OLT 9x6 Cabana BC96-BEV-CEDAR Assembly Manual

Hide thumbs

Advertisement

Table of Contents

Version #13.3
Feb 24, 2025
Stock Code:
BC96-BEV-CEDAR
GAR88-BEV-METAL
GAR88-BEV-PLY
Thank you for purchasing an
9x6 Cabana. Please take the
time to identify all the parts
prior to assembly.
Important Information:
- It is the sole responsibility of the customer to check with your local municipal or county by-laws before
ordering this product to confirm it complies with building codes in your area.
- If the product is elevated, any structural and building code requirements are solely the customer's
responsibility, and should be abided by.
- Snow load ratings vary by geographical location. If heavy or wet snowfall occurs, it is advisable to sweep
snow off roof frequently.
- In areas with high or gusty wind conditions, it is advisable to install the structure securely to the ground.
- Have a regular maintenance plan to ensure screws, doors, windows and parts are tightly affixed.
- All structures purchased from Outdoor Living Today are covered for a period of one year for defects in
manufacturing and workmanship. Costs incurred for customer installations are not included.
- Failure to use supplied parts included in this kit could result in poor product performance and may void
your warranty. Please contact Outdoor Living Today's Customer Toll Free Line if you plan to deviate from
our written instructions.
Customer agrees to hold Outdoor Living Today and any Authorized Dealers free of any liability for improper
installation, maintenance and repair.
In the event of a missing or broken piece, simply call the Outdoor Living Today Customer Support Line
@ 1-888-658-1658 within 30 days of the delivery of your purchase. It is our commitment to you to courier
replacement parts, free of charge, within 10 business days of this notification. Replacement parts will not
be provided free of charge after the 30 day grace period.
1-888-658-1658
9x6 Cabana - Bevel
Assembly Manual
www.outdoorlivingtoday.com
Page 1
