Philips Consumer Lifestyle
Service Manual
PRODUCT INFORMATION
• This product meets the requirements regarding
interference suppression on radio and TV.
• After the product has been repaired, it should function
properly and has to meet the safety requirements as
officially laid down at this moment.
TECHNICAL INFORMATION
• Colour
: Metallic Anthracite
• Battery
: NiMH 14.4 V 800 mAh
• Charging time
: 4 hrs
• Run time
: 50 min
• Moving speed
: 30 cm/sec
• Navigation
: Random walker 3-pattern
• Special features
: Stairs detector
• Sensors
: Infrared sensors for detecting
• Accuracy Hardfloor : Straigh line deviation
• Dustbin capacity
: 0.2 L
• Sound level
: 60 dB
• Size
: 300 x 50 mm
• Heigth
: 50 mm
• Net weight
: 1.3 kg
Published by Philips Consumer Lifestyle
12/07
soft-pack
combination
and avoiding stairs
± 8 cm per each 90 cm
Printed in the Netherlands
Vacuum cleaner
INCLUDED ACCESSORIES
• AC power adaptor
• 2 x Exhaust filter
• 2 x Side brushes
REPAIR INSTRUCTION
• No specific issues
OPTIONAL (accessories)
• No specific issues
© Copyright reserved
FC8802/01
Subject to modification
