OF THE CAPSTAN D.D. 1. Set the ejection mode. (DIRECT DRIVE) MOTOR 2. Withdraw the main power plug from the socket. • Remove the mechanism from the main PWB (refer to Page 8 "item 1 When removing the mechanism from the...
  • Page 26 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U REPLACING THE UPPER AND LOWER DRUM ASSEMBLING OF PHASE MATCHING ASSEMBLY MECHANISM COMPONENTS • Assemble the phase matching mechanism compo- • Replacement (Perform in the numerical order) nents in the following order. 1 Remove the motor as stated in Page 25 D.D. motor 1.
  • Page 27 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U 1Insert Reverse Guide Lever Ass’y Insert reverse guide lever ass'y 2 Insert pinch drive cam Align here. Turn the reverse guide lever assembly counterclockwise Fit the pinch drive cam so that the notch of pinch to the stopper.
  • Page 28 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U 1. Make sure that the loading gear is at the Phase-Match- INSTALLING THE SHIFTER ing point 1 as shown below. 2. Install, paying attention to insert point 5 and release point 3. Drum 3. For the phase matching at the insert point 1, see the Capstan Phase-Matching point 2 as shown below.
  • Page 29 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U INSTALLING THE MASTER CAM (AT REAR REPLACEMENT OF LOADING MOTOR • Removal SIDE OF MECHANISM CHASSIS) 1. Make sure beforehand that the shifter is at the point as shown below. 2. Place the master cam in the position as shown below.
  • Page 30 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U ASSEMBLY OF CASSETTE HOUSING 1. Drive Gear and R Drive angle ass’y MSPRT0381AJFJ Apply grease Apply grease Apply grease Figure 4-47. 2. Synchro Gear, Drive Gear L and Drive Gear R LANGF9592AJFW Top surface should be free from scratches or soil.

  • Page 31: Electrical Adjustment

    VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U 5. ELECTRICAL ADJUSTMENT Notes: • Before the adjustment: Electrical adjustments discussed here are often required after replacement of electronic components and mechanical parts such as video heads. Check that the mechanism and all electric components are in good working condition prior to the adjustments,otherwise adjustments can not be completed.

  • Page 32: Adjustment Of Head Switching Point

    VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U SERVO CIRCUIT ADJUSTMENT 5-2 ADJUSTMENT OF FV (False Vertical Sync) OF STILL PICTURE 5-1 ADJUSTMENT OF HEAD SWITCHING Measuring Color TV monitor POINT instrument Measuring Dual-trace oscilloscope Mode Playback still instrument Cassette Self-recorded tape (SP mode) Mode...

  • Page 33: Adjustment Of Sif-Input Level

    VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U MTS CIRCUIT ADJUSTMENT (HI-FI MODELS ONLY) 5-4 ADJUSTMENT OF SIF-INPUT LEVEL Measuring AC milli-voltmeter and RF signal instrument generator. Mode Input signal RF CH-10 (at 300Hz 30% MOD.) Test point AUDIO OUT jack (R channel) Control R142(S-IF ADJ.)

  • Page 34: Mechanism Operation Flowchart And Troubleshooting Guide

    VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U...
  • Page 35 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U...
  • Page 36 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U...
  • Page 37 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U...
  • Page 38 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U...
  • Page 39 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U...

  • Page 40: Troubleshooting

    VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U...
  • Page 41 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U...
  • Page 42 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U...
  • Page 43 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U...
  • Page 44 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U...
  • Page 45 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U...
  • Page 46 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U...
  • Page 47 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U...
  • Page 48 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U...
  • Page 49 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U...
  • Page 50 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U...
  • Page 51 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U - M E M O -...

  • Page 52: Block Diagram

    VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U 8. BLOCK DIAGRAM SYSTEM SERVO BLOCK DIAGRAM...
  • Page 53 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U...
  • Page 54 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U SIGNAL FLOW BLOCK DIAGRAM(VC-A592U/A593U/A5933U)
  • Page 55 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U Playback luminance signal Playback chroma signal Audio playback signal E-E signal Recording luminance signal Recording chroma signal Audio recording signal E-E signal(Audio)
  • Page 56 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U SIGNAL FLOW BLOCK DIAGRAM(VC-H992U/H993U/H994U)
  • Page 57 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U Audio playback signal E-E signal Playback luminance signal Playback chroma signal Recording luminance signal Recording chroma signal Audio recording signal E-E signal(Audio) VC-H993U VC-H994U VC-H993U VC-H994U...
  • Page 58 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U POWER CIRCUIT BLOCK DIAGRAM...
  • Page 59 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U SCHEMATIC DIAGRAM • The indicated voltages in the following diagram IMPORTANT SAFETY NOTICE: are measured with an SSVM, upon receiving color bars (400 Hz sound signal) in either the PARTS MARKED WITH " å " ( ) ARE...

