Application
TAC DuraDrive Direct Coupled Actuators are designed
to be used in both damper and valve control
applications. The following general instructions are for
damper applications, refer to the Applicable Literature
table for valve literature.
The MS40-717X series actuators are over the shaft
spring return actuators compatible with 2 to 10 Vdc or
1
4 to 20 mAdc
control signals.
Features
•
150 lb-in (17 N-m) rated torque
•
NEMA Type 4 housing (IEC IP56)
•
Custom automatic current sensing motor control
provides extended reliability and repeatable timing
•
Direct coupled to the damper shaft with dual
industrial hardened universal mounting clamps
•
Integral wiring for proportional control by 2 to 10 Vdc
1
or 4 to 20 mAdc
•
Clockwise or counterclockwise spring return is
determined by actuator mounting position
•
Accurate 92° travel digitally controlled
•
Integral position indication scale
•
Rugged die-cast housing
•
Oil immersed gear train provides continuous
lubrication
•
Integral transformer for high voltage systems
•
Rated for operating temperature up to 140 °F
•
Five year warranty
•
MS40-717x series actuators can be double-
mounted (gang mounting) to accommodate high
torque application requirements (2 to 4 actuators).
•
Position feedback signal
1.
With the addition of a 500 Ohm resistor - not in-
cluded
Printed in U.S.A. 11-07
TAC
1354 Clifford Avenue
P. O. Box 2940
Loves Park, IL 61132-2940
www.tac.com
© Copyright 2007 TAC All Rights Reserved.
MS40-717X Series
TAC DuraDrive™ Series Spring Return
Proportional Actuators
General Instructions
F-26748-4
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for t.a.c. DuraDrive MS40-717 Series
Summary of Contents for t.a.c. DuraDrive MS40-717 Series
- Page 1 MS40-717X Series 1354 Clifford Avenue P. O. Box 2940 Loves Park, IL 61132-2940 TAC DuraDrive™ Series Spring Return www.tac.com Proportional Actuators General Instructions Application TAC DuraDrive Direct Coupled Actuators are designed to be used in both damper and valve control applications.
-
Page 2: Applicable Literature
Applicable Literature F-Number Description Audience Purpose – Sales Personnel Describes the globe valve – Application Engineers actuator/linkage assembly’s features, MX40-6XXX-2XX, MX40-7XXX-2XX Series F-26750 – Installers specifications, and possible applications. Actuator/Linkage Assemblies General Instructions – Service Personnel Provides step-by-step mounting – Start-up Technicians instructions. - Page 3 Minimum Damper Shaft Length, Standard Damper shaft must be at least 4-5/8" (117 mm) long for standard mounting. Optional Shorter than standard length shafts require the AM-676 shaft extension (order separately). Position Indicator, Scale numbered from 0 to 95°, provided for position indication. Nominal Damper Area, Actuator sizing should be done in accordance with damper manufacturer’s specifications.
-
Page 4: Typical Applications (Wiring Diagrams)
TYPICAL APPLICATIONS (wiring diagrams) 2 to 10 Vdc MS40-7170 Yellow/Black Control Signal Gray Position Feedback (-) Blue Signal 2 to 10 Vdc (+) Black 120 Vac White Green/Yellow 1 Unused conduit port must remain plugged with a water tight pipe plug as shipped from factory to maintain NEMA Type 4 or IP56 rating. - Page 5 2 to 10 Vdc MS40-7171 Yellow/Black Control Signal Gray Position Feedback (-) Blue Signal 2 to 10 Vdc (+) Brown 240 Vac Light Blue Green/Yellow 1 Unused conduit port must remain plugged with a water tight pipe plug as shipped from factory to maintain NEMA Type 4 or IP56 rating.
