OLT 9x6 Cabana Assembly Manual

Bevel
Hide thumbs

Advertisement

Quick Links

Download this manual
Thank you for purchasing
a 9x6 Cabana. Please take
the time to identify all the
parts prior to assembly.
Note: The General Assembly Manual
illustrates a Door Configuration in
the front center location. The Door
can also be positioned in the front
corners. To correctly configure Door
in front corners, follow general
assembly steps and refer to Page 37
for required changes.
Some of the safety and usage measures you may wish to consider include:
-snow load ratings vary by geographical location. If heavy or wet snowfall occurs, it is advisable to sweep the
snow off the roof(s).
-if the product is elevated, any structural and building code requirements are solely the customer's
responsibility, and should be abided by.
-in high or gusty wind conditions it is advisable to keep the structure securely grounded.
-have a regular maintenance plan to ensure screws, doors, windows and parts are tight.
Customer agrees to hold Outdoor Living Today Partnership and any Authorized Dealers free
of any liability for improper installation, maintenance and repair.
In the event of a missing or broken piece, simply call the Outdoor Living Today Customer Support Line
@ 1-888-658-1658 within 30 days of the delivery of your purchase. It is our commitment to you to courier
replacement parts, free of charge, within 10 business days of this notification. Replacement parts will not be
provided free of charge after the 30 day grace period.
1-888-658-1658
9x6 Cabana - Bevel
Assembly Manual
Safety Points and Other Considerations
Our products are built for use based on
proper installation and normal residential
use, on level ground. Please follow the
instruction manual when building your
shed and retain the manual for future
maintenance purposes.
www.outdoorlivingtoday.com
Page 1
Version #11
Jan 15, 2021
sales@outdoorlivingtoday.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the 9x6 Cabana and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for OLT 9x6 Cabana

Summary of Contents for OLT 9x6 Cabana

  • Page 1 9x6 Cabana - Bevel Version #11 Jan 15, 2021 Assembly Manual Thank you for purchasing a 9x6 Cabana. Please take the time to identify all the parts prior to assembly. Note: The General Assembly Manual illustrates a Door Configuration in the front center location.
  • Page 2 What to do before my Shed arrives? • Become familiar with this assembly manual and determine if you can complete the project yourself or will require a professional contractor. • One helper is recommended to assist in constructing your shed. It generally takes two people over two days to assemble a shed.
  • Page 3 Foundation Types for a 9x6 Garden Shed 75” 75” 105” 105” Completed Foundation Concrete Foundation Floor Frame Concrete Slab Foundation: - Slab must be at least the same size as assembled floor frame (75” x 105”) or larger. - 6” Deep foundation. - 1.0 Cubic Yards of concrete required.

  • Page 4: Parts List

    Thank you for purchasing our 9x6 Cabana. Please take the time to identify all the parts prior to assembly. Parts List: D. Trim and Miscellaneous Section Bottom Skirting 10 - 3/4” x 4 1/2” x 34 3/4” - Bottom Skirting (Bevel) A.
  • Page 5 9X6 CABANA HARDWARE PACKAGE Hardware Kit (Provided) x 255 x 25 SS2 - 3/4” Screws S1 - 2 1/2” Screws Silver x 152 SB1 - 3/4” Screws S3 - 2” Screws Black Headed x 32 x 51 N2 - 1 1/2” Nails SB2 - 2”...
  • Page 6 Regular Maintenance & Tips to prolong the life of your shed. Before/During Assembly: 1.) Paint each face and edge of your plywood floor with a latex exterior paint. 2.) Caulk wall seams if gaps appear. 3.) Caulk around window framing. 4.) Caulk perimeter between floor plywood and bottom wall plate.