  • Page 60: Schematic Diagram And Pwb Foil Pattern

    VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U 9. SCHEMATIC DIAGRAM AND PWB FOIL PATTERN MAIN CIRCUIT(1)(VC-A592U/A593U/H993U/H994U) * VOLTAGE MEASUREMENT MODE PB ..Parentheses ( REC ..Without Parentheses...
  • Page 61 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U...
  • Page 62 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U MAIN CIRCUIT(1)(VC-A593U/A5933U/H992U) * VOLTAGE MEASUREMENT MODE PB ..Parentheses ( REC ..Without Parentheses...
  • Page 63 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U...
  • Page 64 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U MAIN CIRCUIT(2)(VC-A592U/A593U/H993U/H994U) * VOLTAGE MEASUREMENT MODE PB ..Parentheses ( REC ..Without Parentheses...
  • Page 65 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U...
  • Page 66 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U MAIN CIRCUIT(2)(VC-A593U/A5933U/H992U) * VOLTAGE MEASUREMENT MODE PB ..Parentheses ( REC ..Without Parentheses...
  • Page 67 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U...
  • Page 68 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U MAIN CIRCUIT(3) * VOLTAGE MEASUREMENT MODE PB ..Parentheses ( REC ..Without Parentheses...
  • Page 69 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U...
  • Page 70 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U MAIN CIRCUIT(4)(VC-A592U/A593U/A5933U) * VOLTAGE MEASUREMENT MODE PB ..Parentheses ( REC ..Without Parentheses...
  • Page 71 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U...
  • Page 72 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U MAIN CIRCUIT(4)(VC-H992U/H993U/H994U) * VOLTAGE MEASUREMENT MODE PB ..Parentheses ( REC ..Without Parentheses...
  • Page 73 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U...
  • Page 74 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U OPERATION CIRCUIT (Except VC-H994U) (VC-H994U) * VOLTAGE MEASUREMENT MODE PB ..Parentheses ( REC ..Without Parentheses...
  • Page 75 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U PWB FOIL PATTERN OPERATION PWB...
  • Page 76 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U MAIN PWB...
  • Page 77 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U...
  • Page 78 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U Ref. No. Part No. Description Code Ref. No. Part No. Description Code - M E M O -...

  • Page 79: Parts List

    Pour que votre commande soit rapidement et correctement remplie, 3. PART NO. 4. DESCRIPTION veuillez fournir les renseignements suivants. In USA: Contact your nearest SHARP Parts Distributor to order. 1. NUMERO DU MODELE 2. NO. DE REF For location of SHARP Parts Distributor, 3. NO. DE PIECE 4.
  • Page 80 J Zener Diode H993U/H994U Only) D957 VHD1S40////-1 V 1S40 Q704 VS2SA1037KQ-1 V 2SA1037KQ D991 RH-EX0631GEZZ J Zener Diode Q705 VSKRC102S//-1 V KRC102S(VC-A592U/ D992 RH-DX0475CEZZ V DX0475CE å IC901 A593U/A5933U) RH-FX0034CEZZ V PC817 Q705 VSUN2211///-1 V UN2211(VC-H992U/ Q701 RH-PX0233GEZZ J LED, Start Sensor...
  • Page 81 VCEA9M1HW475M V 4.7 50V Electrolytic C215 VCKYCY0JF105Z 6.3V Ceramic C610 VCKYCY1CF104Z V 0.1 16V Ceramic C216 VCKYCY0JF105Z 6.3V Ceramic (VC-A592U/A593U/A5933U Only) (VC-A593U/A5933U/H993U/ C611 VCKYCY1CF104Z V 0.1 16V Ceramic H994U Only) C612 VCKYCY1CF104Z V 0.1 16V Ceramic C217 VCEA9M0JW107M V 100 6.3V Electrolytic...
  • Page 82 VCEA0A0JW108M V 1000 6.3V Electrolytic C711 VCKYCY1HB102K V 1000p 50V Ceramic C931 VCEA0A0JW337M V 330 6.3V Electrolytic C712 VCKYCY1HB102K V 1000p 50V Ceramic (VC-A592U/A593U/A5933U Only) C713 VCKYCY1HB102K V 1000p 50V Ceramic C932 VCQYTA1HM104J V 0.1 50V Mylar C714 VCKYCY1CF104Z V 0.1...
  • Page 83 VRS-CY1JF472J V 4.7k 1/16W Metal Oxide R675 VRS-CY1JF183J V 18k 1/16W Metal Oxide R609 VRS-CY1JF333J V 33k 1/16W Metal Oxide (VC-H992U/H993U/H994U Only) (VC-A592U/A593U/A5933U Only) R676 VRS-CY1JF102J V 1k 1/16W Metal Oxide R610 VRS-CY1JF183J V 18k 1/16W Metal Oxide (VC-H992U/H993U/H994U Only)
  • Page 84 R826 VRS-CY1JF333J V 33k 1/16W Metal Oxide R725 VRD-RA2BE472J V 4.7k 1/8W Carbon R832 VRS-CY1JF103J V 10k 1/16W Metal Oxide (VC-A592U Only) R833 VRS-CY1JF103J V 10k 1/16W Metal Oxide R725 VRD-RA2BE563J V 56k 1/8W Carbon R834 VRD-RA2BE103J V 10k 1/8W Carbon...
  • Page 85 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U Ref. No. Part No. Description Code Ref. No. Part No. Description Code S811 QSW-K0002AJZZ V Switch, Eject SWITCHES S813 QSW-K0002AJZZ V Switch, Power S881 QSW-Z0001AJZZ V Switch, Shuttle (VC-H994U Only) BALUNES S882 QSW-K0002AJZZ V Switch, Rec S883...
  • Page 86 H993U/H994U) LHLDX1032AJ00 V Frame (R) 500-3 HDECQ1967AJSA V Cassette Flap(VC-H992U) AH LHLDX1030AJZZ V Holder (L) 500-3 HDECQ1970AJSA V Cassette Flap(VC-A592U) AL LHLDX1031AJZZ V Holder (R) 500-3 HDECQ1971AJSA V Cassette Flap MLEVF0469AJFW V Proof Lever (R) (VC-A593U/A5933U) MLEVP0281AJ00 V Door Open Lever...
  • Page 87 - Guarantee Card — (U.S.A. Only) PACKING PARTS (NOT REPLACEMENT ITEM) SPAKC3951AJZZ - Packing Case(VC-H992U) — SPAKC3966AJZZ - Packing Case(VC-A592U) — SPAKC3967AJZZ - Packing Case(VC-A593U) — SPAKC3969AJZZ - Packing Case(VC-H993U) — SPAKC3970AJZZ - Packing Case(VC-H994U) — SPAKC3974AJZZ - Packing Case(VC-A5933U) —...

