OLT CB128-SLIDER-PLY-AK Assembly Manual

12x8 cabana-slider-ak (t&g) plywood roof

Advertisement

Quick Links

12x8 Cabana - Slider - AK (T&G)
STOCK CODE #
CB128-SLIDER-PLY-AK
Roof Area: 115sqft
Thank you for purchasing
a 12x8 Cabana. Please take
the time to identify all the
parts prior to assembly.
Safety Points and Other Considerations
Our products are built for use based on
proper installation on level ground and
normal residential use. Please follow the
instruction manual when building your
shed and retain the manual for future
maintenance purposes.
Customers are responsible for ensuring
a solid, level, well-draining site for
construction.
Please check with your local municipal
or county by-laws before ordering this
product to confirm it complies with
building codes.
In the event of a missing or broken piece, call the Outdoor Living Today Customer Support Line @ 1-888-658-1658 with-
in 30 days of the delivery of your purchase. It is our commitment to you to courier replacement parts, free of charge,
within 10 business days of this notification. Replacement parts will not be provided free of charge after the 30 day
grace period.
All structures purchased from Outdoor Living Today are covered for a period of one year for defects in manufacturing
and workmanship. Costs incurred for customer installations are not included.
Failure to use supplied parts included in this kit could result in poor product performance and may void your warranty.
Please contact Outdoor Living Today's Customer Toll Free Line if you plan to deviate from our written instructions.
1-888-658-1658
Plywood Roof
Assembly Manual
- Snow load ratings vary by geographical location. If heavy or wet snowfall occurs, it
is advisable to sweep snow off roof frequently.
- If the product is elevated, any structural and building code requirements are solely
the customer's responsibility, and should be abided by.
- In areas with high or gusty wind conditions, it is advisable to install the structure
securely to the ground.
- Have a regular maintenance plan to ensure screws, doors, windows and parts are
tightly affixed.
Customer agrees to hold Outdoor Living Today and any Authorized
Dealers free of any liability for improper installation, maintenance and
repair.
www.outdoorlivingtoday.com
Page 1
Version #1.2
Apr 26, 2022
sales@outdoorlivingtoday.com

Advertisement

loading

Summary of Contents for OLT CB128-SLIDER-PLY-AK

  • Page 1 12x8 Cabana - Slider - AK (T&G) Plywood Roof Version #1.2 Assembly Manual Apr 26, 2022 STOCK CODE # CB128-SLIDER-PLY-AK Roof Area: 115sqft Thank you for purchasing a 12x8 Cabana. Please take the time to identify all the parts prior to assembly.
  • Page 2 What to do before my Shed arrives? • Become familiar with this assembly manual and determine if you can complete the project yourself or will require a professional contractor. • One helper is recommended to assist in constructing your shed. It generally takes two people over two days to assemble a shed.
  • Page 3 Foundation Types for 8x12 Garden Shed 96” 96” 136 1/2” 136 1/2” Completed Foundation Concrete Foundation Floor Frame Concrete Slab Foundation: - Slab must be at least the same size as assembled floor frame (136 1/2” x 96”) or larger. - 6”...
  • Page 4 Thank you for purchasing our 12x8 Cabana Garden Shed. Please take the time to identify all the parts prior to assembly. 1. Floor Section Steps Parts List - Pages 4 and 5 Floors 1-12 3 - 45 1/2” x 75” - Floor Joist Frames - Large 3 - 45 1/2”...
  • Page 5: Hardware Kit

    Parts List - Pages 4 and 5 Steps Facia Trim 67-71 4 - 3/4” x 2 1/2” x 51” - Facia Nailing Strips 4 - 3/4” x 5 1/2” x 58” - Side Facia (Angle Cut, 2 right, 2 left) 4 - 3/4”...
  • Page 6 Regular Maintenance & Tips to prolong the life of your shed. Before/During Assembly: 1.) Paint each face and edge of your plywood floor with a latex exterior paint. 2.) Caulk wall seams if gaps appear. 3.) Caulk around window framing. 4.) Caulk perimeter between floor plywood and bottom wall plate.
  • Page 7: Floor Section