  • Page 7: Floor Section

    A. Floor Section Exploded view of all parts necessary to complete Floor Section. Identify all parts prior to starting. Plywood Floor Plywood Floor Large (2) Small Floor Joist (4) Floor Joist Frames (3) Floor Runners Long (3) Concrete Pad (optional foundation method) Floor Runners Short (3)
  • Page 8 17 1/2” Both Outside Floor Joist Frames require 1 Floor Joist attachment. Center Joist 17 1/2” from Outside of Floor Joist Frame and attach with 2 - 2 1/2” Screws per end. Center Frame Position completed Floor Joist Frames with center 75”...
  • Page 9 Concrete Slab Foundation With Floor Runners attached, carefully flip the floor over and place on your foundation. Caution: you will need 2 people to assist you. Be careful when laying floor down not to bend or twist floor. When in place, level floor completely.
  • Page 10 Exploded view of all parts necessary to B. Wall Section complete the Wall Section. Identify all parts prior to starting. Front and Rear Top Wall Plate (4) Side Gable Wall Panel (2) Angle cut down length) Side Top Wall Plate (2) (Angle cut on end) Door Header Solid Wall...
  • Page 11 Important: Pilot hole ALL 2x3 Wall Studs with 1/8” drill bit prior Pilot Hole to screwing. This will make it first. much easier to attach together. Wall Plate Parts Hardware Starting with Solid Wall Panels, carefully lay panel Solid Wall Panels S1 - 2 1/2”...
  • Page 12 Optional Caulking seams will help prevent moisture from entering your shed. Caulking not 2 1/2” Screws included in kit. Pilot Hole first. Side Wall Panel Position 1st side wall panel on plywood floor so once again 2x3 bottom wall plate is sitting flush with floor framing.
  • Page 13 Complete attachments of remaining side walls as per Steps 11 - 15. Pilot Hole first. Position and attach both Window Walls as per Steps 11 - 15. Parts Hardware Window Walls S1 - 2 1/2” Screws (35” x 75”) x 2 x 6 total Flush to tip of Bevel.
  • Page 14 Notch to front and on top. Parts Attach Door Header to vertical door jambs with 2 - 2 1/2” Screws per Door Header side. Header is 3” wide at bottom and has a 1/2” thick x 2 1/2” wide strip of (2”...
  • Page 15 Optional - Caulking Pilot Hole seams will help prevent first. moisture from entering your shed. Caulking Angle not included in kit. screws into perimeter Floor Joists. Hardware When all walls are attached together, check alignment with the floor. Bottom S1 - 2 1/2” Screws of wall frames should sit flush with outside of floor framing, with siding overhanging x 36 total by approximately 1/2”.
  • Page 16 Front Top Plate Next, attach the Front Top Plates. The Front and Rear Top Plates are angle cut down the length. Once again, position Top Plates on wall frame so they are flush. Front and Rear Top Plates will fit between Side Top Plates. Attach with 4 - 2”...
  • Page 17 C. Rafter and Roof Section Exploded view of all parts necessary to complete the Roof Section. Identify all parts prior to starting. Middle Roof Outside Roof Filler Shingles (16) Panels (2) Outside Roof Panels (2) Panels (2) Ridge Boards (4) 44”...
  • Page 18 Locate 9 Rafters, 2 Soffits and a completed Ridge Board. Lay out on level ground as shown to the right. Double up Rafters as illustrated. Screw doubled up Rafters together Doubled up Rafters with 3 - 2 1/2” Screws per piece. - screw together with Parts (Steps 26 - 28) Hardware (Steps 26 - 28)
  • Page 19 Flip Rafter Section over so Soffit is facing down. Starting with the rear Section, lift completed rafters up and place on gable framing. Gable Notch Slide Rafter Section up on gable framing until bottom of Ridge Board slips into gable notch. Soffit should sit approx.
  • Page 20 Place front completed Rafter Section on gable walls as per Steps 30 & 31. Gable Notch Offsetting Metal Ridge Board Connectors. At the peak, align Ridge Boards so they are flush together and secure them with 12 - 1 1/4” Screws. Important: if there is a gap between Ridge Boards, have a helper push the front and rear walls closer together from outside.
  • Page 21 Parts (Steps 35 - 36) Roof Gussets are positioned on mid rafters. Have two helpers push the Roof Gussets Front and Rear Walls at the top from the outside of shed until inside to inside (3/4” x 3 1/2” x 48”) x 3 measurement between the Top Plates is 70”.
  • Page 22 Exploded view of upside down roof panels. Outside Roof Panel. Shingles overhang plywood on outside panels. Shingles and plywood flush on middle panel. Parts (Steps 38 - 42) Hardware (Steps 38 - 42) Identify all Roof Panels. There are 4 Outside Outside Roof Panels S1 - 2 1/2”...
  • Page 23 Shingles overhang plywood on Outside Roof Panel. Lift up, position and attach 2nd Outside Roof Panel on Rafters as per Step 39. Middle Panel Outside Panel Outside Panel Position and attach Front Roof Panels as per Steps 38 - 41. Roof Filler Shingles are included to cover roof seams.
  • Page 24 Attach above the exposure line. Exposure Line Slide in another filler shingle and attach as per Screw first filler shingle down to rafters Step 44. On your last row of shingles, attach smaller using 1 - 2 1/2” Screw per panel (2 in total). filler shingle with 2 - 1 1/2”...

