- 1 Assembly Directions
- 2 Step 1: Center Back Panel Assembly
- 3 Step 2: Position Center Wire Tray
- 4 Step 3: Attaching Bracket Back Panel
- 5 Step 4: Attaching Worksurface Brackets
- 6 Step 5: Securing Back Panel Assemblies
- 7 Step 6: Positioning Modesty Panels
- 8 Step 7: Installing Center Modesty Panel
- Download this manual
Advertisement
Table of Contents
Related Manuals for Steelcase 8824RCT
Summary of Contents for Steelcase 8824RCT
- Page 1 Steelcase, Inc. Grand Rapids, MI 49501 U.S.A. 1-888-783-3522 Radius Computer Table Models: 8824RCT 8836RCT 8830RCT NOTE: Care should be taken to avoid scratching or marring painted surfaces! Tools #2 and #3 Phillips Assembly Directions Printed In U.S.A. 93-9501353 A Page 1 of 7...
- Page 2 Stand center back panel assembly on end in an inverted position, and secure right and left hand back panel assemblies onto each side with (4) screws. NOTE: Make sure panel assemblies are placed tight against each other without gaps, prior to tightening screws! NO SPACE SHOULD APPEAR AFTER ASSEMBLY 10 X 7/8”...
- Page 3 The center back panel includes (3) sets of (2) holes for attaching the bracket back panel attachment. Determine the height of your worksurface. The worksurface may be assembled at (3) different heights, (26”, 28”, and 30” high). Locate the set of holes for your heights. Secure bracket back panel attachment to center back assembly with (3) machine screws.
- Page 4 Each end panel assembly includes (3) sets of (2) holes for attaching worksurface brackets. The holes must match up with the same set of holes used in Step 3. Attach worksurface brackets to end panel assemblies with (2) machine screws each. NOTE: Start all machine screws with fingers and continue tightening with power driver, thus spreading flanges on brass inserts located in end panel assembly.
- Page 5 Position and secure right and left hand back panel assemblies to right and left hand end panel assemblies with (3) machine screws each. NOTE: Start all machine screws with fingers and continue tightening with power driver, thus spreading flanges on brass inserts located in each end panel assembly.
- Page 6 Position and secure right and left hand modesty panels to right and left hand end panel assemblies with (1) machine screw. NOTE: Start all machine screws with fingers and continue tightening with power driver, thus spreading flanges on brass inserts located in center back panel.
- Page 7 Remove center modesty panel from stored position in center wire tray, and insert between right and left hand modesty panel in the manner shown below. Secure center modesty panel to right and left hand modesty panels with (2) sheet metal screws. Align (2) holes in center modesty panel flange with (2) pre-drilled holes in underside of worksurface and secure with (2) wood screws.
