- Page 1 User guide Mortise Touch. Version 0.1 05/23...
- Page 2 LinkedIn YouTube Instagram We’re always updating our guides because we want to keep things fresh! You can visit igloohome.co/support periodically to view the latest version, unless, this is the latest version. Hello you, igloohomie from the future, wow!
-
Page 3: Table Of Contents
Table of Contents What’s Included Specifications Installation Guide Requirements Preparing the Door Installation Instructions User Guide Lock Anatomy Features Unlocking from the Outside Unlocking from the Inside Locking from the Outside Locking from the Inside Child & Pet Safety Handle Function App Onboarding Managing Access in App 9V Jumpstart... -
Page 4: What's Included
What’s Included Drill Sheet & Installation Guide Front Assembly Back Assembly Back Plate Strike Plates AA Batteries x4 RFID Tags x2 RFID Stickers x2 Screws 5 Physical Keys Mortise Shafts Mortise Assembly Note: 1. For door frames with thickness of 40mm and above, it is recommended to use the strike plate with an extended curved lip;... -
Page 5: Specifications
Specifications Model Gross (with packaging) 5.2kg / 11.46lbs 4.6kg / 10.14lbs Body Zinc Alloy, ABS, Acrylic Modes of Access (Entry) PIN codes, Digital Keys, RFID tags and stickers, Mechanical keys, Fingerprint unlock Modes of Access (Exit) Handle, Multi-function button Provided RFID Tags & Stickers 1 pair of tags | 1 pair of stickers RFID Tags &... -
Page 6: Installation Guide Requirements
Installation Guide Requirements Clearance Door Thickness 70mm (2.75”) 40mm-70mm >190mm (7.48”) (1.57” - 2.75”) (with handle) Mortise Assembly Length Dead bolt Cable Latch bolt Auxiliary latch... -
Page 7: Screw Specifications
Screw Specifications • 20mm For doors with thickness 40 - 55mm (0.78”) (1.57” - 2.16”) • 35mm For doors with thickness 50 - 60mm (1.37”) (1.96” - 2.36”) • 50mm For doors with thickness 65 - 75mm (1.96”) (2.55” - 2.95”) •... -
Page 8: Preparing The Door
Gap between door and door frame: <3mm (0.01”) Door and door frame material : Wood Note: Not for metal gates, glass doors or sliding doors. If you are unsure if your door is suitable, send us web links to your door pictures to support@igloohome.co... - Page 9 How to use the Drill Sheet Drilling (Door) Fold here Make sure this is before drilling aligned to the centre holes for side of door edge Door edge Chiselling Depth Width: 2 - 3mm (0.0079” - 0.01”) Door edge Mark the center of the holes and then drill for accuracy.
-
Page 10: Installation Instructions
Installation Instructions Mortise touch is set for Out-swing doors upon factory release. To switch for a In-swing door, adjust and reorient the lever inside the Internal Body as below. Unscrew off from the ‘PUSH’ position. Slide down to relocate the lever. Firmly fix the screw on the ‘PULL’... - Page 11 Install Mortise Inside Screws (0.31”) Mortise Shaft Install Outer Body Install the key cylinder of the outdoor unit correctly against the mortise installed on the door. Screws 35mm (1.37”)
- Page 12 Connecting Cable Outdoor unit cable Mortise cable The toggle switch must be the opposite from the outdoor body. Install Inner Body Be aware not to damage the cables during installation. Screws 12.7mm (0.50”)
-
Page 13: Installation Confirmation
Install Striker on the door frame. Ensure to chisel appropriately to the correct measurements. Dust Box Striker Screws 15mm (0.23”) Installation Confirmation 1. Insert batteries then the buzzer will sound 2. Lock the door by pressing and holding 3. Unlock the door with 1234567890... -
Page 14: User Guide Lock Anatomy
User Guide Lock Anatomy Outer Body Inner Body Touch Screen Keypad Low Battery Indicator Battery Cover RFID Reader Multi-Function button Key Cover Fingerprint Reader Outer Handle Inner Handle Emergency Jumpstart Note: Please remove the bottom cover to access keyhole... -
Page 15: Features
Features Decoy PIN Code Privacy Mode Disable all modes of access except Heighten security and throw off onlookers by entering random digits the Master Digital key to prevent before your actual PIN code. unwanted entries into your property. Battery Emergency Jumpstart Low Battery Alert Easily jumpstart the lock with a 9V Intuitive audio and visual alerts will... - Page 16 Modes of access PIN codes, Digital Keys, RFID tags & stickers, Modes of access (Entry) Fingerprint Modes of access (Exit) Digital Keys, Key Fob PIN Code As the owner of the lock, you can use the Master PIN code, issue Guest PIN codes, and test the lock during set-up with the Factory PIN code.