  • Page 25: Miscellaneous Section

    D. Miscellaneous Section Exploded view of all parts necessary to complete the Miscellaneous Section. Identify all parts prior to starting. Note: Not shown: Interior Door Stops, 1 Interior Barrel Bolt Facia Nailing Window Strips (2) Rear Wall Ridge Caps Trim Kit (2) Narrow Trim (2) Pentagon Window...
  • Page 26 Thicker at Butt Parts Attach Bottom Skirting - Bevel around the base of the Bottom Skirting - Bevel shed.Bevel is thicker at butt and thinner at top of board. Skirting (3/4” x 4 1/2” x 34 3/4”) x 10 will hide floor framing. Gaps on side will be covered by Wide Trim Hardware pieces later.
  • Page 27 Trim out front and rear walls by attaching Top Wall Trim. Position with thick end of Bevel downward at top of wall, tight against Soffits. Attach with 4 - 1 1/2” Finishing Nails per piece. Parts Top Wall Trim (Bevel) (3/4”...
  • Page 28 Trim out rear corners with remaining pieces of Corner Trim and Wide Corner Trim. Align and attach with 8 - 1 1/2” Finishing Nails per piece as per Step 51. Align with top of Wide Corner Trim. Butt up tight to side of Wide Corner Trim.
  • Page 29 Attach Rear Wall Narrow Trim where wall panels come together and leave a seam. Position trim equally on wall seam and tight underneath Soffit and Rafter. Use 8 - 1 1/2” Finishing Nails per piece to secure. Parts Rear Wall Narrow Trim (1/2”...
  • Page 30 Attach Facia Nailing Strips to the underside edge of the plywood roof. Align corner of Nailing Strip with corner of roof plywood. Secure each Strip with 3 - 1 1/4” Screws. Complete all four pieces, two on each side of the shed. Parts Facia Nailing Strips (3/4”...
  • Page 31 Front Facia caps Side Facia. Attach Front and Rear Facia to rafter ends. There are 2 Facia pieces per side. Secure with 8 - 1 1/2” Finishing Nails per piece, ensure nails connect with the ends of the rafters behind Facia. Gaps between facia pieces will be covered by Detail Plates in Step 59.
  • Page 32 Important: Butt (thick) end of Ridge Cap will be facing towards the outside of shed. Parts (Steps 60 - 61) Place 1st Roof Ridge Cap on roof peak overhanging Roof Ridge Caps x 18 shingles by approximately 1”. Attach with 2 - 1 1/2” Shingle Hardware (Steps 60 - 61) Nails 9”...
  • Page 33 Position Vertical Door Trim pieces flush with inside edge of Door Jambs and tight to Soffits on top. Attach with 8 - 1 1/2” Finishing Nails per piece. Nail into the thick part Flush with inside of the bevel siding. of door jamb.
  • Page 34 2“ Screws 3/4” screw Top and Bottom Hinges centered on door trim. Attach Door Hinges to Top and Bottom Dutch Door Middle Hinges sections. Top Door has trim overhanging door at bottom while bottom door has trim recessed slightly. Hinges should centered on trims.
  • Page 35 1/4” gap on inside. Slight gap.Top Trim overlaps bottom trim to prevent water from getting in. Place the Top Dutch Door Panel into place and gap top and bottom trims on the outside about 1/8” apart. On the inside, horizontal door frames should be about 1/4” apart. Use a shim once again to help you.
  • Page 36 Temporarily position Interior Vertical Door Stop to help align Interior Barrel Bolt. Silver Barrel Bolt Hardware Attach Interior Silver Barrel Bolt to inside of door as illustrated Y5 - Silver Barrel Bolt above. Use 3/4” Silver Screws to secure. Refer to Step 69 to allow for x 1 total adequate clearance.
  • Page 37 Window frame. Caulk gap. Screw insert into bottom (thick) part of siding. Parts To reduce possible water from penetrating Window Inserts x 2 into the window cavity, caulk gap on both sides of window opening prior to installing Window Hardware Insert.
  • Page 38 Assemble Flower Box with Assembly Instructions included on Page 40. Position completed Flower Box below bottom of window trim and secure with 2 - 2” Screws per box. Screw from inside of box into the cen- ter wall stud. Attach second screw 2” underneath first screw and once again into the wall stud.
  • Page 39 Alternate Door Configuration (Door on Left or Right of Center) To configure the Cabana so the Door is positioned on the left or right of center wall panel, follow the general directions in this manual for a regular door configuration and note the following changes.
  • Page 40 Outdoor Living Today Flower Box Assembly Instructions Exploded Side Trims (D) View Front Trim (C) End Caps (B) 1 1/4” Parts Lists: Nails (G) A - Base, Rear & Front Box Frames (3pcs) 3/4” x 5 1/2” x 23” B - End Cap Frames (2pcs) 3/4”...
  • Page 41 In both cases we recommend that you consult with a paint and stain dealer in your area for their recommendations. We hope your experience assembling your 9x6 Cabana Garden Shed has been both positive and rewarding.
