2.2. System Overview

This chapter describes the functions and operating principal of the main component.

2.2.1. Front View

NOTE
• This illustration may differ from your machine depending on your model. There are various types of machine.
• Some features and optional goods may not be available depending on model or country.
C480
1 Scanner lid
2 Handle
3 Tray
4 Front door
5 Output support
6 Control panel
* C480W only.
Copyright© 1995-2017 SAMSUNG. All rights reserved.
2. Product specification and description
7 NFC tag *
8 Toner cartridges
9 Waste toner container
10 Imaging unit
11 Scan unit
12 USB port
13 Scanner glass
2-9
