2.3 The Operator Panel

DIP-switch
location
TAC 200 Operator panel.
List of functions
P: Function
Time / Mode
00
01 Room temperature
02 Outdoor temprature
03 Supply temperature
04 Calc. supply temp. SP
05 SetPoint room, day
06 SetPoint room, night
07 Night setback SP (°C)
08 Curve parallel adjustm.
09 Time pr 1, day-by-day
10 Time pr 1, 1-7 days
11 Time pr 2, day-by-day
12 Time pr 2, 1-7 days
13 Clock hh:mm
14 Month.day
15 Year
TAC 200 List of functions and example on the use of the operating keys.
TAC AB, Feb 2000
The Operator panel consists of a semi-graphic display, a leaflet with the
functions and the following operating keys
– upward in list
P
– downward in list (in the text also called p
P
– increase value
+
– decrease value
–
– toggle switch for the 30 minutes segments
0/ l
List of
functions
P:00
0/ l
The keys P and P
up
tions, and the keys + and – (and in some cases 0/I) are used to change the
value of the selected item.
P
P
(in the text also called P
Display. Normally showing
P:00 followed by the time.
12:34
P
– +
P
are used to move up or down in the list of func-
down
Operating keys
Display
20.0
P:05
)
up
)
down
Operating keys
+
20.1
°C
19.9
–
General
2:5