    Exploded view of all parts necessary to complete A. Floor Section Floor Section. Identify all parts prior to starting. Note: Floor Footprint is 136 1/2” wide x 96” deep. Plywood Floor Large (3) Plywood Floor Small (3) Floor Joist Frames Small (3) Floor Runners (8) Floor Joist...
  • Page 8 When correctly positioned, attach each Joist with 4 - 2 1/2” screws (2 per end). You can find the Square Drive Screw Bit in the Hardware Kit Bag. find Square Drive Bit for the screws in with the Hardware Kit Bag. Attach each large and small floor joist Lay out Floor Joist Frames as illustrated.
  • Page 9 Parts Attach Front Floor Runners to completed floor frame with notch aligned Front Floor Runners flush with corner of floor framing and edge overhanging front by 2”. (1 1/2” x 5 1/2” x 68 3/16”) x 2 The overhanging edge of the front floor runners will be used later to support Hardware the sliding door track.
  • Page 10 push plywood Important - Make sure floor is together at seams. level before moving on to wall section. Use a level to confirm, and shim floor joists as required. Hint: Use a chalk line to mark location of floor Position all Large & Small Plywood Floor pieces joists determine on top of completed floor joists.
  • Page 11 B. Wall Section Exploded view of all parts necessary to complete the Wall Section. Identify all parts prior to starting. Front and Rear Top Plates (4) (Angle cut on edge) Rear Wall Panel (4) (34 1/8” wide) Gable Walls (4) Side Top Plates (6) (4 Angle cut on one end and 2 square cut.)
  • Page 12 Important: Pilot hole ALL 2x3 Wall Studs with 1/8” drill bit prior Pilot Hole to screwing. This will make it first. much easier to attach together. Bottom Wall Plate Parts Parts (Continued) For each Solid Wall Panel/Rear Solid Solid Wall Panels Front Wall Panels Wall Panel/Front Wall Panel, carefully lay (45 1/2”...
  • Page 13 Optional - Caulking seams will help prevent moisture from entering your shed. Caulking not included in kit. Do Not Attach Walls To Floor Until Step 23 Hardware (Steps 16 -18) Position side Solid Wall Panel into place on plywood floor. Butt both S1 - 2 1/2”...
  • Page 14 Pilot Hole first. Pilot Hole first. Pilot Hole first. Complete all Side and Rear Wall attachments as per Steps 15 - 17. The rear wall is made up of four Rear Solid Wall Panels. Toll Free 1-888-658-1658 www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 14...
  • Page 15 Pilot Hole first. Pilot Hole first. Parts Hardware Position and attach both Window Walls as Window Walls S1 - 2 1/2” Screws per Steps 15 - 18. (45 1/2” x 75”) x 2 x 6 total Step to front and top. Align flush outside with wall siding.
  • Page 16 Aluminum strip on back of Long Door Header Attach Door Header - Short to other side. Position and attach Door Header - Long between short door headers. The Long Door Header has an aluminum strip attached to the back for added support. Attach by screwing down into wall framing with 2 - 3”...
  • Page 17 Advice: Prior to fastening walls and installing rafters, take time to confirm your walls are level, square and plumb. Measure diagonal at top and bottom of walls corner-to-corner. This should be approximately 159 7/8”. More importantly, if measurements are not within 1/4”, your walls are not square. Adjusting now will make it easier to install roof section Pilot Hole first.
  • Page 18 Next, attach the Front Top Plates. The Front and Rear Top Plates are angle cut down the length. Once again, position Top Plates on wall frame so they are flush. Front and Rear Top Plates will fit between Side Top Plates. Attach with 4 - 2” Screws per plate.
  • Page 19 Flashing overhangs wall on outside. Use a straight edge to check that angle of Gable lines up with Top Wall Plate angle. Adjust Gable for best fit. Place completed Gable section so framing sits flush with the inside of the Top Wall Plate. It should also be centered side-to-side on the Top Wall Plate.
  • Page 20 C. & D. Rafter and Roof Section Exploded view of all parts necessary to complete Large Plywood the Roof Section. Identify all parts prior to starting. Roof Panel (4) Small Plywood Roof Panel (4) Metal Ridge Board Connectors Ridge Boards (4) 52 1/2”...
  • Page 21 Ridge Board Locate 9 - Rafters, 2 - Soffits & complet- 2 1/2” Screws ed Ridge Board. Lay out on level ground as into Doubled shown to the right. Double up Rafters as illus- up Rafters trated. Screw doubled up Rafters together with 3 - 2 1/2”...
  • Page 22 Soffit Carefully lift 1 completed Rafter Section up (make sure Soffit is facing down) and place on gable framing. Soffit should sit approx. Gable Notch 1/8” away from wall panel. End Rafter will sit flush with end of wall. Slide Rafter Section up on gable framing until bottom of Ridge Board slips into gable notch. Soffit will sit approximately 1/8”...
  • Page 23 Offset Metal Ridge Board Connectors Hardware (Step 35) At the peak, align Ridge Boards so they are flush together and secure S2 - 1 1/4” Screws them with 12 - 1 1/4” screws. To completely secure Ridge Boards, place 4 - 1 x 16 total 1/4”...
  • Page 24 91” across Parts Roof Gussets are positioned on middle Rafters. Prior to attaching, make Roof Gussets sure walls are properly aligned. Have two helpers push walls at the top from the (3/4” x 3 1/2” x 72”) x 3 outside of shed until inside to inside measurement between front and rear plates Hardware is 91”.
  • Page 25 With Roof Plywood Large correctly positioned on rafters, attach plywood to rafters with 12 - 1 1/4” screws. On 5th rafter, be sure to angle screw to hit the meat of the rafter. Parts Hardware Locate one sheet of Roof Plywood Small. Position Roof Plywood Small S2 - 1 1/4”...
  • Page 26 Parts Hardware Locate second sheet of Roof Plywood Small. Roof Plywood Small S2 - 1 1/4” Screws Position below previous panel and attach with 8 - 1 1/4” (5/8” x 8 5/8” x 72”) x 1 x 8 total screws. Parts Hardware Repeat Steps 39 - 43 to complete opposite side of...
  • Page 27: Miscellaneous Section