- Page 17 Bluetooth This mode requires you to have the igloohome app installed on your mobile phone with a verified account. You can be the owner of the lock, or be a recipient of a Guest Digital Key to use this as a valid mode of access.
- Page 18 The lock accepts RFID credentials. You can register up to 100 tags and stickers. Only the provided RFID tags and stickers are recommended. To purchase more, please go to www.igloohome.co/store 1. Tap your RFID tag or sticker on the RFID reader.
- Page 19 Key Fob 1. Press the button on the Key Fob. 2. The LED indicator on the lock will flash blue to establish the Bluetooth connection, then green when it is successfully unlocked. You will also hear four ascending tones. Note: The Key Fob needs to be used within Bluetooth range of the lock. Mechanical handle This can only be accessed from the back assembly.
-
Page 20: Child & Pet Safety Handle Function
Child & Pet Safety Function Activate 1. The function is deactivated by default. 2. To activate it, push the safety toggle to the right. 3. The Mortise now cannot be unlocked from the inside using the handle. Push Right... - Page 21 Deactivate 1. To deactivate the function, simply push the safety toggle towards the left. 2. The Mortise can now be unlocked from the inside using the handle. Push Left...
-
Page 22: App Onboarding
App Store Google Play Register for an igloohome account 1) Launch the igloohome app and tap [Create new account] 2) Fill in the fields shown on the screen. 3) Accept the terms of services and privacy policy. 4) Tap [Create account]. - Page 23 3. Tap on [Add Lock]. 4. Select the property you created. 5. Follow the instructions on the screen. If you’re pairing the lock to an existing igloohome account: and select [Add and manage]. 1. Tap on 2. Tap on [Add Lock].
-
Page 24: Fingerprint Registration
Managing Access via the app Fingerprint Registration Up to 10 authorized fingerprints can be added to the Padlock Lite 1. On the igloohome mobile app, tap on the icon. 2. Tap on [+Access]. 3. Select the access type from the list on the screen. - Page 25 (Text, Email, WhatsApp, Facebook Messenger etc.) to claim the Digital Key. Your guest will either need to download the igloohome mobile app and register for an account or claim the Digital Key with their existing igloohome account.
-
Page 26: 9V Jumpstart
9V Jumpstart 9V Jumpstart Feature 1. Touch and hold the battery contacts against the 9V jumpstart pin on the lock and you will hear a series of beeps and the keypad will light up if the batteries are fully drained. 2. -
Page 27: Changing Batteries
Changing Batteries Push the battery cover upwards to Insert AA Batteries remove it. Battery Cover Secure battery cover tightly by pushing it downwards. - Page 28 *Please ensure you are within Bluetooth range of the lock and your Bluetooth function is turned on. 1. On your igloohome app, tap on 2. Select [Auto Lock Timer] 3. Select from the list of preset durations, or customise the number of seconds, Auto Lock or choose to never automatically lock.
- Page 29 *Please ensure you are within Bluetooth range of the lock and your Bluetooth func- tion is turned on. Volume Control 1. On your igloohome app, tap on 2. Select [Volume]. 3. Select the volume level from 0 to 5 (softest to loudest).
- Page 30 *Please ensure you are within Bluetooth range of the lock and your Bluetooth function is turned on. Delete Lock 1. On your igloohome app, tap on 2. Select [Delete Lock]. 3. Follow the instructions shown on the pop-up and tap [Ok].
-
Page 31: Audio And Led Indications
Audio and LED Indications Actions Indications Bluetooth Connection Status indicator flashes Blue Ascending 4 fast tones after unlocked Successfully Unlocked and flash Green LED 2 times 1 long beep after product is locked Successfully Locked and Green LED for 2 seconds Incorrect PIN 4 short beeps and flash Red LED 2 times Invalid RFID... -
Page 32: Troubleshoot
• Check if the Digital Keys is expired. It must be has been installed on the door frame accepted within 1 hour of generation • Update your igloohome app to the latest version Slow locking / Unlocking • Switch to a new set of batteries •... -
Page 33: Fcc Compliance
FCC Compliance This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 34: Eu Declaration Of Conformity
The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc . ® and any use of such marks by igloohome Pte. Ltd. is under license . Other trademarks and trade names are those of their respective owners. - Page 35 For enquiries go to: igloohome.co/MT1support...