- Page 6 4 to 20 mA MS40-7173 Yellow/Black Control 500 Ohm Signal Gray Position Feedback (-) Blue Signal 2 to 10 Vdc (+) 24H (DC+) Black 24G (DC-) 24 Vac Transformer Green/Yellow or 22-30 Vdc 1 Unused conduit port must remain plugged with a water tight pipe plug as shipped from factory to maintain NEMA Type 4 or IP56 rating.
-
Page 7: Installation
4 to 20 mA DC Controller MS40-717X Yellow/Black (+) 4 to 20 mA DC 500 Ohm Gray (-) Common DC Blue Green/Yellow MS40-717X Power Yellow/Black Gray Position Feedback (-) Blue Signal 2 to 10 Vdc (+) Green/Yellow 4 Color coding of wiring on older models (MX40-717x-0- 1 Unused conduit port must remain plugged with a 0-0) manufactured prior to December, 2007, differs water tight pipe plug as shipped from factory to... - Page 8 Precautions General Warning: • Electrical shock hazard! Disconnect the power supply (line power) before and during installation to prevent electric shock and equipment damage. • Make all connections in accordance with the wiring diagram and in accordance with national and local electrical codes. Use copper conductors only. Caution: •...
- Page 9 Mounting Mount the TAC DuraDrive Actuator directly on the damper shaft in locations that clear the maximum dimensions of the actuator case and allow the actuator to be mounted flush to the surface of the terminal box and perpendicular to the damper shaft. Note: Some terminal boxes have sheet metal screw heads or other protrusions near the damper shaft.
- Page 10 Mounting the Actuator for Clockwise or Counterclockwise Dampers The zero (0) position on the position indicator is the normal or spring return position. When the actuator is mounted with the “R” side facing the installer and the control signal increases the actuator will rotate in the counterclockwise direction.
- Page 11 CENTERLINE 1 Two AM-754 Universal Mounting Clamp Assemblies are provided with each actuator. Each clamp assembly includes 1 universal mounting clamp and 1 retaining clip. Two Universal Mounting Clamp Assemblies are required for all mounting configurations. Figure-10 Long Damper Shaft Mounting with Clockwise Spring Return for Normally Closed Damper. ©...
- Page 12 CENTERLINE 1 Two AM-754 Universal Mounting Clamp Assemblies are provided with each actuator. Each clamp assembly includes 1 universal mounting clamp and 1 retaining clip. Two Universal Mounting Clamp Assemblies are required for all mounting configurations. Figure-11 Long Damper Shaft Mounting with Counterclockwise Spring Return for Normally Closed Damper. Actuator mounting slot AM-751 Anti-rotation bracket...
- Page 13 Short Damper Shafts See Figure-13 for installation of actuator using the AM-676 Universal Shaft Extension. Installation requires AM-676 Universal Shaft Extension and AM-753 Universal Mounting Clamps for 3/4" to 1" (19 to 25 mm) shafts, these items must be ordered separately. 1.
-
Page 14: Wiring Requirements
Actuator AM-753 Anti-rotation Universal Bracket Mounting (included with Clamps actuator) AM-676 Universal Shaft Mounting Surface Extension V-clamp Duct 1 The AM-676 extends the damper shaft approximately 9" (229 mm). Damper Shaft Figure-13 Installation of Universal Shaft Extension. Wiring Requirements Control and Power Leads Remove blue plastic thread protectors before installing conduit fittings. -
Page 15: Theory Of Operation
CHECKOUT This procedure is for checking out a normally closed actuator that is typically mounted unpowered. It is possible to mount the actuator with power applied for special applications. Note: To check out a normally opened actuator the procedure is the same as below, except the initial position is open and closed when powered. -
Page 16: Dimensional Data
DIMENSIONAL DATA Figure-14 dimensions are in inches (mm). 4" (102) 4" (102) 1-27/64" (36) 10-27/32 (275) Figure-14 MS40-717X Damper Actuator. Copyright 2007, TAC 1354 Clifford Avenue All brand names, trademarks and registered trademarks are the property of their respective P.O. Box 2940 owners.
