Summary of Contents for Igloohome RG1
- Page 1 Installers & User guide Glass Door Lock. Version 0.1 07/21...
- Page 2 Welcome! This guide will get you up and running with your igloohome Glass Door Lock. In the meantime, you should follow igloohome on Facebook and Youtube! Like us on Facebook Visit our Youtube As our igloohome app is frequently updated, there may be changes to this manual.
-
Page 3: Table Of Contents
Table of Contents What’s Included Specifications Installation Guide Requirements Prepare Lock for Installation Installing/Replacing Batteries Installation Instructions Double Glass Doors Single Glass Doors User Guide Lock Anatomy Features Unlocking from the Outside Unlocking from the Inside Locking from the Outside Locking from the Inside App Onboarding Managing Access in App... -
Page 4: What's Included
What’s Included Smart Module Lock Assembly Clip-On Striker Magnet Sensor Drill Sheet RFID Tags x2 RFID Stickers x2 AA Alkaline Batteries x4... -
Page 5: Specifications
Specifications Model Battery Type 4 x AA* Alkaline Battery Life Up to 10 months Emergency Power 9V Alkaline Battery Operation Temp -20°C to 50°C Battery Operation Temp -10°C to 50°C IP Rating IP54 Material ABS, PC , Al, Zn Weight Net: 1.3kg, Gross: 1.6kg Unlock Mechanism Bluetooth, PIN code, RFID Tags/Stickers... -
Page 6: Installation Guide
Installation Guide Requirements Clearance Door Thickness Measurements Supported glass door thickness : 12mm The Glass Door Lock is designed to fit 12mm swinging glass doors only. Do ensure that there is sufficient clearance on your glass door for lock unit and clip-on striker. >... -
Page 7: Prepare Lock For Installation
Prepare Lock For Installation Install Smart Module 1. Unfasten the screws of the indoor unit and remove the housing 2. Snap the Smart Module into position and connect the cable 3. Assemble back the housing and fasten with the screws. Snap the Smart Module Connect... - Page 8 Glass Door and Lock Assembly orientation The keypad will be orientated automatically depending on how the lock is positioned during installation. Note: After a period of use, the keypad orientation will become fixed. To reset this, simply remove and reinstall the batteries. Left Hand Installation ‘LH’...
-
Page 9: Installing/Replacing Batteries
Installing/Replacing Batteries Using your fingers, loosen the screw on the battery cover and remove the battery cover. Battery Cover Twist to loosen screw Install or replace with 4 new Put back the battery cover and AA alkaline batteries tighten the screw. -
Page 10: Installation Instructions
Installation Instructions Double Glass Doors Lock one side of the glass doors in place. This must remain locked to use the lock. If this is not done, the lock will not secure the glass doors properly. Use a wet wipe/wet cloth to wipe the area of the glass door where the glass door lock will be installed on. - Page 11 Assembling the Lock Assemble the lock assembly onto one of the glass door by pushing it into place fully. Ensure the lock assembly is snugly in place.
- Page 12 Assembling the Clip-on Striker On the other glass panel, assemble the clip-on striker by pushing it into place fully. Ensure that it is installed at the correct height with respect to the lock assembly.
-
Page 13: Single Glass Doors
Installation Instructions Single Glass Doors Assembling the Lock Assemble the lock assembly onto the glass door by pushing it into place fully. Ensure the lock assembly is snugly in place. - Page 14 On the glass door frame, use the provided drill sheet to drill out the required holes to depths of 20mm. Door frame Depth Width: 20mm Note: If you are installing the Glass Door Lock with the Smart Module on the bottom of the unit (left-hand installation), please flip the drill sheet upside-down as well (with magnet hole at the top).
- Page 15 Ensure Glass Door Lock’s auto-relock is working when the glass door is closed, and that the locking and unlocking is smooth and unobstructed.
-
Page 16: User Guide
User Guide Lock Anatomy Front & Back Assembly Thumbturn Smart Module Touch Screen Keypad Unlock LED Indicator RFID Reader 9V Jumpstart Battery Cover Clear... -
Page 17: Features
User Pin codes, e.g. One-Time, Permanent & Duration. RFID The igloohome Glass Door Lock is able to register up to 100 key cards. Lock Manual Re-lock Auto Re-lock The igloohome Glass Door Lock User can press and hold the “unlock”... - Page 18 Features Security / Alarms Security Lockout Activity Logs Keypad or RFID is disabled after Entry via PIN codes and Bluetooth Key several incorrect access attempts to will be logged in the app. ensure your property is always secure. Bluetooth key access logs are updated in real-time and PIN code access logs are updated when the owner uses a Privacy Mode...