    D. Miscellaneous Section Important- Illustrations show shed with Cedar and Metal Roof Panels and assembly is interchangeable. Parts Attach Bottom Skirting pieces around the base of the shed. Bottom Skirting Side Skirting will hide floor framing. Gaps on side will be covered by (1/2”...
  • Page 28 Flush to bottom of wall siding. Parts Hardware Attach Filler Trim to each corner side Filler Trim N1 - 1 1/2” Finishing Nails wall. Align Filler Trim so it sits flush with the (5/8” x 2 1/2” x 75”) x 4 x 32 total bottom of the last piece of Wall siding.
  • Page 29 A wood clamp may be helpful Front Soffit to hold the track in place while attaching to Soffit. Door 3/8” Header 3/8” Gap between Track and Door Header. Extra piece of lap siding can be used as a spacer. Tracks meet Note: Aluminum track has pre-drilled in the middle holes for screws which do not line...
  • Page 30 Twist Roller Cart onto bolt. After doors are hung, you may need to adjust this until doors hang straight up and down at equal height. Parts Locate all four Roller Assemblies. Before attaching to top of doors, Sliding Doors assemble the units as shown above. Attach two Roller Assemblies to (36”...
  • Page 31 1/4” Gap Lower Door Track 1 5/8” Parts Locate Door Tracks and Door Stops. Middle Door Stop should be Lower Door Track centered on shed and outer Door Stops should be 1 1/2” from edge of (1 1/2” x 1 5/8” x 60”) x 2 bottom skirting.
  • Page 32 Door Stop and Track Cover are flush Parts Hardware Locate Door Track Covers. Lineup so Track Lower Door Track Cover S1 - 2 1/2” Screws Covers are flush with Door Stops. This creates an (3/4” x 3 1/2” x 43 1/2”) x 3 x 12 total enclosure so doors can not slide out of the track.
  • Page 33 Left Side Right Side Door Door Door Flange attaches to Left Side Door. Flush with inside of door frame. Parts Position Interior Door Flange on the rear of the left side door Interior Door Flange (when viewed from the front of the shed). Ensure flange is flush with (3/4”...
  • Page 34 Fit Corner Trim tight underneath Soffit. To trim out corners, start with a Corner Trim, align tight underneath Soffit and Rafter. Align Wide Corner Trim with bottom of Corner Trim. Corner Trim will cap the Wide Corner Trim. Do a dry run in each cor- ner before attaching to confirm positioning.
  • Page 35 Attach Rear Wall Narrow Trim where wall panels come together and leave a seam. Position trim equally on wall seam and tight underneath Soffit and Rafter. Use 8 - 1 1/2” Finishing Nails per piece to secure. Parts Rear Wall Narrow Trim (1/2”...
  • Page 36 Facia/Roof Nailing Strips (4 @ 3/4” x 2 1/2” x 48” Parts Attach Facia/Roof Nailing Strips (3/4” x 2 1/2” x 51”) to Facia Nailing Strips the underside edge of roof plywood with 4 - 1 1/4” Screws per (3/4” x 2 1/2” x 51”) x 4 piece.
  • Page 37 Pentagon Facia Plate Parts Attach Pentagon Facia Plate where End Facia Pentagon Facia Plates meets at the peak. Use 4 - 1 1/2” finishing nails per (1/2” x 3 1/2” x 8”) x 2 piece to secure. Hardware N1 - 1 1/2” Finishing Nails x 8 total Facia Detail Plate Horizontal Gable Detail Plate Parts...
  • Page 38 caulk in siding gap at top. caulk in siding Requires a large channel on both amount. sides of window. Parts Locate Window Inserts. Before installing, dab caulk in siding channel on Window Inserts both sides of window opening. This will prevent water from getting in behind win- (18 1/4”...
  • Page 39 Congratulations on assembling your 12x8 Cabana! Note: Our Sheds are shipped as unfinished products. If exposed to the elements, the western red cedar lumber will weather to a silvery-gray color. If you prefer to keep the cedar lumber looking closer to the original color, we suggest that you treat the wood with a good oil base wood stain. You may also wish to paint your new shed rather than stain it.