  • Page 88: Exploded View Of Mechanical Parts

    VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U 11. EXPLODED VIEW OF MECHANICAL PARTS Ref. No. Part No. Description Code Ref. No. Part No. Description Code MECHANISM CHASSIS PARTS...
  • Page 89 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U Ref. No. Part No. Description Code Ref. No. Part No. Description Code CASSETTE HOUSING CONTROL PARTS...
  • Page 90 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U Ref. No. Part No. Description Code Ref. No. Part No. Description Code CABINET PARTS VC-H994U Only Except VC-H994U...
  • Page 91 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U Ref. No. Part No. Description Code Ref. No. Part No. Description Code FRONT PANEL PARTS(VC-A592U/H992U) 500-7 500-3 500-2 500-1 500-5 500-4 502-2 502-1 PRECAUTION ON FRONT PANEL SET-UP Cassette cover Front panel Cassette housing Cassette cover open lever...
  • Page 92 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U Ref. No. Part No. Description Code Ref. No. Part No. Description Code FRONT PANEL PARTS(VC-A593U/H993U) 500-7 500-3 500-2 500-6 500-1 500-4 500-5 502-2 502-1 PRECAUTION ON FRONT PANEL SET-UP Cassette cover Front panel Cassette housing Cassette cover...
  • Page 93 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U Ref. No. Part No. Description Code Ref. No. Part No. Description Code FRONT PANEL PARTS(VC-A5933U/H994U) 500-7 500-3 500-2 500-6 500-1 500-5 500-4 VC-H994U 502-3 VC-A5933U 502-2 502-1 502-2 502-1 PRECAUTION ON FRONT PANEL SET-UP Cassette cover Front panel...

  • Page 94: Packing Of The Set

    RRMCG0235AJSB Infrared Remote Control Unit SSAKA0001AJZZ Polyethylene Bag QCNW-0322AJZZ SPAKP0114AJZZ 75 ohm Coaxial Cable Form Bag SPAKX1044AJZZ Packing Foam TLABK0005AJZZ No. Label SPAKC3951AJZZ (VC-H992U) SPAKC3966AJZZ (VC-A592U) SPAKC3967AJZZ (VC-A593U) SPAKC3969AJZZ (VC-H993U) SPAKC3970AJZZ (VC-H994U) SPAKC3974AJZZ (VC-A5933U) Packing Case MARK Not Replacement Item...
  • Page 95 VC-A592U/A593U VC-A5933U/H992U VC-H993U/H994U Ref. No. Part No. Description Code Ref. No. Part No. Description Code...
  • Page 96 Code Ref. No. Part No. Description Code COPYRIGHT C 1999 BY SHARP CORPORATION ALL RIGHTS RESERVED. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without prior written permission of the publisher.

This manual is also suitable for:

Vc-a593uVc-a5933uVc-h992uVc-h993uVc-h994u

Table of Contents
