OLT 9x6 Cabana Bevel Assembly Manual

Metal roof
Hide thumbs Also See for 9x6 Cabana Bevel:

Advertisement

Quick Links

Download this manual
Thank you for purchasing
a 9x6 Cabana. Please take
the time to identify all the
parts prior to assembly.
Note: The General Assembly Manual
illustrates a Door Configuration in the
front center location. The Door can also
be positioned in the front corners. To
correctly configure Door in front
corners, follow general assembly steps
and refer to Page 39 for required
changes.
Safety Points and Other Considerations
Our products are built for use based on
proper installation and normal residential
use, on level ground. Please follow the
instruction manual when building your
shed and retain the manual for future
maintenance purposes.
Some of the safety and usage measures you may wish to consider include:
-snow load ratings vary by geographical location. If heavy or wet snowfall occurs, it is advisable to sweep the
snow off the roof(s).
-if the product is elevated, any structural and building code requirements are solely the customer's
responsibility, and should be abided by.
-in high or gusty wind conditions it is advisable to keep the structure securely grounded.
-have a regular maintenance plan to ensure screws, doors, windows and parts are tight.
Customer agrees to hold Outdoor Living Today Partnership and any Authorized Dealers free
of any liability for improper installation, maintenance and repair.
In the event of a missing or broken piece, simply call the Outdoor Living Today Customer Support Line
@ 1-888-658-1658 within 30 days of the delivery of your purchase. It is our commitment to you to courier
replacement parts, free of charge, within 10 business days of this notification. Replacement parts will not be
provided free of charge after the 30 day grace period.
1-888-658-1658
9x6 Cabana - Bevel
Assembly Manual
(Metal Roof)
www.outdoorlivingtoday.com
Page 1
Version #4
May 26, 2020
