Installation Instructions Page 1
1
1
Position bottom of stand 4-5 feet from base of tree.
3
As tree stand is being raised, the
person holding Installation Straps will
3
pull toward themselves to take up slack.
It will steady and ease the weight of
stand on the other two people. Continue
walking stand upward, until Tree
Connetion Brace is resting against the
tree.
Stabilizer Bar and Installation Straps MUST be secured prior to climbing the Ladder Stand.
Distributed by Acheson Harriman Swan, LLC, 2407 W. Euclid Ave., Littleton, CO 80120
Customer Service Department 1-866-972-6168
4
L
U
Slide the inner part of the Stabilizer Bar
into the outer part. Attach Stabilizer Bar
L
to the second rung of the Middle
4
Ladder Section
1-M8x45mm bolts
Insert the Adjustment Knob
Stabilizer bar at the proper adjustment
point to the tree.
W A R N I N G
Failure to comply may result in serious injury or death.
Drawings are for illustration purposes only and may not depict actual product.
2
One person will stand at the base of ladder with
2
his/her foot on the bottom rung while holding
installation straps. This will prevent tree stand from
sliding. Two people will stand at opposite ends of
tree stand, facing platform and slowly walk tree
stand upward using rungs of ladder.
B
45
B
with
.
45
U
in the
5
Model: RTLS-310
15' Ladderstand
5
Move base of ladder toward or
away from the tree slightly in
order to make Platform as
Parallel to the ground as
possible.
Apply your full weight to the first
step so it settles into the ground.
©2021 (rev. 1/21)
