DESCRIPTION
KNOW YOUR MOWER (Fig. A)
1. Self-Propel Switch
2. Self-Propel Speed-Control Knob
3. Safety Button
4. Switch Button for LED Headlights
5. Handle-Locking Clamp
6. Grass Bag
7. Quick-Adjust Lever
8. Cutting-height Adjustment Lever
9. Rear Wheel
10. Front Wheel
11. Mower Deck
12. Front Handle
13. LED Headlights
14. Battery Cover
15. Rear Handle
16. Rear Discharge Door
17. Side Rail
18. Mower-Status Indicator
19. Switch Lever
20. Handle
21. Support for Upright Storage
22. Trailing Shield
23. Battery-Release Button
24. Safety Key
25. Mulching Insert
OPERATION
ASSEMBLING THE GRASS BAG
1) Slide the grass bag onto the frame (Fig. B).
2) Assemble the top clips to the frame (Fig. C), then
assemble the two side clips. Assemble the bottom
clip last.
3) The completely assembled grass bag is shown in
Fig. D.
NOTICE:
Under normal usage, bag material is subject to
wear. To reduce the risk of injury, frequently inspect the
bag assembly and replace if there are any signs of wear
or deterioration. Use only grass bags manufactured for
this mower.
ADJUSTING THE FOLDABLE HANDLE
the handle has been locked at one of the three preset
operating positions (UPPER OPERATING POSITION,
MIDDLE OPERATING POSITION and LOWER OPERATING
POSITION).
Your mower is shipped with the handle in the compact,
LOCKED STORAGE POSITION (Fig. E).
1) Press and hold the quick-adjust lever to release the
2) Lift the handle from its folded position, then release
ATTACHING THE GRASS BAG
adjustment to the lawn mower without first stopping
the motor, removing the safety key and waiting for the
blade to stop rotating.
NOTICE: Remove the mulching insert before attaching
the grass bag on the mower.
◾
Insert the board of the grass bag into the mower and
hang the grass bag on the mower.
NOTICE: Remove the pre-installed mulching insert
from the mower before attaching the grass bag to the
mower.
◾
ADJUSTING THE CUTTING HEIGHT (Fig. I)
when adjusting its height. The mower can be set to 7
cutting heights between 25mm and 90mm. Choose
the proper cutting height according to the types and
conditions of the grass.
ATTACHING/DETACHING THE BATTERY PACK (Fig. J)
CHARGE BEFORE FIRST USE.
not attempt to attach the battery pack to the mower or
operate the mower until the broken or missing parts are
replaced. Failure to do so could result in serious injury.
56 VOLT LITHIUM-ION CORDLESS MOWER — LM2130E-SP
WARNING: Do not attempt to start the mower until
handle from the LOCKED STORAGE POSITION.
the lever. Gently pivot the handle upward until you hear
and feel the lock pin engage in one of the following
different positions as shown in the Fig. F.
WARNING: Do not at any time make any
To Attach/Remove the Grass Bag (Fig. G)
To Attach/Remove the Mulching Insert (Fig. H)
WARNING: Keep your feet away from the deck
WARNING:
If any parts are broken or missing, do
13