-
Page 19: Unlocking From The Outside
Unlocking from the Outside Bluetooth 1. Open your igloohome app 2. Tap on the “Bluetooth Unlock” button 3. The status indicator will flash green twice with 4 short ascending tones once unlocked. Home Glass Door Lock PIN Code 1. Press any button on the keypad to wake device up 2. - Page 20 RFID 1. Hold the registered card and move it closer towards the “RFID icon” on the Glass Door Lock. 2. The status indicator will flash green twice with 4 short ascending tone once unlocked.
-
Page 21: Unlocking From The Inside
Unlocking from the Inside Multi-Function Button Press the Multi-Function Button to Unlock. - Page 22 Bluetooth Unlock 1. Open your igloohome app 2. Tap on the “Bluetooth Unlock” button 3. The status indicator will flash green twice with 4 short ascending tones once unlocked. Home Glass Door Lock...
-
Page 23: Locking From The Outside
Locking from the Outside Auto Relock The igloohome Glass Door Lock relocks automatically when door is closed. User can configure the delay or deactivate* relock if they prefer to. Note: Function will only work when Sensor is installed. *Even if auto-relock is disabled, as a security feature, the Glass Door Lock will still lock after 30s if it is unlocked using the multi-function button/BT unlock and door is not opened. - Page 24 Manual Relock Press and hold the Unlock icon on the bottom right of the keypad for 2 seconds until the status indicator will show green with a long beep. Note: Used when Auto Relock is “Off”...
-
Page 25: Locking From The Inside
Locking from the Inside Multi-Function Button In the case that auto-relock function is disabled or does not work, after closing the door, user can alternatively press the Multi-Function Button to manually lock the Glass Door Lock from the inside. -
Page 26: App Onboarding
Test Factory PIN Unlock 1234567890 In the factory mode (before pairing), the PIN to unlock is Register as a Lock User a) Download igloohome from App store / Play store. b) Create an account and login. Pairing a) Select [Add new igloohome lock]... -
Page 27: Managing Access In App
Bluetooth Guest Key Bluetooth Guest Key can be shared with other users for mobile access. It allows your guests to unlock the igloohome smart lock via Bluetooth. There are 3 steps to using a Shared Bluetooth Key Under [Access], create [+Access] and choose [Bluetooth Key] under [Access Type]. - Page 28 Managing Access in App Adding Key Card 1. Under [Access], select [+Access] followed by [Keycard]. 2. Wait until the confirmation of the lock by an audio indicator (long beep). 3. Tap key card(s) on the lock to add and then rename the key card(s) on the App right away. 4.
-
Page 29: Lock Behaviour
Lock Behaviour Security Lockout After several incorrect PIN code or RFID attempts, the corresponding entry method will be locked out and the security alarm will be triggered. Note: Bluetooth, multi-function button and any other unlocking methods aside from the one locked out can be used to unlock in this mode Security Lockout 5 consecutive invalid PIN or RFID attempts... - Page 30 Privacy Mode Privacy Mode prevents others from using PIN code and RFID tag/stickers to unlock when you are inside the property. It can be activated when the Glass Door Lock is locked. Note: Bluetooth can be used to unlock in this mode. Passage Mode Passage Mode enables you to have easy access during high human traffic flow by deactivating auto relock.
-
Page 31: 9V Jumpstart
9V Jumpstart 9V Jumpstart Feature 1. Touch and hold the battery contacts against the 9V jumpstart pin on the lock and you will hear a series of beeps and the keypad will light up. 2. While holding the 9V battery to the jumpstart, key in your PIN code on the keypad followed by the ‘Unlock’... -
Page 32: Audio And Led Indications
Audio and LED indications Actions Indications Bluetooth Connection Status indicator flashes Blue Ascending 4 fast tones after unlocked Successfully Unlocked and flash Green LED 2 times 1 long beep after product is locked Successfully Locked and Green LED for 2 seconds Incorrect PIN 4 short beeps and flash Red LED 2 times Invalid RFID... -
Page 33: Troubleshooting
• Check if the Glass Door Lock is in privacy/ accepted within 1 hour of generation passage mode or security lockout mode • Update your igloohome app to the latest version • Check that your lock is not muted • Switch to a new set of batteries... - Page 34 FCC WARNING This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
- Page 35 For enquiries go to: igloohome.co/support...
