Realtree RTLS-310 Instruction & Safety Manual page 13

Installation Instructions Page 3
10
11
O
L
N
12
P
NOTE: Follow these instructions in reverse to remove your ladder stand from tree.
Distributed by Acheson Harriman Swan, LLC, 2407 W. Euclid Ave., Littleton, CO 80120
Customer Service Department 1-866-972-6168
NOTE: The Ladder Jaws are designed to wrap around
a tree trunk when Vertical Jaw Assembly Vertical Strap
O
is tightened.
Before engaging the Ladder Jaw Mechanism:
1) Check that the Ladder stand is properly installed on
correct sized tree. If the ladder jaws cannot close
on the tree trunk (pictured left), the tree is too
large for safe installation.
2) Check that the installation straps
wrapped around the tree base and tightly secured
3) The ladder base is correctly and safely secured
onto level ground.
Check to make sure the Vertical Jaw Assembly
Strap is not caught, tangled or snagged.
O
Make sure the strap falls flat and straight from the
foot platform.
Carefully loop the Vertical Jaw Assembly Vertical
Strap O through either the right or left metal
hooks on the Stabilizer Bar
Lightly pull on Vertical Jaw Assembly Vertical
Strap O to check and make sure that both ladder
jaws close in on the tree trunk.
Loop Jaw Assembly Tree Buckle
through Jaw Assembly Ratchet Strap
N
N
.
With the Jaw Assembly Ratchet Strap
N
attached, wrap the Jaw Assembly
Tree Buckle
lower diagonal point from the Stabilizer
L
Bar (as shown right). Feed Jaw
Assembly Tree Buckle Webbing
though the spring loaded cam buckle
and firmly tighten around tree trunk.
Position Jaw Assembly Ratchet Strap
N
so that it faces the ladder. Feed
Vertical Jaw Assembly Webbing
through ratchet strap and ratchet the
strap tight until the tension closes the
ladder jaws. DO NOT overtighten.
See "Ratchet Strap Instruction" for
correct operation of the Ratchet Strap.
S
are correctly
L (as shown left).
P
P
around tree trunk at a
O
Model: RTLS-310
15' Ladderstand
